Installation instructions
DH75/DH110 RANGE
Installation model DH75/110
1. Remove machine from packaging and set on a level surface.
Check at machine is level bo vertically and horizontally.
2. Remove covers as shown in FIG.1 relative to machine type
installed.
3. The Electrical supply to unit must be sized according to e
data on e serial number label, paying close attention to
I.E.E regulations latest edition regarding e special conditions
governing electrical supply to machines in potentially damp
areas (DH75/110 are IP45).
4. The electrical supply should be connected to e terminals
on e Printed Circuit Board in e electrical box found in
e top corner of e machine, see Fig1 & Fig4. Wires to be
connected as follows: brown/red to live, blue/black - to neutral,
and green/yellow to ear.The fan mode switch can be set
to cycle fan when Hygrostat senses demand but should be
set to continuous to promote good air circulation and reduce
condensation.
Note that on models fitted with LPHW and or remote hygrostat
the fans will start automatically whenever there is an air heating
or dehumidification demand. During defrost the fans will stop. (Fan
cycle not recommended for TTW machines with humidistat only).
Set Fan Speed switch to “High” for maximum duty, “Low” for minimum sound.
5. Locate drain, 15mm compression fitting, on side of unit and run
it away to waste as preferred. A single hole is provided in e
side of e unit. The drain is factory fitted to is hole. (In TTW
machines ere is an alternate position - see drawings).
Models wi LPHW fitted
6. Connect water circuit piping to e 22mm stubs provided on
e side of e machine as per diagram.
7. It is recommended at isolation valves are fitted to enable
isolation of e machine in e event of service.
The Circulating Pump must be sized to take into account
e design flow rate of e machine plus e water system
resistance. (Flow Rate 9.6 l/min Pressure Drop 2.8 m/hd).
Please leave ese instructions for e user.
Fig 1
Standard &
TTW machine
Standard
machine
Mains in
terminals on
printed circuit
board
Grille
Fixing screws (3)
Outer cover
Rremove panel
(4 screws)
Mains in
Condensate
drain
LPHW in
LPHW out
Port B
LPHW out
Port AB
LPHW in
Port A to LPHW fin
block
Fig 2
LPHW SCHEMATIC
Boiler
Radiator
(If fitted)
Flow
balance
valve
Flow meter
3 way motorised vslve
LPHW connections
located in cabinet
(Diverting)
Pump
Fig 3
DH75/110
Radaitor
(If fitted)
HEALTH & SAFETY WARNING
As e Heat Pump contains electrical and rotational equipment, it is recommended at ONLY competent persons carry out any work on is type of
machine (see guarantee). Isolate electrically before entering machine or removing panels.
This appliance is not intended for use by persons (including children) wi reduced physical,sensory or mental capabilities, or lack of experience and
knowledge, unless ey have been given supervision or instruction concerning use of e appliance by a person responsible for eir safety.
Children should be supervised to ensure at ey do not play wi e appliance
ISOLATE ELECTRICALLY BEFORE ENTERING MACHINE OR REMOVING PANELS.
The Calorex TTW units are designed for installation in a heated room, adjacent to e poolroom.
SD405450 issue 15
