Seite 1/160
OPERATION MANUAL
Operation manual
Packaged water-cooled water chillers
English
Bedienungsanleitung
Kompakte wassergekühlte Kaltwassererzeuger
Deutsch
Manuel d'utilisation
Groupes d'eau glacée refroidis par eau
Français
Gebruiksaanwijzing
Watergekoelde ijswaterkoelgroepen
Nederlands
Manual de funcionamiento
Enfriadores de agua empaquetados
Español
Manuale d'uso
Refrigeratori d'acqua monoblocco con raffreddamento ad acqua
Italiano
∂Á¯ÂÈÚ›‰ÈÔ ÏÂÈÙÔ˘ÚÁ›·˜
™˘ÁÎÚÔÙ‹Ì·Ù· ˘‰Úfi„˘ÎÙˆÓ „˘ÎÙÒÓ ÓÂÚÔ‡
EÏÏËÓÈο
Manual de operação
Refrigeradores de água arrefecidos a água
Portugues
Инструкция по эксплуатации
Моноблочные чиллеры с водяным охлаждением
русский
EWWQ014KBW1N
EWWQ025KBW1N
EWWQ033KBW1N
EWWQ049KBW1N
EWWQ064KBW1N
Packaged water-cooled water chillers
Operation manual
1
EWWQ014~064KBW1N
Packaged water-cooled water chillers
D-EOMHP00908-17EU
CONTENTS Page
Introduction ....................................................................................... 1
Technical specifications ............................................................................. 1
Electrical specifications ............................................................................. 2
Description ........................................................................................ 2
Function of the main components.............................................................. 3
Safety devices............................................................................................ 3
Internal wiring - Parts table........................................................................ 4
Before operation................................................................................ 5
Checks before initial start-up ..................................................................... 5
Water supply.............................................................................................. 5
General recommendations ........................................................................ 5
Operation .......................................................................................... 5
Digital controller......................................................................................... 5
Working with the units................................................................................ 6
Advanced features of the digital controller................................................. 9
BMS connection modbus ................................................................ 12
General description of Modbus................................................................ 12
Implemented error code........................................................................... 13
Defining the BMS setting......................................................................... 13
Variables database .................................................................................. 13
Troubleshooting............................................................................... 14
Maintenance.................................................................................... 15
Important information regarding the refrigerant used .............................. 15
Maintenance activities ............................................................................. 15
Disposal requirements............................................................................. 15
Menu overview................................................................................ 16
The English text is the original instruction. Other languages are
translations of the original instructions.
This appliance is not intended for use by persons, including children,
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
INTRODUCTION
This operation manual concerns packaged water-cooled water
chillers of the Daikin EWWQ-KB series. These units are provided for
indoor installation and used for cooling and/or heating applications.
The units can be combined with Daikin fan coil units or air handling
units for air conditioning purposes. They can also be used for
supplying water for process cooling.
This manual has been prepared to ensure adequate operation and
maintenance of the unit. It will tell you how to use the unit properly
and will provide help if problems occur. The unit is equipped with
safety devices, but they will not necessarily prevent all problems
caused by improper operation or inadequate maintenance.
In case of persisting problems contact your local Daikin Dealer.
Technical specifications
(1)
EWWQ014KBW1N EWWQ064KBW1N
EWWQ025KBW1N
EWWQ033KBW1N
EWWQ049KBW1N
Packaged water-cooled water chillers
Operation manual
READ THIS MANUAL ATTENTIVELY BEFORE STARTING
UP THE UNIT. DO NOT THROW THIS MANUAL AWAY.
KEEP IT IN YOUR FILES FOR FUTURE REFERENCE.
Read the chapter "Operation" on page 5 before changing
the parameters.
Before starting up the unit for the first time, make sure that
it has been properly installed. It is therefore necessary to
carefully read the installation manual supplied with the unit
and the recommendations listed in "Before starting".
(1) Refer to the engineering data book for the complete list of specifications.
General EWWQ 014 025 033
Dimensions HxWxD
(mm)
600x600x600
Machine weight
(kg)
120 170 175
Connections
•water inlet G 1
•water outlet G 1
General EWWQ 049 064
Dimensions HxWxD
(mm)
600x600x1200
Machine weight
(kg)
310 340
Connections
•water inlet G 1-1/2
•water outlet G 1-1/2
Compressor 014 025 033
Model
JT140L-P8Y1
JT236DJ-Y1 JT315DJ-Y1
Speed
(rpm)
2900
Oil type FVC68D
Oil charge volume
(l)
1.5 3.0 3.0
Refrigerant type R410A
Refrigerant charge
(kg)
1.2 2.1 3.1
Evaporator 014 025 033
Type brased plate heat exchanger
Min. water volume
(l)
62 103 155
Water flow range
(l/min)
31~75 53~123 76~186
Condenser 014 025 033
Type brased plate heat exchanger
Water flow range
(l/min)
24~95 39~157 59~237
Compressor 049 064
Model 2x
JT236DJ-Y1
2x
JT315DJ-Y1
Speed
(rpm)
2900
Oil type FVC68D
Oil charge volume
(l)
2x 3.0 2x 3.0
Refrigerant type R410A
Refrigerant charge
(kg)
4.6 5.6
Evaporator 049 064
Type brased plate heat exchanger
Min. water volume
(l)
205 311
Water flow range
(l/min)
101~247 152~373
Condenser 049 064
Type brased plate heat exchanger
Water flow range
(l/min)
79~314 118~474
