M0112_
OCT 2024
Page 1 of 8www.CANARM.COM
Canarm Ltd. - Corporate Head Office 2157 Parkedale Avenue, PO Box 367 Brockville, Ontario Canada K6V 5V6
Tel: (613) 342-5424 Fax: (613) 342-8437 [email protected] www.canarm.com
WALL EXHAUST FANS
BELT & DIRECT DRIVE
INSTALLATION AND MAINTENANCE INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
Models:XB, HV, HVA, HVAR, ADD, ADDR, DDS, DDP, SXB, SADD
THE PURPOSE OF THIS MANUAL IS TO AID IN THE PROPER INSTALLATION AND OPERATION OF THE
FANS. THESE INSTRUCTIONS ARE INTENDED TO SUPPLEMENT GOOD GENERAL PRACTICES AND ARE
NOT INTENDED TO COVER DETAILED INSTRUCTION PROCEDURES. IT IS THE RESPONSIBILITY OF THE
PURCHASER TO ASSURE THAT THE INSTALLATION AND MAINTENANCE OF THIS EQUIPMENT IS
HANDLED BY QUALIFIED PERSONNEL.
Inspect all shipments carefully for damage. THE RECEIVER MUST NOTE ANY DAMAGE ON THE CARRIER’S
BILL OF LADING AND FILE A CLAIM IMMEDIATELY WITH THE FREIGHT COMPANY.
ELECTRICAL CONNECTIONS
WARNING: BE SURE POWER IS OFF AT THE ELECTRICAL PANEL BEFORE WIRING.
WARNING: ALL ELECTRICAL WORK SHOULD BE PERFORMED
BY A QUALIFIED ELECTRICIAN.
INSTALLATION
1.Cut and frame the appr
opriate wall opening. Fans mounted to a wall require a different wall opening than fans
mounted in cabinets or sleeves. For specic dimensions, refer to the submittal drawing for the specic fan
conguration.
2.Mount the fan in the opening with the fan panel directly over the load bearing support and if this is not practical
angle supports must be provided to transfer the fan weight to the load bearing structure.
3.Caution: The fan contains rotating parts and requires electrical service. Appropriate safety precautions should
be taken during installation, operation and maintenance.
4.Warning: Do not install or operate this fan in an environment where combustible materials, gasses or fumes
are present unless it was specically designed and manufactured for that application.
5.A damper, if used, should be securely mounted in a manner that allows free and unobstructed operation.
6.All electrical work must be done, in accordance with all applicable electrical codes, by a qualied electrician.
Please follow all applicable national, state/provincial and local codes, all of them will supersede this manual.
7.Prior to wiring ensure the power supply is locked in the OFF position and that the motor nameplate voltage
and the supply voltage match.
8.Be sure to keep all wiring clear of any rotating parts.
9.Before starting the fan ensure that the wheel rotates freely.
