Doc. T644.01

TVTXI916S

TVEVO916S

P3

C

R

2

4

3

0

P3

1 2 3 4 5 6

SEL

SEL*

CH1

CH2

CH3

CH4

CH5

CH6

CH7

CH1

CH2

CH3

CH4

CH5

CH6

CH7

OFF

100%

75%

50%

Min.

DIM +

DIM -

CH1

CH2

CH3

CH4

CH5

CH6

CH7

CH1

CH2

CH3

CH4

ON (1)

OFF (1)

ON (2)

OFF (2)

www.bromicheating.com.au

TUNGSTEN SMART-HEAT™

WIRELESS REMOTE CONTROL

BY BROMIC

USER MANUAL

DESCRIPTION OF THE PRODUCT

UHF band remote with PLL controlled carrier frequency.

This type of remote is used for controlling devices for

domestic use, automatic openings, ON-OFF light control,

dimming, etc. This appliance transmits a rolling code type

signal to prevent duplication and guarantee maximum

secrecy. The remote code can be stored in the receiver

directly via the latter or via radio from the remote. With

the second possibility you can add new remotes to an

existing system without having to touch the receiver. This

can be done directly by the end user (the installer’s help is

not required). The code is stored in the receiver’s EEPROM

memory that retains it even if power is cut temporarily.

SAFETY RULES

• Do not use the manual remote in places or where

systems are sensitive to radio emissions (e.g. airports,

hospitals).

• Keep the remote out of the reach of children and

animals.

• Do not keep or use the remote in places that are damp,

where there is steam, high air humidity, dust or where

it is exposed to the direct rays of the sun or similar

environmental conditions.

• Do not let the manual remote drop: it could be damaged

or its range of action reduced.

• Changes or modification not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.

USE

• The operator is in no way protected against interference

from other telecommunication equipment or systems

(e.g. authorised radio systems working on the same

frequency range).

• If you are having problems with its range of action, fix

the remote up high. Change the battery if necessary.

CHANGING THE BATTERY

• Keep the batteries out of the reach of children.

• Call a doctor immediately if a battery is swallowed.

• Explosion hazard if the battery is substituted incorrectly.

• Replace the battery with a CR 2430 type battery only.

• Always wrap the battery up, both when it is being

stored and when it is being disposed of. The battery

should not come into contact with other metal objects

as it could cause the battery to run down, catch fire or

be damaged.

• Dispose of damaged or finished batteries immediately

in compliance with the law. To this end, contact the

authorities for safeguarding the environment or the

centre for disposing of waste materials in your area.

• Do not throw the battery away with household rubbish.

1. Open the back cover (manual remote) or the

battery housing (wall remote).

2. Take the old battery out and put the new one in the

same way.

Pay attention to correct polarity (+/-)!

REMOTE FIXING

If the remote is fixed on the wall with biadhesive, the

maximum holding will be reached after 24 hours from

the application. Application temperature min.+10°C.

GUARANTEE

The guarantee complies with the law. If the guarantee

has to be used please refer to the specialized retailer.

The right to the guarantee is applicable only for the

country in which the manual remote was purchased.

The batteries are not covered by the guarantee.

HOW TO STORE A REMOTE VIA RADIO WITHOUT

ACCESSING THE RECEIVER BY MEANS OF A

PREVIOUSLY STORED REMOTE

• Press the internal key P3 of a previously stored

remote , the enabled receiver emits a continuous

sound for 5 seconds.

• Transmit a channel present in the memory of the

receiver, in which the new code is to be memorized,

within 5 seconds and the buzzer will interrupt the

sound for 1 sec, and then carry on for another 5

seconds.

• Transmit the new channel to store within 5 seconds,

confirmed by intermittent buzzing.

CONFORMITY

Teleco Automation s.r.l. declares that the remotes

supplied satisfy the following technical regulations:

• FCC (Federal Communications Commission) Part

15 (FCC ID: P59TVTXI916S; P59TVEVO916S)

• IC (Industry Canada) RSS-102

(IC: 11242A-TVTXI916S; IC: 11242A-TVEVO916S)

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions

(1) this device may not cause harmful interference,

and (2) this device must accept any interference

received, including interference that may cause

undesired operation.

4/7 Channel Wall Remote42 Channel Portable Remote

Carrier Frequency916MHz

ModulationFSK

Power Supply

3V ±10%

CR2430 battery

Consumption when

transmitting

10mA

Working Temperature-10/+55°C

42 CHANNEL REMOTE

TECHNICAL DATA

The manufacturer programs each individual remote with a unique code

Manufactured by Teleco Automation s.r.l. - Italy - www.telecoautomation.com

The manufacturer reserves the right to modify design features and technical data without notice.

7 CHANNEL REMOTE

SEL button:

multi-remote function

Each LED position represents a

remote, in total 6 positions. Press the

SEL buttons from 1 to 6 times in order

to select the desired position. The

selection remains memorized until the

next variation, even with remote o;

it is sucient to press a channel push

button to reactivate the last selection.

4 CHANNEL REMOTE

Preset 1

Preset 2

Preset 3

Preset 4

DIM +

DIM -

O

Single/

Double

Single/

Double

Single

Single/

Double
