Seite 1/1

320

290

490

830

183

314

600/700/800/900

Min. 855 / Max. 1170

Cod. 02145506 EAN 8422248104876

THALASSA 800XGGR

AUTO

t i r a

l e d

DECORATIVESHOODS

Code 02145506

EAN 8422248104876

Model THALASSA 800XGGR

Type Vertical

Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564

AEC (Anual Energy consumption) (kWh/annum) 14,5

EEI class (Energy Eiciency Class) A+++

FDE (Fluid Dynamic Eiciency) 39,7

FDE class (Fluid Dynamic Eiciency Class) A

LE (Lighting Eiciency) (lux/W) 26,3

LE class (Lighting Eiciency Class) B

GFE (Grease Filtering Eiciency) 75,5

GFE Class (Grease Filtering Eiciency class) C

Air flow at minimum speed (m3/h) 283

Air flow at maximum speed (m3/h) 605

Air flow at intensive speed (TURBO) (m3/h) 842

Sound Power Level at minimum speed (dB) 46

Sound Power Level at maximum speed (dB) 64

Sound Power Level at intensive speed (TURBO) (dB) 69

Po (Power Consumption in o mode) (W) 0,4

Ps (Power Consumption in standby) (W) 0

Integration directive EU 66/2014

ƒ (Time Increase Factor) 0,6

EEI (Energy Eiciency Index) 29,3

QBEP (Flow Rate at Best Eiciency Point) (m3/h)

259,7

PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 326,2

WBEP (Electric Power Input at Best Eiciency Point) (W) 59,2

WL (Nominal Power Consumption of Lighting system) (W) 3

EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 79

External Dimensions

Width (mm) 800

Depth (mm) 314

Total max height(mm 1170

Total min height(mm 855

Outlet Diameter (mm) 150/125

Characteristics

Motor BT4DC

Extraction Levels 5 + 1

Motor Maximum Power Consumption 135

Maximum Pressure 357

Intensive Speed (TURBO) Pressure 365

Control Type TCD6i

Automatic shut-down timer √

Electronic Filter Saturation Indicator √

Filter Type Metallic

Anti-grease Filter Number 2+1

Inner Shield -

Lighting

Light Type SS Led

Adjustable Intensity Lighting √

Nº of Lamps 1

Installation

Minimum height distance to a electric worktop hob (mm) 400

Minimum height distance to a gas worktop hob (mm) 650

Instalation with Outlet tube to the exterior / Recirculating BOTH

Easy Instalation System √

Electric Connection

Total Rush Power (W) 143

Rated Voltage (V) 220-240

Network Frequency (Hz) 50

Electrical Insulation Class CLASS I

Plug -

Accessories

Upper Decorative tube Extension 02861300

White Decorative Tube -

Black Decorative Tube 02861401

Island Tube Enhancer -

Check Valve 02832004

MAX PRO Metal Filter -

Metal Filter 02800905* / 02800925*

DUAL Filter (metal + active charcoal) 02800918 / 02800927

Active Charcoal Filter 02859398

Noiseless Flexible Duct 02893002

❒

Touch Control Panel with digital display, authomatic shut-down timer

and cleaning filters indicator

❒

AUTO connectivity with automatic control from the CATA hob

❒

6 extraction levels, 5 + 1 TURBO

❒

Extraction power (according to UNE/EN 61591): 842m

/h - 283m

❒

Sound power (Reg.(EU) nº65/2014): 46dB(A), maximum: 64dB(A)

❒

BRUSHLESS motor. Ultra silent. Maximum energy consumption 135W

❒

High-eiciency lighting by intensity-adjustable two-tone warm / natural LED STRIP

❒

Easy-to-install system

❒

Non-condensation filter and Filter condensation collection area

❒

Dishwasher-washable filters

❒

Black/white/Grey glass finishing

❒

Max. Pressure: 357 Pa

❒

150/125 mm outlet diameter

❒

Energy Class: A+++

▶ Accessories

(not included)

Active charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02859318 / EAN 8422248098472 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Check valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02832008 / EAN 8422248086837. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top tub BK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02861403 / EAN 8422248078818 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top tub WH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02861003 / EAN 8422248097765 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Top tub INOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02861303 / EAN 8422248097758 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SILENTPOWER+A+

motor BRUSHLESSBRUSHLESS motorBRUSHLESS motor
