Dual VESA Security Enclosure Desk Mount

w/ Storage Compartment (Black / White)

PAD-2VDMB/ PAD-2VDMW

INSTRUCTION - MANUAL

CONTENTS:

INSTALLATION:

888-733-4448

1. Mounting Setup

x1

M5 Allen Key

M5 x 8

M5 Nut

M5 x 12

A

B

(x4)

(x4)

M6 Allen key

(x4)

x4

C

D

E

F G

x8

x8

x4

x1

x1

1A. When mounting into a surface for a desk

mount mode, use (4) screws and (4) anchors as

illustrated (B) and rotate through desk mount (A).

Using a screwdriver (not provided), rotate in until

securely tightened as shown above.

1B. When mounting into CTA Digital’s

ADD-PARAFS2 stands, first open the back

door to the storage area. Then use the

provided allen key tool (I) and rotate in

screws (H) on top of the washers (J) as

shown until securely fastened. Shut door

and lock with key. (G)

M6 x 16

x4

x4

H

J

**Screw Driver is for

illustration purposes and

not included

B

M6 Allen Key

I

x1

I

H

M6 x 16

J

A

**Floor Stand is for

illustration purposes and

not included

A

Mounting to Direct Surface

Mounting to Another

Vesa Compatible Item

OR

x2

x2

Foam Adapter &

Sheet Bundle

**Tablet shown for

illustration and

NOT INCLUDED.

K

L
