Seite 1/68

User reference guide

Daikin Altherma 3 R MT F+W

ELVH12S18E▲6V▼

ELVH12S23E▲6V▼

ELVH12S18E▲9W▼

ELVH12S23E▲9W▼

ELVX12S18E▲6V▼

ELVX12S23E▲6V▼

ELVX12S18E▲9W▼

ELVX12S23E▲9W▼

ELBH12E▲6V▼

ELBH12E▲9W▼

ELBX12E▲6V▼

ELBX12E▲9W▼

▲= 1, 2, 3, …, 9, A, B, C, …, Z

▼= , , 1, 2, 3, …, 9

Table of contents

User reference guide

ELVH/X12S18+23E + ELBH/X12E

Daikin Altherma 3 R MT F+W

4P708475-1 – 2023.05

Table of contents

1 About this document 4

1.1 Meaning of warnings and symbols................................................................................................................................. 5

2 User safety instructions 7

2.1 General............................................................................................................................................................................ 7

2.2 Instructions for safe operation ....................................................................................................................................... 8

3 About the system 10

3.1 Components in a typical system layout.......................................................................................................................... 10

4 Quick guide 11

4.1 User permission level...................................................................................................................................................... 11

4.2 Space heating/cooling..................................................................................................................................................... 11

4.3 Domestic hot water ........................................................................................................................................................ 15

5 Operation 16

5.1 User interface: Overview ................................................................................................................................................ 16

5.2 Menu structure: Overview user settings........................................................................................................................ 18

5.3 Possible screens: Overview............................................................................................................................................. 19

5.3.1 Home screen................................................................................................................................................... 19

5.3.2 Main menu screen.......................................................................................................................................... 22

5.3.3 Setpoint screen............................................................................................................................................... 23

5.3.4 Detailed screen with values ........................................................................................................................... 24

5.4 Turning operation ON or OFF ......................................................................................................................................... 24

5.4.1 Visual indication.............................................................................................................................................. 24

5.4.2 To turn ON or OFF .......................................................................................................................................... 25

5.5 Reading out information................................................................................................................................................. 25

5.6 Space heating/cooling control........................................................................................................................................ 26

5.6.1 About space heating/cooling control............................................................................................................. 26

5.6.2 Setting the space operation mode................................................................................................................. 26

5.6.3 Determining which temperature control you are using................................................................................ 28

5.6.4 To change the desired room temperature .................................................................................................... 28

5.6.5 To change the desired leaving water temperature ....................................................................................... 29

5.7 Domestic hot water control............................................................................................................................................ 30

5.7.1 About domestic hot water control................................................................................................................. 30

5.7.2 Reheat mode .................................................................................................................................................. 31

5.7.3 Scheduled mode............................................................................................................................................. 32

5.7.4 Scheduled + reheat mode .............................................................................................................................. 32

5.7.5 To change the domestic hot water temperature .......................................................................................... 33

5.7.6 Using DHW powerful operation..................................................................................................................... 33

5.8 Preset values and schedules........................................................................................................................................... 34

5.8.1 Using preset values......................................................................................................................................... 34

5.8.2 Using and programming schedules................................................................................................................ 35

5.8.3 Schedule screen: Example.............................................................................................................................. 38

5.8.4 Setting the energy prices................................................................................................................................ 42

5.9 Weather-dependent curve ............................................................................................................................................. 44

5.9.1 What is a weather-dependent curve? ........................................................................................................... 44

5.9.2 2-points curve................................................................................................................................................. 45

5.9.3 Slope-offset curve........................................................................................................................................... 46

5.9.4 Using weather-dependent curves.................................................................................................................. 47

5.10 Other functionalities....................................................................................................................................................... 49

5.10.1 To configure time and date ............................................................................................................................ 49

5.10.2 Using quiet mode ........................................................................................................................................... 50

5.10.3 Using holiday mode ........................................................................................................................................ 50

5.10.4 Using WLAN .................................................................................................................................................... 51

6 Energy saving tips 54

7 Maintenance and service 55

7.1 Overview: Maintenance and service .............................................................................................................................. 55

8 Troubleshooting 57

8.1 To display the help text in case of a malfunction........................................................................................................... 57

8.2 To check the malfunction history ................................................................................................................................... 57

8.3 Symptom: You are feeling too cold (hot) in your living room........................................................................................ 58

8.4 Symptom: The water at the tap is too cold.................................................................................................................... 58

8.5 Symptom: Heat pump failure ......................................................................................................................................... 59
