Dell™PowerConnect™2216/2224/2324SwitchesUser'sGuide
Introduction
Troubleshooting
Getting Help
Notes, Notices, and Cautions
Information in this document is subject to change without notice.
©2004DellInc.Allrightsreserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, OptiPlex, Latitude, PowerEdge, PowerVault, PowerApp, Axim, DellNet, and PowerConnect are
trademarks of Dell Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any
proprietary interest in trademarks and trade names other than its own.
Models PowerConnect 2216, PowerConnect 2224, PowerConnect 2324
January2004Rev.A00
NOTE: A NOTE indicates important information that helps you make better use of your system.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
Back to Contents Page
Introduction
Dell™PowerConnect™2216/2224/2324SwitchesUser'sGuide
Package Contents
Front Panel Indicators
Connecting Devices
Typical Deployments
Class-of-Service
Mounting Kit Instructions
Technical Information
Dell™PowerConnect™switchesprovide10/100-Mbps Gigabit or 10/100/1000-Mbps Gigabit Ethernet connectivity. The switches have the following features:
lSwitch ports
¡PowerConnect2216— -16 ports, 10/100 Mbps Gigabit
¡PowerConnect2224— -24 ports, 10/100 Mbps Gigabit
¡PowerConnect2324— -24 ports, plus two additional RJ 45 Gigabit Ethernet ports, 10/100/1000-Mbps Gigabit.
lComplies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX,IEEE802.3z/ab1000Base-T
lTag-based IEEE 802.1p Class-of-Service with two priority queues per port
lIEEE 802.3x PAUSE frames flow control in full-duplex operation
lAutomatic negotiation for speed and full- and half-duplex mode on all ports
lBackpressure flow control in half-duplex operation
lCollision detection on all ports
lAuto MDI/MDIX
l8K MAC address entries supported
lComprehensive LED indicator panel to monitor overall switching condition
l19-inch rackmountable and wallmountable, standard 1U chassis
lInternal power supply
Package Contents
Beforeyouinstallaswitch,verifythatyourpackagecontainsthefollowingitems:
lSwitch
lSelf-adhesive rubber pads for desktop installation
lKit for 19-inch rack installation
lKit for wallmount installation of 16- and 24-port switches
lPowerConnect 2216/2224/2324 Switches CD
lAC power cord
Front Panel Indicators
Your PowerConnect switch contains two rows of LEDS that provide information about connection speed, data activity, and duplex operation mode.
Power (POWER) LED
l —Green The switch is powered on.
l —Off The switch is off.
10/100 Ports Link/Activity (SPD/LNK/ACT) LED
l — Steady green A 100-Mbps link has been established, but no data is being transmitted or received.
l —Blinking green -A 100 Mbps link has been established and data is being transmitted or received.
l —Steady amber -A 10 Mbps link has been established, but no data is being transmitted or received.
l —Blinking amber -A 10 Mbps link has been established and data is being transmitted or received.
l — Off No link has been established.
10/100/1000 Ports Link/Activity (SPD/LNK/ACT) LED (2324 only)
l — Steady green A 1000-Mbps link has been established, but no data is being transmitted or received.
l —Blinking green -A 1000 Mbps link has been established and data is being transmitted or received.
l —Steady amber -A 10 Mbps or 100-Mbps link has been established, but no data is being transmitted or received.
l —Blinking amber -A 10 Mbps or 100-Mbps link has been established and data is being transmitted or received.
l — Off No link has been established.
Duplex Mode/Collisions (FDX/HDX) LED
l —Steady green The port is operating in full-duplex mode.
l —Blinking green Collisions are occurring on the port.
l — Off -The port is operating in half duplex mode.
Figure 1- 1. PowerConnect 2216
Figure 1- 2. PowerConnect 2224
