Service Manual – Digital InterLock Coffee Grinders

For the Latest speciFications and inFormation go to www.wiLburcurtis.com

This appliance is designed for commercial use. Any servicing other than cleaning and maintenance should be performed by an autho-

rized Wilbur Curtis service center.

•DoNOTimmersetheunitinwateroranyotherliquid

•Toreducetheriskofreorelectricshock,doNOTopentoppanel.Nouserserviceablepartsinside.Repairshouldbedone

only by authorized service personnel.

•Keephandsandotheritemsawayfromhotpartsofunitduringoperation.

•Nevercleanwithscouringpowdersorharshimplements.

Important Safeguards/Conventions

Conventions

WARNINGS–TohelpavoidpersonalinjuryImportantNotes/Cautions–fromthefactory

QUICKSTART&SETUP

SETUP

1.Installthegrinderonarm,levelbaseinalocationwhereitcanbeconnectedtoagroundedelectricaloutletof120VAC,ratedat15

amps.

2.Testtheunitbyrunningsomewholebeancoffeethroughthegrinder.Ifanyproblemsareencountered,refertothetroubleshooting

sectioncompleteatwww.wilburcurtis.comorcallTechnicalSupportat800-995-0417.

CONNECTINGTHEINTERLOCKGRINDER

1.TurnbothunitsOFF.

2.PlacethegrindercloseenoughtothebrewersoittheInterLockcablewillreachthebrewer.

3.Locatethejack,labeledCLASS2WIRINGONLY,onthebackofthebrewer.PlugintheInterLockcabelfromthegrinder.

4.TurnbothunitsON.Interlockingiscomplete.

INTERLOCKOPERATINGINSTRUCTIONS

1.Openthedoorontopofthegrinderandllwithfreshwholebeancoffee.Closethetopdoor.

2.PlaceanemptySatelliteonthewarmerdeckofthebrewerandpreheatitbyswitchingonwarmer.

3.Placeanewpaperlterintothebrewcone.

4.Insertthebrewconeintothebasketholderarmsonthegrinder.

5.Presstheappropriategrindswitch(SMALL,MEDIUMorLARGE).

6.Allowthegrindmotortocompletelystopbeforeremovingthebrewcone.Thebrew

selectionisnow“Locked”inatthebrewerandisindicatedbytheashinglightonthe

InterLockbrewer.

7.Transferthelledbrewconetothebrewerandpresstheashingbrewbutton.

Brewcycleiscompletewhenthebrewlightstopsashing.

ADJUSTINGTHEGRINDS

1.Emptyhopperofcoffeebeans.Rungrindertocleargrindingburrsofcoffee.

2.Openhousingcovertolocateadjustmentscrew(8)andlocknut(7).Loosenlocknut.

3.Runmotorduringadjustment.Turningadjustmentscrewclockwisewillresultinaner

grind(if,whileturning,youhearthegrindingburrsstartingtotouch,immediately,back

off1/8thturn).Turningcounterclockwisewillproduceacoarsergrind.

4.Withascrewdriverholdingtheadjustmentscrewinplace,tightenthelocknut.

5.Runsomecoffeebeansthroughthemachinetocheckthegrindadjustment.

6.Replacefrontcoveronmachine.

*Thisadjustmentmaychangetheamountofgroundcoffeedispensed.

CHANGINGABROKENSHEARDISK

1.Unplugthepowercord.

2.Emptythehopperofbeans.

3.Takeoutthethumbscrews(10)toremovethegrindcap(6).

4.Pulloutthegrindingburr/feedwormassembly(2).Theinnerhalfofthegrindingburrset

willremaininthehousing.

5.Separatetheshearcap(5)andsheardrive(3).Thesnappedsheardisk(4)shouldfall

out of it’s slot on the shear drive.

6.Inspectandcleanhousing(1)ofanycoffeeordebris.Especiallylookforanythingthatmayhavebrokenthesheardisk.

7.Re-insertthefeedwormandgrindingburrontothemotorshaft.

8.Pushsheardrivethroughburr/feedwormassemblyandalignlargeslotwithtongueonthemotorshaft.

9.Rotateburr/feedwormassemblytoalignslotwithnarrowslotonsheardrive.

10.Insertanewsheardiskintoslot.Coverwiththeshearcap.

11.Replacegrindcapandthumbscrews.
