The Danfoss DP720 Series is an element of the PLUS
+1
®
family of mobile machine management products.
The DP720 is designed to perform in the most
extreme mobile machine environments.
The DP720 offers different display options to meet
your application needs. The display is equipped with
a Projective Capacitive touch screen that works
through mud, water and with gloves on.
The latest technology with backlight provides
outstanding brightness and contrast performance
resulting in an easy-to-read screen. Optically Bonded
LCD/Lens Technology improves sunlight view-ability
and prevents fogging.
Develop your own software and layout with PLUS+1
®
GUIDE. A graphic library is available for fast time-to-
market.
Features
•
7” High resolution TFT display 800 x 480
pixels, 18-bit colour
•
Ideal for gauges, diagnostic menus, and
other ancillary functions
•
User-programmable with PLUS+1
®
GUIDE (Graphical User Integrated
Development Environment)
•
Optically bonded LCD
•
Projective Capacitive Touch screen
•
Two optional video inputs with both
PAL and NTSC support
•
Two multifunction inputs that include
DIN/ AIN/FreqIN/Rheo/4-20 mA
•
Fully integrated connectors and silicone
keypad provide water and dust
protection from all sides
•
Keypad with 14 buttons (8 soft-keys and
6 buttons for navigation)
•
All buttons have white backlight design
for low light and night use, all are
individually software controlled
•
Protective glass provides superior
antiglare and contrast control under all
light conditions
•
Two mounting options:
‒
Flush mount in dashboard
‒
Stand-alone post mount according
to VESA standard: 75 mm x 75 mm
(2.953 in x 2.953 in)
•
Can be mounted in Portrait or
Landscape orientation
•
Software configurable LED light bar
•
USB port for fast software downloads
and uploads
•
Integrated light sensor for automatic
backlight adjustment
•
LCD brightness >800 cd/m
2
•
Digital output for external alarm buzzer
•
CE compliant
•
On board real-time clock
Comprehensive technical literature is
online at www.danfoss.com
Data Sheet
DP720 Series
PLUS+1
®
Mobile Machine Displays
©
Danfoss | August 2020AI152986480991en-000607 | 1
