Seite 1/2
[1] Freeze gate ins. When a gate is sent
to these inputs, the acquisition process of
each channel is momentarily frozen and the
wavetable is locked.
The two trigger inputs are normalized
from left to right. Inserting a cable in the
right channel trigger input will break the
normalization.
[2] Time CV in (0-8V). Acquisition time can
be controlled from outside with this input.
[3] Preamp inputs (0-8v). To start feeding
signals into Proteo’s acquisition engine
patch any kind of source here .
The two inputs are normalized from left to
right. Beside being tought for unipolar CVs,
inserting bipolar signals here is still possible
without damaging the acquiring path.
[4] Speed CV (0-8V). If a patch cable is
inserted here, the playback speed can be
altered from outside.
[5] Time CV attenuverter. This dial works in
direct connection with the Time knob [6] and
permits to attenuate or invert the CV coming
from Time CV in [2].
[6] Time. This control changes the
acquisition speed. Thinking at it as a virtual
tape loop, you can take a bigger “window” by
recording longer fragments at slower speeds
(turning CW) or maybe just capture a small
detail by recording it at faster speeds (CCW).
[7] 2ch. Oscilloscope. This two section
display shows exactly what’s the waveform
coming out from each oscillator output.
[8] Outputs. Being a stereo oscillator,
Proteo has two separate outputs. The right
oscillator, by default, is tuned 1 octave below
the left one.
[9] V/oct input (0-7V). Both oscillators are
tied togheter by the same pitch and volt/
octave control. The right one ranges from C1
to C8 and can be considered as the “master”
oscillator.
[10] Span CV in (0-8V). Use this CV to alter
the detuing of the right oscillator.
[11] Morph CV in (0-8V). Use this CV to
change the Morph [15] perchentage from
outside.
[12] Span. The right oscillator by default
(with this dial at 12 o’clock) is tuned 1 octave
below the left one. When turned full CCW
it can go down to -4 octaves while, when
turned fully CW it can go 1 octave above the
left one. Making 5 octaves in total of span.
When a cable is patched into the Span CV in
[10] this control become an attenuverter of
incoming CV.
[13] Freq. Use this two controls to adjust the
whole intonation.
[14] Morph. Having a continously evolving
waveform with a lot of harmonics can make
hard to understand wich note is coming
out from Proteo outputs. That’s why both
channels can be blended with a sinewave
(faders at zero).
[15] Freeze buttons. Each channel can be
frozen manually by pressing these buttons.
In this case they work in latching mode.
PROTEO Quickstart manual.
Hi, thank you for purchasing PROTEO.
This sheet is intended to be a quick view of the module. For a more detailed guide
please refer to the online manual over the dedicated page at clank.eu
1
3
4
5
12
7
15
8
2
14
10
11
9
6
13
