us.dahuasecurity.com Intelligent Solutions for a Safer World

Dahua panoramic cameras provide 180° or 360° views that provide wide-area video surveillance for increased situational

awareness. Fisheye and Multi-sensor cameras replace multiple single-sensor cameras providing easier installation and a higher

return on investment. This Quick Guide presents the specications for all components necessary to create your own network

panoramic surveillance system from Dahua.

2x2MP Dual Sensor Congurations Fisheye

Stairwell Conguration Hallway Conguration Single Sensor 360 0

8x2MP Multi-sensor 4x2MP Multi-sensor Dome 4x2MP Multi-sensor Bullet

3600 Stitched 1800 Stitched 1800 Stitched

Unstitched Multi-ex Congurations

180º View 270º View 360º View

Position all four sensors toward the front

of the track for a 180º overview. Best when

required to mount where a lens may be

obstructed.

Position three of the sensors toward the front

of the track and one to the back for a 270º

overview. Best when required to mount where

a lens may be obstructed.

Position sensors evenly around track for

a full 360º overview. Best for applications

that will be mounted in an open area without

obstruction.

The IR LEDS and lenses are xed to the same bracket, so when the lenses move so do the LEDs.

IP PANORAMIC

SOLUTION QUICK GUIDE

Go from this: To this:

· Quicker installation

· Fewer cameras and cable

· One VMS license

· Lower total cost of ownership

us.dahuasecurity.com Intelligent Solutions for a Safer World

DH-IPC-PDBW8840N-A180 DH-PSDW81642M-A360 DH-IPC-PDBW5831N-B360 DH-IPC-PDBW82041N-B360

2MP IR 180° Panoramic Dome 8 x 2MP Panoramic + 4MP PTZ Multi-Flex Quad-sensor Dome Camera Multi-Flex Quad-sensor Dome Camera

UltraSeries

• Four (4) 1/2.8-in. CMOS Sensors

• 4096 x 1800 at 30 fps

• 180° Panoramic View

• 2.8 mm Lenses

• Starlight+ Technology

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+,

H.264, MJPEG

• Digital Wide Dynamic Range

• Max IR Distance 30 m (98 ft)

• Analytics+: (Vehicle Density, Crowd Den-

sity) IVS (Tripwire, Intrusion)

• IP67 and IK10

• Best for wide area surveillance

UltraSeries

• Panoramic Camera: Eight (8) 1/1.8-in.

2MP CMOS Sensors with Eight (8) 5 mm

Lenses for a 360° Panoramic View

• PTZ Camera: One (1) 1/1.8-in 4MP

CMOS Sensor with One (1) 5.6 mm to

223 mm Lens

• 8192 x 1800 at 30 fps (Panoramic) plus

2560 x 1440 at 30 fps (PTZ)

• Starlight Technology 0.008 lux Color

• Triple-stream Encoding

• Max IR Distance 400 m (1312.34 ft)

PTZ with Zoom Priority for Optimal IR

Coverage at Any Zoom Level

• Intelligent Video System (IVS) with Smart

Track, Crowd and Vehicle Density

• IP66

• Best for wide area surveillance

UltraSeries

• Four (4) 1/2.8-in. 2MP STARVIS™

CMOS Sensors

• Four (4) 2.7 mm to 12 mm Motorized

Zoom Lenses

• Dual-stream Encoding, per sensor

• 1920 x 1080 at 30 fps per Sensor

• Ultra-wide Dynamic Range (140 dB,

channel 1 only)

• Intelligent Video System: Motion, Trip-

wire, Intrusion,Scene Change, Aban-

doned/Missing Object

• Sensors Independently Positionable and

Configurable

• Enhanced Starlight Technology 0.005

lux Color

• Smart H.265+, H.265, Smart H.264+,

H.264, H.264B, H.264H, MJPEG (sub

stream)

• Max IR Distance 30 m (98 ft)

• IP67 and IK10

• Best for medium to large intersecting

areas for wide coverage

UltraSeries

• Four (4) 1/2.7-in. 5MP CMOS Sensors

• Four (4) 2.8 mm to 12 mm Motorized

Zoom Lenses

• Triple-stream Encoding per sensor

• FlexStream Consolidates Video from All

Channels into a Single Stream

• 2592(H) x 1944(V), per Sensor

• Wide Dynamic Range on all Channels

• Intelligent Video System: Abandoned/

Missing Object

• Analytics+: Perimeter Protection, Face

Detection

• Sensors Independently Positionable and

Configurable

• Enhanced Starlight Technology 0.005

lux Color

• Smart H.265+, H.265, Smart H.264+,

H.264, H.264B, H.264H, MJPEG (sub

stream)

• Max IR Distance 30 m (98 ft)

• IP67 and IK10

• Best for medium to large intersecting

areas for wide coverage

DH-IPC-EBW81242N N68BR4V N55CS5

12MP 360° IR Fisheye 6MP 360° IR Fisheye 5MP 360° Panoramic Fisheye

UltraSeries

• 1/1.7-in. STARVIS™ CMOS

• 12MP at 30 fps

• 1.98 mm Fixed Lens

• Multiple Dewarping Modes

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264

• Built-in Microphone

• Digital Wide Dynamic Range

• Max IR Distance 10 m (33 ft)

• Analytics+ (People Counting, Queue Managment) IVS

• IP67 and IK10

• Best for lowlight small applications where high resolu-

tion details are required

UltraSeries

• 1/1.8-in. STARVIS™ CMOS

• 6MP at 30 fps

• 1.3 mm Fixed Lens

• 0.005 lux Color

• Multiple Dewarping Modes

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264

• Digital Wide Dynamic Range

• Max IR Distance 10 m (33 ft)

• IVS: Motion, Tripwire, Intrusion, Scene Change, Abandoned/

Missing Object, Heat Map

• IP67 and IK10

• Best for lowlight small applications that require tight

intergration with numerous VMS platforms

ProSeries

• 1/2.7-in. CMOS

• 5MP at 30 fps

• 1.4 mm Fixed Lens

• Built-in Microphone

• Multiple Dewarping Modes

• Smart H.265+, H.265, Smart H.264+, H.264

• True Wide Dynamic Range (120 dB)

• Analytics+ (People Counting) IVS (Tripwire, Intrusion,

Abandoned/Missing Object, Heatmap)

• IP67

• Best for well lit small applications

N55CT5 DH-IPC-HDBW4231FN-E2-M DH-IPC-PFW8840N-A180

5MP 360° Panoramic Fisheye 2 x 2MP IR Dual-sensor Dome Camera 2MP IR 180° Panoramic Bullet

ProSeries

• 1/2.7-in. 5MP STARVIS™ CMOS

• 5MP at 30 fps

• 1.4 mm Fixed Lens

• Built-in Microphone

• Multiple Dewarping Modes

• Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264

• True Wide Dynamic Range (120 dB)

• Maximum IR Distance 10 m (33 ft)

• Analytics+ (People Counting) IVS (Tripwire, Intrusion,

Abandoned/Missing Object, Heat Map)

• Best for indoor lowlight small applications

ProSeries

• Two (2) Independent 1/2.8-in. STARVIS™ CMOS

• 2MP at 30 fps

• 2.8 mm Lenses

• Basic Starlight Technology 0.009 lux Color

• Dual-stream Encoding per Sensor

• H.265, H.264, MJPEG (Sub stream only)

• True Wide Dynamic Range (120 dB)

• Max IR Distance 20 m (66 ft)

• Intelligent Video System: Motion, Tripwire, Intrusion, Scene

Change, Abandoned/Missing Object, Facial Detection

• IP67 and IK10

• Best for Hallways and corridors

UltraSeries

• Four (4) 1/2.8-in. CMOS Sensors

• 4096 x 1800 at 30 fps

• 2.8 mm Lenses

• Starlight+ Technology

• Analytics+: (Vehicle Density, Crowd Density) IVS

(Tripwire, Intrusion) Triple-stream Encoding

• Smart H.265+, H.265, Smart H.264+, H.264, MJPEG

• Digital Wide Dynamic Range

• Max IR Distance 30 m (98 ft)

• IP67 and IK10

• Best for wide area surveillance

IP Panoramic Cameras

us.dahuasecurity.com Intelligent Solutions for a Safer World

DISPLAY NETWORK VIDEO RECORDERS

DHI-LM32-F200 DHI-NVR5216-16P-I 4TB N54B3P N54A4P

31.5-in. Full HD LED Monitor 16CH ePoE NVR 16CH 4K ePoE NVR 24CH 4K PoE NVR

• 31.5’’ Full HD 1920*1080 Resolution

LED Monitor

• • Plastic Housing

• • Input: VGAx1, HDMIx1

• • Output: Speakers x2

UltraSeries

• Analytics+ NVR, 320Mbps

• 160Mbps when Analytics+ function is

enabled, (16 channel IP Video Inputs)

• 16 Ports PoE, 8 ports ePoE

• 16CH IP cameras: 2CH @12MP, 4CH @

8MP and 16CH @ 2MP

• Includes perimeter protection, Analytics+

search and license plate recognition with

compatible LPR cameras

• 4TB included

ProSeries

• Smart H.265+, Smart H.264+ Decoding

• Maximum 320 Mbps Incoming

Bandwidth

• Up to 12MP Resolution Preview and

Playback

• 4 SATA III Ports, up to 10TB per port

• 16 PoE Ports (8 of which are ePoE Ports)

• 4CH@8MP, 16CH@1080P

• 120 W Total Rated PoE Power, 25.5 W

maximum per port

• IVS Recording on all IP Channels

ProSeries

• Smart H.265+, Smart H.264+ Decoding

• Maximum 320 Mbps Incoming

Bandwidth

• Up to 12MP Resolution Preview and

Playback

• Supports IPC UPnP

• 24 PoE/PoE+ Ports

• HDMI/VGA Simultaneous Video Output

• 220 W Total Rated PoE Power, 25.5 W

maximum per port

• 3D Intelligent Positioning (Dahua

cameras)

• IVS Recording on all IP Channels

SWITCHES MANAGEMENT SOFTWARE

DH-PFS3010-8ET-96 DH-PFS4218-16ET-240 SmartPSS DSS

8-port Fast Ethernet PoE Switch 16-port Managed Gigabit Switch Smart Professional Surveillance System Digital Surveillance Management Center

• Layer 2 Commercial Switch

• Long-distance PoE (LD PoE) Transmits

Power and Data 250 m (820 ft)

• Conforms to IEEE802.3, IEEE802.3u and

IEEE802.3X

• Conforms to IEEE802.3af and

EEE803.3at

• Two (2) 10/100/1000 Mbps Uplink Ports

• Supports Hi-PoE (60 W)

• MAC Auto-learning and Aging; 16K MAC

Address Capacity

• MDI/MDIX Self-adaptation

• Metal Enclosure

• Layer 2 Managed PoE Switch

• Supports the IEEE802.3af, IEEE802.3at,

and Hi-PoE Standards

• Two (2) 1000 Base-X (Combo Port)

• Two (2) 10/100/1000 Base-T (Combo

Port)

• 240 W PoE Budget

• 250 m (820 ft ) PoE Transmission

• PoE Management, PoE Setting, Event

Statistics, Green PoE

• Supports Hi-PoE (60 W)

• High Lightning Protection Design

• Non-blocking Video Transmission

• Efficient Device Management

• Manage up to 64 Devices over a

Maximum of 256 Channels

• Supports H.265 and H.264 Dual Video

Compression Codecs

• Live Video Monitoring and Playback

• Configure Video Wall Layout and

Scheme

• Configure NVR Recording

• PTZ Camera Control

• Intelligent Video System (IVS) with

People Counting and Heat Map

• Complete Organization, Device, and

Event Centralized Management

• Manages up to 20,000 channels with

DSS Pro.

• Supports H.265 and H.264 Dual Video

Compression Codecs

• Support for Video Wall Configuration and

Display

• Live Video Monitoring and Playback

• PTZ Camera Control and Smart Track

• Intelligent Video System (IVS) with

Business Analysis

MOBILE APPLICATION STORAGE

DMSS DHI-TF-P100/128GB DHI-TF-P100/256G STx000VX000X

128 GB Micro SD Card 256 GB Micro SD Card Skyhawk Series Hard Drives

• IOS and Android

• Relay Out Functionality

• MJPEG Video Decoding

• Multi-language Interface (Chinese,

Dutch, English, French, German, Italian,

Portuguese, Russian, and Spanish)

• SD Card Slot up to 128 GB

• Cost-effective TLC Storage Medium

• High-transmission Speed of up to 100

MB/s

• Write speed is up to 60 MB/s

• Waterproof, Shockproof, and X-ray Proof

• High and Low Temperature Resistance

• SD Card Slot up to 256 GB

• Cost-effective TLC Storage Medium

• High-transmission Speed of up to 100

MB/s

• Write speed is up to 880 MB/s

• Waterproof, Shockproof, and X-ray Proof

• High and Low Temperature Resistance

• Designed for 24/7 Surveillance-optimized

Applications

• Firmware Optimized for Continuous

Recording; 90% Write and 10% Read

• Engineered for Workloads up to 180 TB/

year

• Capacity Up to 10 TB, Supports 64

Cameras per Drive

• Low Power Consumption and Startup

Current

• Tarnish-resistant Components to

Minimize Environmental Effects

IP Recorders & Accessories

Produktspezifikationen

Marke:	Dahua Technology
Kategorie:	Überwachungskamera
Modell:	DH-IPC-PDBW82041N-B360

Brauchst du Hilfe?

Wenn Sie Hilfe mit Dahua Technology DH-IPC-PDBW82041N-B360 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Überwachungskamera Dahua Technology

Dahua Technology Ultra IPC-HF7842F Bedienungsanleitung

8 Oktober 2024

Dahua Technology Lite IPC-HDW1320S Bedienungsanleitung

4 Oktober 2024

Dahua Technology Ultra IPC-HF7442F-FR Bedienungsanleitung

4 Oktober 2024

Dahua Technology SD49225T-HN-W Bedienungsanleitung

23 September 2024

Dahua Technology DH-HAC-HDW1230T-Z Bedienungsanleitung

22 September 2024

Dahua Technology Pro HAC-HFW2221SP-0280B Bedienungsanleitung

17 September 2024

Dahua Technology SD5A825GA-HNR Bedienungsanleitung

15 September 2024

Dahua Technology SDT5X425-4Z4-QA-2812 Bedienungsanleitung

13 September 2024

Dahua Technology Pro PTZ12240-LR8-N Bedienungsanleitung

11 September 2024

Dahua Technology Pro HAC-HFW2231BP-0360B Bedienungsanleitung

10 September 2024

Bedienungsanleitung Überwachungskamera

Neueste Bedienungsanleitung für -Kategorien-

Trebs CCD-401C Bedienungsanleitung

15 Oktober 2024

D-Link DCS-7510 Bedienungsanleitung

15 Oktober 2024

Foscam FI9900EP Bedienungsanleitung

14 Oktober 2024

Alecto DVC-215IP Bedienungsanleitung

14 Oktober 2024

Hikvision DS-2CD2326G2-IU Bedienungsanleitung

13 Oktober 2024

Hikvision DS-2TD2166-15/V1 Bedienungsanleitung

13 Oktober 2024

Hikvision DS-2DE7A245IX-AE/S1 Bedienungsanleitung

13 Oktober 2024

Hikvision DS-2CD7A26G0-IZ(H)SY Bedienungsanleitung

11 Oktober 2024

Hikvision DS-2CE79DF8T-AZE Bedienungsanleitung

11 Oktober 2024

Hikvision DS-2XM6726G0-I(D)(S)(M)(/ND) Bedienungsanleitung

11 Oktober 2024
