900

371

240

290

370

730

340

Mín. 755 / Má 1070x.

Cod. 02184006 EAN 8422248102445

Cod. 02000103 EAN 8422248102025

90

c

m

LED

GRECO 90 WH

PRO SILENCE

2013 2015&

❒

Touch Control Panel with authomatic shut-down timer and cleaning filters indicator

❒

5 extraction levels, 4 + 1 TURBO

❒

Extraction power (according to UNE/EN 61591): 865m

3

/h- 282m

3

/h**

❒

PRO SILENCE. Roof Motor. Maximum energy consumption 155W

❒

This cooker hood just works with the PRO SILENCE motor

❒

High eiciency Led lighting

❒

Easy-to-install system

❒

Non-condensation filter XL

❒

Dishwasher-washable filters

❒

White glass finishing

❒

Max. Pressure: 470 Pa

❒

Front panel with opening for intensive use

❒

200 mm outlet diameter

❒

Energy Class: A*

▶ Accessories

(not included)

Top tub WH ..............................................Cod. 02861003 / EAN 8422248097765 .................................

Top tub INOX .............................................Cod. 02861303 / EAN 8422248097758 .................................

* Energy class measured for the complete system of Roof motor+equivalent rangehoods.

** Tested with the 6m lengh aluminium flexible ducting provided.

865 m

3

/h

High Eiciency Motor

Code02184006

EAN8422248102445

Model

GRECO PRO SILENCE 90 WH

TypeVertical

Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564

AEC (Anual Energy consumption) (kWh/annum)45,5

EEI class (Energy Eiciency Class)A

FDE (Fluid Dynamic Eiciency)32,3

FDE class (Fluid Dynamic Eiciency Class)A

LE (Lighting Eiciency) (lux/W)43,2

LE class (Lighting Eiciency Class)A

GFE (Grease Filtering Eiciency)69,5

GFE Class (Grease Filtering Eiciency class)D

Air flow at minimum speed (m3/h)282,4

Air flow at maximum speed (m3/h)582,1

Air flow at intensive speed (TURBO) (m3/h)865,3

Sound Power Level at minimum speed (dB)44

Sound Power Level at maximum speed (dB)56

Sound Power Level at intensive speed (TURBO) (dB)65

Po (Power Consumption in o mode) (W)0,48

Ps (Power Consumption in standby) (W)0

Integration directive EU 66/2014

ƒ (Time Increase Factor)0,8

EEI (Energy Eiciency Index)48

QBEP (Flow Rate at Best Eiciency Point) (m3/h)

527,2

PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa)379

WBEP (Electric Power Input at Best Eiciency Point) (W)137

WL (Nominal Power Consumption of Lighting system) (W)7,5

EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux)324

External Dimensions

Width (mm)900

Depth (mm)290

Total max height(mm1070

Total min height(mm755

Outlet Diameter (mm)200

Characteristics

MotorPRO SILENCE

Extraction Levels4+1

Motor Maximum Power Consumption162

Maximum Pressure379

Intensive Speed (TURBO) Pressure-

Control TypeTC4i

Automatic shut-down timer√

Electronic Filter Saturation Indicator√

Filter TypeMetallic

Anti-grease Filter Number1+1

Inner Shield-

Lighting

Light TypeEcoLed

Adjustable Intensity Lighting-

Nº of Lamps2

Installation

Minimum height distance to a electric worktop hob (mm)530

Minimum height distance to a gas worktop hob (mm)650

Instalation with Outlet tube to the exterior / RecirculatingEXTERIOR

Easy Instalation System√

Electric Connection

Total Rush Power (W)162

Rated Voltage (V)220-240

Network Frequency (Hz)50

Electrical Insulation ClassCLASS I

Plug-

Accessories

Upper Decorative tube Extension02861303

White Decorative Tube-

Black Decorative Tube02861403

Island Tube Enhancer-

Check Valve-

MAX PRO Metal Filter-

Metal Filter02800930+02800904

DUAL Filter (metal + active charcoal)-

Active Charcoal Filter-

Noiseless Flexible Duct-

PROSILENCE
