Lies die bedienungsanleitung für Cougar MG120-G RGB (2 Seiten) kostenlos online; sie gehört zur Kategorie Computergehäuse. Dieses Handbuch wurde von 3 Personen als hilfreich bewertet und erhielt im Schnitt 4.8 Sterne aus 2 Bewertungen. Hast du eine Frage zu Cougar MG120-G RGB oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/2
MG120-G RGB sports an elegant and compact design with a darkmirror transparent front panel
with three ARGB VK120 fans and a tempered glass side window, which shows a dazzling and
attractive view of your computer’s internal components. Moreover, it supports three radiators
for optimized cooling performance. This case is designed to allow users to contemplate their
high-end system components and RGB lighting effects they want.
Enjoy the Dazzling RGB Show
The integrated lighting button and ARGB VK120 fans with built-in LED controller, allows MG120-G RGB
to display amazing lighting effects. It’s also adaptable with any compatible motherboards 5V ARGB ’
connection for system-wide lighting synchronization.
Three ARGB VK120 fans included
VK120 fan with Tri-Directional RGB Circle of Light that deliver a powerful and bright RGB lighting effect.
In addition, VK120 equipped premium Hydro-Dynamic-Bearing and PWM function can provide more
durable and silent performance.
Great Support for Components
You won’t believe how powerful a gaming beast you can build inside MG120-G RGB. Its advanced support
for graphics cards (up to two 330 mm-long graphics cards) will allow you to enjoy the latest games with
smooth framerates.
Top-notch Cooling
MG120-G RGB’s compact layout allows you to install six fans and three water cooling radiators, with the
front one up to 280mm. This immense cooling potential will enable you to choose freely the components
you want in your build.
FEATURES
Assembly Drawing
Specifications might vary depending on the country or region of sale.
Power button / RGB button
A
Removable front panel
C
USB3.0 x 1 ,USB2.0 x 1 , Mic x 1, Audio x 1
B
F
Right side panel
Thumb screws
E
D
Tempered glass left panel
Slot covers
G
I
2.5" HDD/SSD trays
H
3.5”HDD trays
(compatible for 2.5”HDD/SSD)
J
Air filter for bottom panel
Air filter for front panel
K
2 x 140 / 3 x 120mm fans for front panel
(ARGB VK120 fans x 2 pre-installed)
M
120mm fan for rear panel
(ARGB VK120 fan x 1 pre-installed)
N
Air filter for top panel
L
2 x 140 / 2 x 120mm fans
for top panel (optional)
O
• Integrated RGB system with 5V ARGB motherboard synchronization
• Support for Micro ATX / Mini ITX Motherboards
• Massive Tempered Glass Side Window
• Up to Two 330 mm Graphics Cards
• Up to Six Fans
• Up to Three Water Cooling Radiators (Up to 280mm)
• Support for Two 3.5" HDDs and Two 2.5" SSDs or Four 2.5" SSDs.
ENGLISH
• Integriertes RGB-System mit 5-V-ARGB-Motherboard-Synchronisierung
• Unterstützt Micro-ATX/Mini-ITX-Motherboards
• Massives Seitenfenster aus gehärtetem Glas
• Bis zu zwei 330-mm-Grafikkarten
• Bis zu sechs Lüfter
• Bis zu drei Wasserkühlungsradiatoren (bis zu 280 mm)
• Unterstützt zwei 3,5 Zoll-Festplatten und zwei 2,5 Zoll-SSDs oder vier 2,5 Zoll-SSDs
DEUTSCH
• Sistema RGB integrado con sincronización de placa base con 5V ARGB
• Soporte para Motherboards Micro ATX / Mini ITX
• Gran Ventana de Vidrio Templado
• Hasta dos Tarjetas Gráficas de 330 mm
• Hasta seis Ventiladores
• Hasta tres Radiadores de Water Cooling (de hasta 280mm)
• Soporte para dos HDDs de 3.5” y dos SSDs de 2.5” o cuatro SDDs de 2.5”
ESPAÑOL
• Zintegrowany system RGB zsynchronizowany z płytą główną przez złącze ARGB 5 V
• Obsługa płyt głównych Micro ATX / Mini ITX
• Duże boczne okienko ze szkła hartowanego
• Maksymalnie dwie karty graficzne 330 mm
• Maksymalnie 6 wentylatorów
• Maksymalnie 3 radiatory chłodzenia wodnego (do 280 mm)
• Obsługa dwóch dysków twardych 3,5" i dwóch SSD 2,5" albo cztery SSD 2,5".
POLISH
• Integrált RGB-rendszer, 5 V-os ARGB alaplap-szinkronizálással
• Támogatás Micro ATX / Mini ITX alaplapokhoz
• Masszív, edzett üvegből készült oldalsó ablak
• Max. két 330 mm-es grafikus kártya
• Max. hat ventilátor
• Max. három vízhűtő radiátor (fent 280 mm-ig)
• Támogatás két 3,5"-os HDD-hez és két 2,5"-os SSD-hez vagy négy 2,5"-os
SSD-hez
HUNGARIAN
• Sistema RGB integrado com sincronização de placa mãe de 5V ARGB
• Suporte para Placas Mães Micro ATX / Mini ITX
• Janela lateral em vidro temperado massivo
• Até duas Placas de Vídeo de 330 mm
• Até seis Ventoinhas
• Até três Radiadores de Water Cooling (Em cima até 280mm)
• Suporte para dois HDDs de 3.5” e dois SSDs de 2.5” ou quatro SDDs de 2.5”
PORTUGUÊS
РУССКИЙ
• Интегрированная система RGB подсветки с 5V ARGB синхронизацией
материнской платы
• Поддержка материнских плат формата Micro ATX / Mini ITX
• Массивное боковое окно из закаленного стекла
• До двух 330-мм графических карт
• До шести вентиляторов
• До трех водоохлаждающих радиаторов (до 280 мм)
• Поддержка двух 3.5-дюймовых жестких дисков и двух 2.5-дюймовых SSD
накопителей или четыре 2.5-дюймовых SSD накопителей.
• Système RGB intégré avec synchronisation de la carte mère ARGB 5V
• Prise en charge de cartes mères Micro ATX / Mini ITX
• Fenêtre latérale en verre trempé massif
• Jusqu'à deux cartes graphiques 330 mm
• Jusqu'à six ventilateurs
• Jusqu'à trois radiateurs de refroidissement par eau (Haut jusqu'à 280 mm)
• Prise en charge de deux disques durs 3,5" et deux SSD 2,5" ou quatre SSD 2,5".
FRANÇAIS
• Sistema RGB integrato con sincronizzazione della scheda madre ARGB 5 V
• Supporto per schede madri Micro ATX / Mini ITX
• Finestra laterale in vetro temperato massiccio
• Fino a due schede grafiche da 330 mm
• Fino a sei ventole
• Fino a tre radiatori di raffreddamento ad acqua (280 mm)
• Supporto per due HDD da 3,5" e due SSD da 2,5" o quattro SSD da 2,5".
ITALIANO
• RGB 5V ARGB整合系统支援 主机板灯效同步控制功能
• Micro ATX / Mini ITX 支持 主板
• 全景钢化玻璃侧窗
• 2 330 mm 最高可安装 组 显卡
• 6最高支持 个风扇
• 3 ( 280mm )最高可安装 个水冷散热器 支持最大长度 水冷排
• 2 3.5" HDD ( 2 2.5"SSD ) 4 2.5" SSD支持 个 硬盘 可转换为 个 硬盘 与 个 硬盘
中 文
• ARGB 5V RGBシステムは のマザーボードの 効果に同期します
• Micro-ATX Mini-ITXと マザーボードに対応しています。
• PC強化ガラスウィンドウで、 の内部構造が見えます。
• 2 330 mm最大 つの グラフィックカードに対応できます。
• 6最大 個のファンを装着できます。
• 3 280mmつの水冷ラジエーターを装着可能です。（ の水冷ラジエーターを装着可能）
• 2 3.5 HDD( 2 2.5" SSDs) 4 2.5" SSDつの インチの 或いは つの と つの を装着できます。
日本語
•
5V ARGB 마더 보드 동기화 기능이있는 통합 RGB 시스템
•
Micro ATX / Mini ITX 마더보드 지원
•
강화 유리 사이드 윈도우
•
최대 2개의 330 mm 그래픽 카드 장착 가능
•
최대 6개의 팬 설치 가능
•
최대 3개의 수냉식 라디에이터(280mm)
•
3.5" HDD 2개와 2.5" SSD 2개 또는 2.5" SSD 4개 지원
한국어
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H 000001 означает, что товар был произведен в феврале 2017 года.1702
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,
и означают год,
последующие две цифры – месяц изготовления.
Например, S/N: D REVI000001 означает, что товар был произведен в феврале 2017 года.AG02
●
Например,
AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
123456 8907
A
B
ACCESSORY KIT
GLOBAL WARRANTY POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR MG120-G RGB
Warranty : 1 Year
●
This warranty gives you specific legal rights. You may also have other rights granted under local law. These rights may vary.
●
Only for electrical components.
X 5Power supply screws
X 25Motherboard/SSD screws
X 4Stand-off
X 5Cable ties
Installing the Front I/O Connectors
POWER SW
POWER SW
HD AUDIO
HD AUDIO
USB
USB 2.0
USB3.0
USB 3.0
POWER LED
POWER LED +
POWER LED -
MG120
-
G
RGB
RGB Sync with M/B
Max. Graphics Card Length
Max. CPU Cooler Height
Max. PSU length
Case Form Factor
Dimension
Motherboard Type
I/O Panel
Case Drive Bays
Expansion Slots
Model No.
Model Name
Cooling Fan Support
Water Cooling Radiator Support
Maximum Number of Fans
Rear : 120mm
4mm Tempered Glass
Yes
Yes
330 (mm) / 12.99 (in)
175 (mm) / 6.89 (in)
160 (mm) / 6.3 (in)
MG120-G RGB
CGR-5TMZB-G-RGB
Mini Tower
210 (W) x 415 (H) x 400 (D) mm / 8.27 (W) x 16.34 (H) x 15.75 (D) inch
4
Mini ITX / Micro ATX
USB3.0 x 1 , USB2.0 x 1 , Mic x 1 , Audio x 1 , RGB Button
3.5" : 2
2.5" : 2+2 (converted from 3.5" drive bays) / (2 SSD trays included)
Top : 120mm x 2 / 140mm x 2
Front : 120mm x 3 / 140mm x 2 (ARGB VK120 fans x 2 pre-installed)
Top : 240mm / 140mm / 120mm
( Max. Component Height on Motherboard is 40mm )
Front : 280mm / 240mm / 140mm / 120mm
6 Max.
Rear : 120mm x 1 (ARGB VK120 fan x 1 pre-installed)
Transparent Left Panel
Onboard Lighting System
Removing the side panels Installing 2.5" HDDs/SSDs Installing 3.5" HDDs
Install with trays
(There are two SSD trays in this case. Please select two locations you prefer to install.)
*Note: Please lay the case down flat when you remove or install the tempered glass panel.
Installing water cooling radiators & cooling fans
120140240
280
120
120
120
140
120
140
240
120
140
*
(Top)
*
( Max. Component Height on Motherboard is 40mm )
1
(Front)
2
(Rear)
3
Up to two 330mm graphics cards
Controlling lighting modes Installing PCI-E cards
For more information, please visit
Compucase Enterprise Co.,Ltd.
All rights reserved.
www . cou g arg ami n g.c om
Made in China
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:+886-6-356-0606
Service E-Mail:service@cougargaming.com
COUGAR USA Technical Service
Tel: (833) 256-3778
Mail: rma@compucaseusa.com
https://cougargaming.com/support/contact/upload/
*Note:
Please remove the USB bezel before you
install the toppest fan at the front panel.
LEFT
LEFT
RIGHT RIGHT
PUSH & HOLD the Bar
Lift up with 45° Angle
to Remove it.
Connectors
Connectors
RIGHT RIGHT
5V Addressable
RGB Connector - 6
5V Addressable
RGB Connector - 1
RGB SW Button
.LED
5V Addressable
RGB Connector - 2
5V Addressable
RGB Connector - 3
5V Addressable
RGB Connector - 5
5V Addressable
RGB Connector - 4
(Please don't remove the
SATA connector from the PSU)
First Mode: Several Lighting Effects
You can use the front panel’s RGB SW button to switch various beautiful lighting effects we have preset for you.
Second Mode: Motherboard Synchronization
Please use the included adapter to connect to a compatible motherboard’s 3-pin 5V Addressable RGB header.
Then, press and hold the RGB SW button for 3 seconds.
※
If y o u press a n d hold th e RGB SW bu t t on for 3 s e cond aga i n .
It will be returned to the First mode: Several Lighting Effects.
First Mode: Several Lighting Effects
Second Mode: Motherboard Synchronization
Press and hold the RGB button for 3 seconds Press and hold the RGB button for 3 seconds
Power suppy
Power Connector5V Addressable RGB Adapter
1
2
