HOTKEYPRESS FUNCTION

Cycles through software or hardware proles (depending on mode)

Adjusts backlighting brightness in 20% decrements

Disables the Windows key to prevent accidental keypresses*

* Can be programmed in iCUE to also disable other contextual menu key presses. Holding this key enters macro

recording mode.

GETTING TO KNOW YOUR KEYBOARD

SETTING UP YOUR KEYBOARD

Connect the detachable USB cable (P) to the keyboard USB Type-C port (M) and to an available

USB 3.0 or better Type-A port on your Windows

®

PC, Apple Mac

®

, or Microsoft Xbox

®

.*

*www.corsair.com/xbox-support

SOFTWARE MODE

When iCUE is running the keyboard operates in software mode and is controlled by iCUE

Install iCUE on a Windows PC or Apple Mac to connect all of your CORSAIR iCUE compatible

products together in a single interface, giving you complete control of everything from lighting

to powerful macros.

Download iCUE from www.corsair.com/downloads.

HARDWARE MODE

When iCUE is not running or the keyboard is connected to a device that does not support iCUE,

the keyboard operates in hardware mode which uses proles and settings saved to the

onboard storage.

With iCUE and the new dynamic prole system, you can create as many custom proles as can

t onto the 8MB of onboard storage. Each prole can store complex backlighting effects (up to 20

layers), actions & macros, and settings.*

AXON HYPER-PROCESSING TECHNOLOGY

FUNCTION HOTKEYS

Macros can be recorded at any time via the below process. In hardware mode your macros are

recorded to onboard storage and in software mode your macros are recorded to the current

iCUE prole.

MACRO RECORDING

Keyboard lighting effects can be controlled via the onboard shortcuts below when iCUE is not

running or the keyboard is connected to a device that does not support iCUE.

ONBOARD LIGHTING

With iCUE you can program vivid and

dynamic custom multi-layered lighting

effects, then save them to onboard storage.

CORSAIR AXON delivers a powerful and responsive keyboard experience with:

* The number of lighting effects layers per prole and total number of proles that can be saved

to onboard storage will vary based on complexity.

ENGLISH

ENGLISHENGLISHENGLISHENGLISH

1

2

3

4

CJK

P

Q

MON

A

DGFI

B

EHL

FACTORY RESET

To clear the onboard memory, hold the ESC key while plugging in the USB cable (P) to your

system, then release the ESC key after two seconds. The keyboard will then power on normally

and be reset to factory defaults.

>Hyper-fast keystroke detection and processing

>Up to 8,000Hz hyper-polling (adjustable in iCUE device settings)

>Up to 20-layer onboard lighting effects (programmable in iCUE per prole)

HOLD

(2 SECONDS)

PRESSKEYS

TO

RECORD

PULSESWHITEBLINKSWHITE

PRESSKEY

ORFN + KEY

COMBINATION

TOSAVE

PRESS

RAPIDLYBLINKSWHITE

HOLDTOCANCEL

Keys that can be recorded:

> Standard keys

Macros can be recorded to:

> Any standard key*

> FN + key*

* Hotkeys cannot be recorded

over with onboard macro

recording.

MACRO CLEANING PROCESS

NOTE: Saving a macro to a key or existing shortcut will overwrite that function until cleared.

With iCUE you can edit recorded macros and assign additional actions to keys.

MACRO RECORDING PROCESS

The Tournament Switch (N) is located on the backside of the keyboard and when turned on puts

the keyboard into a competition compliant mode that:

TOURNAMENT SWITCH

>Disables custom actions and macros to prevent accidental activation

>Changes backlighting to static single color to reduce distraction

>Offers standard operation without proles and prole switching

Other keyboard functions including the brightness key (B), Windows lock key (C), volume control

(J, K), and media keys (L) still function as normal.

To enable Tournament Mode:

1. Move the switch to the right position

> Indicator (O) will light up red when enabled

2. Flip up the switch cover to lock into place

A — PROFILE SWITCH HOTKEY

B — BRIGHTNESS HOTKEY

C — WINDOWS LOCK HOTKEY

D — MACRO RECORDINDICATOR

E — VOLUME MUTE INDICATOR

F — WIN LOCK INDICATOR

G — NUM LOCK INDICATOR

H — CAPS LOCK INDICATOR

I — SCROLL LOCK INDICATOR

J — VOLUME MUTE HOTKEY

K — VOLUME ROLLER

L — MEDIA CONTROL HOTKEYS

M — USB TYPE-C PORT

N — TOURNAMENTSWITCH

O — TOURNAMENTMODEINDICATOR

P — DETACHABLEUSBTYPE-C

TOA CABLE

Q — DETACHABLEMAGNETIC

PALM REST

With iCUE you can change the color of the RGB LED’s while in tournament mode.

SHORTCUTLIGHTING EFFECT

FN + 1

Spiral Rainbow

FN + 2

Rain

FN + 3

Rainbow Wave

FN + 4

Visor

FN + 5

Type Lighting (Per-key)

FN + 6

Type Lighting (Ripple)

FN + 7

Color Shift

FN + 8

Color Pulse

FN + 9

Color Wave

FN + 0

Static Color

(Press to cycle colors)

SHORTCUTFUNCTION

FN + `

Reset to Onboard

Stored Effect

FN + -

Reduce Effect Speed*

FN + =

Increase Effect Speed*

FN + [

Rotate Effect Left*

FN + ]

Rotate Effect Right*

*Functions supported on select effects.

(2 SECONDS)

HOLD

(2 SECONDS)

PULSES

WHITE

PRESS

RAPIDLYBLINKSWHITE

PRESSKEY

ORFN + KEY

COMBINATION

TOSAVE

HOLD

TO CANCEL

(2 SECONDS)

ENGLISHEN

FRANÇAIS (CAN)CF

DEUTSCHDE

NEDERLANDSNL

PУССКИЙRU

ﺔﻴﺑﺮﻌﻟا

AR

ITALIANOIT

ESPAÑOL (LATIN AMERICA)LA

PORTUGUÊS (BRAZIL)BP

DANSKDA

FRANÇAIS (EURO)FR

POLSKIPL

繁體中文

TC

日本語

JA

한국어

KO

SUOMIFI

SVENSKASV

NORSKNO

ESPAÑOL (EURO)ES

PORTUGUÊS (EURO)PT

K70

K70 RGB PRO Mechanical Gaming Keyboard

K70 PRO RGB Optical-Mechanical Gaming Keyboard
