Issue 7

(540) 563-2000

INTERIOR SPEAKERS

S-500 S-505

S-500VC S-505VC

INTRODUCTION

Transformer Tap Color Code

25 Volt Line

70.7 Volt Line

The S-500, S-500VC, S-505 and S-505VC are

speaker/transformer/baffle assemblies for use with any

Clarity Mixer-Amplifier. The S-500VC and S-505VC

include a volume control knob for volume level selection.

These speakers are for use in interior areas only.

C

olor Designation Color Designation

BLK Common BLK Common

BRN 5W GRN 5W

RED 2.5W WHT 2.5W

ORN 1.25W BLU 1.25W

GRN 0.625W GRY 0.625W

These instructions contain the specifications and

information necessary to install, operate and maintain the

Interior Speakers.

WHT 0.312W VIO 0.312W

Dimensions

S-500 13.00"Dia x 3.00"D

SPECIFICATIONS

S-500VC 13.00"Dia x 3.00"D

S-505 12.00"W x 9.70"H x 4.00"D Top

Product Description

2.00"D Bottom

- S-500 8" Ceiling Speaker Assembly

S-505VC Same as the S-505

- S-500VC 8" Ceiling Speaker Assembly with

Volume Control

* All dimensions are approximate.

- S-505 Wall Speaker Assembly

- S-505VC Wall Speaker Assembly with Volume

Control

Technical Specifications

Frequency Response: 65 to 17K

Maximum Power Capability: 5 Watts

Applications

SPL @ 4 Feet with 1 Watt Input: 98dB

- Clarity Paging Systems

Transformer Taps (Watts): 5/16, 5/8, 1-1/4,

- Clarity Background Music Systems

2-1/2 and 5

- Existing 25 or 70V Paging Systems

Line Voltage: 25 or 70V

Features

Environment

- Combination 25/70V Transformer

Temperature: 0 to +50 Degrees C

- Appropriate Baffle (white ceiling grille or wood

Humidity: 0 to 85% non-precipitating

grain with brown cloth front)

- 8" Speaker

1 947400
