Seite 1/69
2 Mega Pixel Network
Indoor Dome Camera
CDIH109
101 Wrangler, Suite 201 • Coppell, Texas 75019 • Phone: 469-635-6800 • Fax: 469-635-6822 • Toll Free: 1-888-694-STAR (7827)
www.costarvideo.com
Features:
• 2 mega pixel resolution (1080p)
• 3-9 mm auto iris and vari-focal lens
• 1/2.7” CMOS Progressive Scan image sensor
• True day/night with IR cut filter
• OnVIF supported; iNEX compatible
• Back Light Compensation (BLC)
• 2 Dimensional Noise Reduction (2DNR)
• SD memory card supported
• Multiple compression (H.264, MJPEG, MPEG-4)
• Motion detection
• Dual IP streaming
• Event buffering
• Password protection, IP filtering
• Power over Ethernet (PoE) or DC12V
Description:
The CDIH109 indoor dome camera provides
high quality video with (1080p) 2.0 mega
pixel resolution. The ability to be powered by
PoE simplifies installation. Costar Video’s IP
cameras are compatible with the iNEX user
interface platform. The iNEX user interface
incorporates features such as simplified user
management, advanced camera mapping
and logical camera grouping making it easier
to monitor and access each of your cameras.
The iNEX user interface also has the ability
to integrate both analog
and IP camera
technology on the same platform allowing
you to have a diverse surveillance system.
Costar Video’s IP cameras are OnVIF
supported. The i
ndustry standard OnVIF
protocol makes it easy to integrate Costar
branded IP cameras with OnVIF compatible
recorders.
2
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PROCUCT TO
RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION
GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage" within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
PRECAUTIONS
Safety -------------------------------------- Installation -------------------------------
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel before operating it any further.
Unplug the unit from the wall outlet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the rear
panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or humid
place or in a place subject to excessive dust,
mechanical vibration.
The unit is not designed to be waterproof.
Exposure to rain or water may damage the unit.
Cleaning ---------------------------------
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use strong
solvents such as thinner or benzene as they might
damage the finish of the unit.
Retain the original carton and packing materials for
safe transport of this unit in the future.
