Cata ISLA MAGRABA Bedienungsanleitung
Cata
Dunstabzugshaube
ISLA MAGRABA
Lies die bedienungsanleitung für Cata ISLA MAGRABA (1 Seiten) kostenlos online; sie gehört zur Kategorie Dunstabzugshaube. Dieses Handbuch wurde von 21 Personen als hilfreich bewertet und erhielt im Schnitt 4.7 Sterne aus 11 Bewertungen. Hast du eine Frage zu Cata ISLA MAGRABA oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/1
65
c
m
LED
280
Ø650
Mín. 720 - Máx. 1700
Cod. 02119207 8422248069342 EAN
DECORATIVEISLANDS
❒
Electronic control panel with authomatic shut-down timer
❒
3 extraction levels
❒
Extraction power (according to UNE/EN 61591): 645m
3
/h - 300m
3
/h
❒
Maximum air flow: 1115m
3
/h
❒
Sound power (Reg.(EU) nº65/2014): 48dB(A), maximum: 63dB(A)
❒
BT2 motor. Extra silent. Maximum energy consumption 200W
❒
High eiciency LED lighting
❒
Easy-to-install system
❒
Recirculation operation
❒
Dishwasher-washable active charcoal filters
❒
Finished Stainless steel and white
❒
Max. Pressure: 400 Pa
❒
Energy class: C
MAGRABA ISLAND
MAGRABA ISLAND
Code 02119207
EAN 8422248069342
Model ISLA MAGRABA
Type Island
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Anual Energy consumption) (kWh/annum) 97,1
EEI class (Energy Eiciency Class) C
FDE (Fluid Dynamic Eiciency) 15,7
FDE class (Fluid Dynamic Eiciency Class) D
LE (Lighting Eiciency) (lux/W) 14,3
LE class (Lighting Eiciency Class) D
GFE (Grease Filtering Eiciency) 91,2
GFE Class (Grease Filtering Eiciency class) B
Air flow at minimum speed (m 3/h) 300
Air flow at maximum speed (m 3/h) 645
Air flow at intensive speed (TURBO) (m 3/h) -
Sound Power Level at minimum speed (dB) 48
Sound Power Level at maximum speed (dB) 63
Sound Power Level at intensive speed (TURBO) (dB) -
Po (Power Consumption in o mode) (W) 0,26
Ps (Power Consumption in standby) (W) 0
Integration directive EU 66/2014
ƒ (Time Increase Factor) 1,4
EEI (Energy Eiciency Index) 84,1
QBEP (Flow Rate at Best Eiciency Point) (m3/h) 385,1
PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 253
WBEP (Electric Power Input at Best Eiciency Point) (W) 172,1
WL (Nominal Power Consumption of Lighting system) (W) 10,5
EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 150
External Dimensions
Width (mm) 650
Depth (mm) 650
Total max height (mm) 1700
Total min height (mm) 720
Outlet Diameter (mm) -
Characteristics
Motor BT2
Extraction Levels 3
Motor Maximum Power Consumption 200
Maximum Pressure 400
Intensive Speed (TURBO) Pressure -
Control Type VL3
Automatic shut-down timer √
Electronic Filter Saturation Indicator -
Filter Type Metallic
Anti-grease Filter Number 1
Inner Shield -
Lighting
Light Type EcoLed
Adjustable Intensity Lighting -
Nº of Lamps 3
Installation
Minimum height distance to a electric worktop hob (mm) 650
Minimum height distance to a gas worktop hob (mm) 650
Instalation with Outlet tube to the exterior / Recirculating RECIRCULATION
Easy Instalation System √
Electric Connection
Total Rush Power (W) 210,5
Rated Voltage (V) 220-240
Network Frequency (Hz) 50
Electrical Insulation Class CLASS II
Plug -
Accessories
Upper Decorative tube Extension -
White Decorative Tube -
Black Decorative Tube -
Island Tube Enhancer -
Check Valve -
MAX PRO Metal Filter -
Metal Filter -
DUAL Filter (metal + active charcoal) 02800922*
Active Charcoal Filter -
Noiseless Flexible Duct -
