Cata GLADIUS 900XGBK PRO SILENCE Bedienungsanleitung

Lies die bedienungsanleitung für Cata GLADIUS 900XGBK PRO SILENCE (1 Seiten) kostenlos online; sie gehört zur Kategorie Dunstabzugshaube. Dieses Handbuch wurde von 25 Personen als hilfreich bewertet und erhielt im Schnitt 4.7 Sterne aus 13 Bewertungen. Hast du eine Frage zu Cata GLADIUS 900XGBK PRO SILENCE oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

Cod. 02000103 EAN 8422248102025

PRO SILENCE

Cod. 02181306 EAN 8422248102049

GLADIUS 900 XGBK

SILENT

90

c

m

LED

Mín. 632 / Máx. 1030

545

45

500

900

290

320

2013 2015&

❒

Touch Control Panel with authomatic shut-down timer and cleaning filters indicator

❒

5 extraction levels, 4 + 1 TURBO

❒

Extraction power (according to UNE/EN 61591): maximum:865m

3

/h- 282m

3

/h**

❒

PRO SILENCE. Roof Motor. Maximum energy consumption 155W

❒

This cooker hood just works with the PRO SILENCE motor

❒

High eiciency Led lighting

❒

Easy-to-install system

❒

MAX panelled stainless steel filters dishwasher washable

❒

Finished in black glass and stainless steel

❒

Max. Pressure: 470 Pa

❒

Inner panel for easy cleaning

❒

200 mm outlet diameter

❒

Energy Class: A*

▶ Accessories

(not included)

Top tube .................................................Cod. 02861300 / EAN 8422248016742 ..................................

* Energy class measured for the complete system of Roof motor+equivalent rangehoods.

** Tested with the 6m lengh aluminium flexible ducting provided.

865 m

3

/h

High Eiciency Motor

Code02181306

EAN8422248102049

Model

GLADIUS PRO SILENCE 900 XGBK

TypeBox

Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564

AEC (Anual Energy consumption) (kWh/annum)45,5

EEI class (Energy Eiciency Class)A

FDE (Fluid Dynamic Eiciency)32,3

FDE class (Fluid Dynamic Eiciency Class)A

LE (Lighting Eiciency) (lux/W)43,2

LE class (Lighting Eiciency Class)A

GFE (Grease Filtering Eiciency)69,5

GFE Class (Grease Filtering Eiciency class)D

Air flow at minimum speed (m3/h)282,4

Air flow at maximum speed (m3/h)582,1

Air flow at intensive speed (TURBO) (m3/h)865,3

Sound Power Level at minimum speed (dB)44

Sound Power Level at maximum speed (dB)56

Sound Power Level at intensive speed (TURBO) (dB)65

Po (Power Consumption in o mode) (W)0,48

Ps (Power Consumption in standby) (W)0

Integration directive EU 66/2014

ƒ (Time Increase Factor)0,8

EEI (Energy Eiciency Index)48

QBEP (Flow Rate at Best Eiciency Point) (m3/h)

527,2

PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa)379

WBEP (Electric Power Input at Best Eiciency Point) (W)137

WL (Nominal Power Consumption of Lighting system) (W)7,5

EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux)324

External Dimensions

Width (mm)900

Depth (mm)500

Total max height(mm1030

Total min height(mm632

Outlet Diameter (mm)200

Characteristics

MotorPRO SILENCE

Extraction Levels4+1

Motor Maximum Power Consumption162

Maximum Pressure379

Intensive Speed (TURBO) Pressure-

Control TypeTC4i

Automatic shut-down timer√

Electronic Filter Saturation Indicator√

Filter TypeMetallic

Anti-grease Filter Number3

Inner Shield-

Lighting

Light TypeEcoLed

Adjustable Intensity Lighting-

Nº of Lamps2

Installation

Minimum height distance to a electric worktop hob (mm)650

Minimum height distance to a gas worktop hob (mm)650

Instalation with Outlet tube to the exterior / RecirculatingEXTERIOR

Easy Instalation System√

Electric Connection

Total Rush Power (W)162

Rated Voltage (V)220-240

Network Frequency (Hz)50

Electrical Insulation ClassCLASS I

Plug-

Accessories

Upper Decorative tube Extension02861300

White Decorative Tube-

Black Decorative Tube-

Island Tube Enhancer-

Check Valve-

MAX PRO Metal Filter-

Metal Filter02800204*

DUAL Filter (metal + active charcoal)-

Active Charcoal Filter-

Noiseless Flexible Duct-

PROSILENCE
