CLIFF
Cliff Electronic Components Limited,
76 Holmethorpe Avenue, Holmethorpe Ind. Estate,
Redhill, Surrey RH1 2PF U.K.
Tel: +44 (0)1737 771375 Fax: +44 (0)1737 766012
www.cliffuk.co.uk
For further information, contact: sales@cliffuk.co.uk
QUICKTEST QT/1
RoHS
The Quicktest is ideal for electrical shops, factories, labs and service
departments.
With its lid open the wires of a plugless lead can be inserted into the
insulated clips. When the lid is closed, current passes to the equipment
being demonstrated or tested. A neon light shows that the connector is live
hot and ready to use. The 13 Amp fuse (BS 1362) is easily accessible for
replacement.
The connector is made of tough, safe materials. The base is phenolic,
moulded for insulation and rigidity. The lid is flame retardant glass filled
thermo plastic.
The insulated clips are colour color coded for easy identification. The
flexible cable grip will take any normal mains cable. Only one small
screwdriver is needed for both the base entry and the terminal screws.
There are 3 standard models:
CL1850 - Quicktest QT/1
CL1853 - Quicktest QT/1 with 2m cable to UK plug.
CL1860 - Quicktest QT/1 with 1.5m cable to Euro plug.
WARNING:Always connect the earth connection for safety. This device is intended for use by suitably qualified
personnel when making connection to the mains supply for test purposes only. It is not to be used for permanent or
semi-permanent connections. All connections must be insulated or otherwise suitably isolated to remove the possibility
of personal contact with live parts.
SPECIFICATION
Size - 130mm. x 60mm. x 50mm. high.
Max Rating - 13A. AC 250V.
5A. DC 24V.
Weight - 235 gms.
CL 1850 - QUICKTEST QT/1
CL 1853 - QT/1 ASSY UK PLUG 2m
CL 1860 - QT/1 ASSY EURO 1.5m
