Use the instructions in this quick start to help you connect the Dell PowerConnect
J-Series J-SRX240 Services Gateway to your network. For details, see the J-SRX240
Services Gateway Hardware Guide at http://support.dell.com/manuals. (Regulatory
model number SRX240)
J-SRX240 Services Gateway (J-SRX240B, J-SRX240H) Front Panel
J-SRX240 Services Gateway (J-SRX240B, J-SRX240H, J-SRX240H-POE)
Back Panel
J-SRX240 Services Gateway with Integrated Convergence Services
(J-SRX240H-POE, J-SRX240H-P-MGW) Front Panel
J-SRX240 Services Gateway with Integrated Convergence Services
(J-SRX240H-P-MGW) Back Panel
CalloutDescriptionCalloutDescription
1Mini-PIM slots5Console port
2Power button6Gigabit Ethernet (0/0 to 0/15)
3LEDs (ALARM, POWER,
STATUS, HA, mPIM)
7USB ports
4Reset Config button
CalloutDescription
1Cable tie holder
2Power supply input
3Grounding point
CalloutDescriptionCalloutDescription
1Mini-PIM slots5Console port
2Power button6Gigabit Ethernet (0/0 to 0/15)
3LEDs (ALARM, POWER,
STATUS, HA, mPIM)
7USB ports
4Reset Config button
037518
Dell PowerConnect J-Series J-SRX240 Services Gateway
Quick Start
