Seite 1/2

Major Speciﬁcations

• Workingradiofrequency:2.4GHz

• Numberofchannels:16

• Numberofgroups:4

• Supportssyncspeedupto1/8,000second

• AFAssistLED:1W

• Maximumeffectivedistance:100meters

• Operatingtemperature:-20°Cto+50°C

• Cameravoltagehandling:upto6V

• Flashvoltagehandling:upto300V

• Dimensions:79mm(L)x77mm(W)x48mm(H)

• Weight:96g

• Powerinput:2xAAbattery,3V,50mA,0.15W;mini

USB2.0,DCinput5V

Package Contents

Installing the Batteries

Openthebatterydoor

bypushingitbackward.

Flipopenthelatchand

inserttwoAAbatteries

usingthecorrect

polarities.Thenclose

thebatterydoorby

pushingittothefront.

Attaching to the Camera

UNLOCK

Turnthelockleverto

theRIGHTtoLOCKthe

multi-systemshoeto

thecamera.

LOCK

Turnthelockleverto

theLEFTtoUNLOCKthe

multi-systemshoefrom

thecamera.

Nomenclature

MULTI-SYSTEM

SHOE(MALE)

HOTSHOE

LOCKLEVER

BATTERYDOOR

TRIPODMOUNT

LEDSTATUSINDICATOR

MENUBUTTON

OKBUTTON

SELECTIONDIAL

LCDDISPLAY

MULTI-SYSTEM

SHOE(FEMALE)

X-SYNCPORT

MINIUSBPORT

MODESWITCH

AFASSIST

LIGHT

LANYARD

LOOP

TESTBUTTON/

SHUTTERRELEASE

BUTTON

GROUPBUTTONS

LCD Panel

CHANNEL POWERLEVEL POWERLEVELINCREMENT

BATTERYINDICATOR

GROUP

MAIN SCREEN

STATUS SCREEN ( + )

CAMERA

SYSTEM

POWERLEVEL/

ZOOM

FLASHPROFILE

FLASH

SYSTEM

SYNCMODE

INDICATOR

RELAYMODE

INDICATOR

DELAY

TIMER

TX Mode

RX Mode

WIRELESS

SENSITIVITY

CHANNEL

BATTERYINDICATOR

FLASH

PROFILE

POWERLEVEL

INCREMENT

POWER

LEVEL

DELAY

TIMER

RELAYMODE

INDICATOR

FLASH

SYSTEM

Cautions and Warnings

BeforeusingyourV6II,readthefollowingsafety

precautionstoensurecorrectandsafeuse:

• TurnOFFallyourequipment(e.g.,Cactusunits,

ashunits,cameras,etc.)beforechanging

batteries.Observethecorrectpolaritywhen

changingbatteries.Thereisadangerof

explosionifthebatteriesareinstalled

incorrectly.

• Switchoffthetransceiverandremovebatteries

duringstorage.

• Donotdisassemble.

• DonotcrushtheV6IIanddonotitexposeto

anyshockorforcesuchashammering,dropping,

orsteppingonit.

Choose the Operation Mode

SettheV6IItransceiverto

thecorrectmode(transmitter

to“TX”,receiverto“RX”)by

slidingthemodeswitchtothe

correctposition.

Setting & Selecting the Group

• TX:Activateany

combinationofgroups

bypressingthegroup

buttons.

• RX:Seteachunitto

GroupA,B,C,orDby

pressingthegroup

button.EachRXcan

onlybeassignedtoONE

group.

Setting the Channel

SetallofyourV6IItransceiverstothesame

channel(e.g.,channel10):

<RADIOSETUP>

Camera and Flash Indicators

Canon Fujifilm Nikon

Olympus

(M43)

Pentax Others

     

   

Camera and Flash Compatibility

Camera System Compatible Flash System



 

 

V6IITransceiver

FlashStandFS-2

QuickStartGuide

&Album



FujifilmashesdonotsupportHSScapabilities.

RF60/RF60X

Wireless

Flash

Transceiver

V6 II

QuickStartGuide

Remote Power Control

Function Key

Adjustingallgroups



Adjustingasinglegroup

(e.g.,groupA)

 +

Hold ,then

Adjustingtheon-cameraash

+

Remote Zoom Control

Function Key

Togglingtoandfromthezoom

controlpanel



Adjustingallgroups



Adjustingasinglegroup

(e.g.,groupA)

 +

Hold ,then

Adjustingtheon-cameraash

+

Normal HSS

TTL Pass-through

• TheV6IItransceivercomeswithamulti-system

shoethatsupportsTTLpass-throughofCanon,

Fujifilm,Nikon,Olympus,Panasonic,andPentax

systems.Makesurethatthecameraandashunit

belongtothesameTTLsystem.

• TurnON/OFFTTLpass-through:Hold

• TheLCDdisplaywillshow

theTTLpass-throughindicator

atthelowerleftcornerinTTL

pass-throughmode.

Corporate Oﬃce:

HARVESTONELIMITED

11D,BLK2,KOONWAHMIRRORFACTORY(6TH)IND.BLDG.,

7-9HOTINST,TUENMUN,HONGKONG

PLEASECONTACTYOURLOCALDEALERFORCUSTOMERSERVICE.

©HARVESTONELTD.2016(1

EDITION)

1.TurnontheHSS/FPsettingoftheremoteTTL

ashesattachedtotheV6IIRX.

2.ChooseNormalHSSfromtheV6IITXmenu.

Camera Shutter Release

1.ConnecttheV6IIRXto

yourcamerausingan

appropriateshutter

releasecable.

2.Matchthechannelandthe

groupoftheTXandtheRX.

Functions Status LED

Half-press Auto-focus Orange

Fullpress Releasethe

shutter

Green

Relay Mode

CameraShutter+Flash

V6 II Units TX RX1 RX2

Connection Handheld Mountoncamera’shot

shoeandconnectusing

acorresponding

shuttercable.

Connectto

ashunit.

Setup Nosetup

required.

RX1

RX2

Visitourwebsitetodownloadthe

usermanualandcheckforthelatest

firmwareupdates.

Forced HSS for Fujiﬁlm

FujifilmashesdonotsupportHSSashexposure.

However,CactusV6IIoffersaworkaroundtosupport

HSSashwithFujifilmcameras.

1.LearnHSS.

2.TurnON/OFFForcedHSSbypressing once.

www.cactus-image.com/v6ii.html

Power Sync

1.ChoosePowerSyncfromtheV6IITXmenu.

2.Adjustthesynctime,ifnecessary.

• TurnthedialtotheLEFTtoexpeditethesync

timeifyoufindadarkbandattheBOTTOMof

thepicture.

• TurnthedialtotheRIGHTtodelaythesync

timeifyoufindadarkbandattheTOPofthe

picture.

Notes:

1.Ifdarkbandsappearatboththetopandbottom

ofthepicture,theashdurationofthe

portableashmaynotbelongenoughtosupport

PowerSync.

2.TheashfiresfullpowerinPowerSync,so

checkforanoverheatwarningfromtimeto

time.FrequentuseofPowerSyncmayoverheat

theportableash.

Camera Setup (TX)

Method1:Auto-Detect

Half-presstheshutterreleaseofyourcamerawhile

switchingontheV6IItoTXmode.

Method2:ManualSelection(e.g.,Pentax)

Flash Setup (TX/RX)

Method1:Auto-Detect

UseanAutoFlashProfile:switchingontheV6IItoRX

modewillcausethetransceivertodetectandapplythe

AutoFlashProfile.

Method2:ManualSelection

Chooseaashspecific-profilefromthemenu

(e.g.,SB-910).

TurnonyourashandswitchittotheTTLmode.

ShownonlywhenaFujifilmcameraisused

<LEARNHSS>

<CAMERA&

FLASHSETUP>

<START>

<SYNCMODE> <POWERSYNC>

<SYNCMODE>

<SYNCMODE> <NORMALHSS>

<CAMERASYSTEM>

<CAMERA&

FLASHSETUP>

<ON>

Menu at a Glance

FUNCTIONS TX RX

-SYNCMODE

-DELAY

-RELAY

-GROUPSEQUENCE

-SPORTSSHUTTER

-TTLPASSTHROUGH

√

CAMERA & FLASH SETUP TX RX

-CAMERASYSTEM

-FLASHSYSTEM

-FLASHPROFILE

-LEARNHSS

√

FLASH SETUP TX RX

-FLASHSYSTEM

-FLASHPROFILE

√

TX

CAMERA&

FLASHSETUP

PREFERENCESFUNCTIONS POWER

SETUP

RADIO

SETUP

FLASH

SETUP

PREFERENCES

FUNCTIONS RADIO

SETUP

POWER SETUP TX RX

-POWERMODE

-EVSTEP

-LOPOWER

√

RADIO SETUP TX RX

-CHANNEL

-RADIOID

-MULTI-MASTER

-WORKRANGE

√

PREFERENCES TX RX

-AF-ASSIST(TX/RX)

-BACKLIGHTPOWER

-BACKLIGHTTIME

-DAYLIGHTMODE

-SWAPCONTROL

-DIALDIRECTION

-TEMPORARYUNLOCK

-SLEEP

-FACTORYRESET

√

<FLASHSYSTEM>

TX



<CAMERA&

FLASHSETUP>

RX



<FLASH

SETUP>

<NIKON>

<FLASHPROFILE> <NIKONSB-910>
