Unit Description

Heat Recovery Ventilator - 150 CFM

parts/motor

controls

hrvcore

The industry’s most advanced residential fresh air system, created

to offer a universal platform specifically designed and improved to

make contractors life easier and more profitable while delivering

constant superior air quality.

product specificationssubjecttochangewithoutnotice.

• Polypropylene crossflow core, impact resistant

• Dimensions: 12" x 12" x 9" (30.5 cm x 30.5 cm x 23 cm)

• MERV 8 grade washable standard filter (included)

• Optional MERV 13 grade filter part no. V24285

1

• Optional HEPA media type filter part no. V25000

HRV

Top ports: V150H75NT

Side ports: V150H75NS

• SRE of 77% at 0°C and 63% at -25°C (64 CFM, 30 L/s)

• Ports size: 5 in.

• Negative pressure defrost (exhaust defrost)

• Corrosion resistant galvanized steel door and cabinet

• One-piece molded insulation shell, no air leakage

(expanded polystyrene; UL 94 HF-1 certified)

• Virtuo constant airflow and auto-balancing device

(patent pending)

• Motorized dampers (no additional backdraft dampers

required)

• Integrated "snap-in" drain system installed in seconds

with no additional parts (drain hose included)

• 6’ power cord

• Unit electrical characteristics:120 volts, 60 Hz, 2.4 A, 163 W

core

Filters

options

• Thanks to the Virtuo Air Technology

TM

, the airflow

calibration and auto-balancing are achieved quickly and

maintained throughout the life of the product

• Select the desired CFM (from 35 to 150 CFM, 17 to 71

L/s) using the proven integrated LCD screen. The airflow

is then set up automatically

• Integrated electronic airflow measurement device with

real time LCD

• Integrated diagnostic tool

• Equipped with PMSM ECM motors for a very low power

consumption

• Suspended installation (chains included)

OR

• Wall-mount installation (universal brackets included)

• installation with 2 brackets

• installation with 4 brackets

Refer to the Wall Control specification sheet for more

information.

35 to 150 CFM (17 to 71 L/s) @ 0.2 in. w.g.

35 to 140 CFM (17 to 66 L/s) @ 0.4 in. w.g.

F

a

b

r

i

q

u

é

a

u

M

a

d

e

i

n

CANAD

A

CANADA

1

Airflow performances associated with MERV 13 optional filter are not HVI certified. However, from tests performed by the manufacturer,

such performances are not affected by the use of this filter.

• Compatible with Tandem Terminations (part no. VTYIK1

and V14695) (CFM output must meet application

requirements)

vbathw

vbathbtw

vbathdw

aUtomaticDehUmiDistat

aDvanceD

toUchscreen

boost

overriDe

VC0190

VC0189

VC0191

VC0184

vautowvtdehumwvttouchw

maincontrols

aUxiliary

controls
