USB Type-C™ Docking Station

Product-No:87743

User manual no:87743-a

www.delock.com

User manual

Mode d’emploi

Uživatelská příručka

Manuale utente

Manual de utilizare

Korisnički priručnik

Bedienungsanleitung

Manual del usuario

Instrukcja obsługi

Bruksanvisning

Használati utasítás

Εγχειρίδιο χρήστη

-2-

English

Description

This docking station by Delock can be connected to a mobile device with

a USB-C™ DP Alt Mode or Thunderbolt™ 3 port and provides a variety of

interfaces. One monitor can be operated at the HDMI output. Three built-in USB

ports allow the use of peripherals, as well as an SD / micro SD card reader,

complete the features.

USB Power Delivery (USB PD 2.0) support up to 87 watt

The docking station has a USB Type-C™ Power Delivery port to connect the

power supply of the laptop or tablet to charge it. In addition it also supplies the

USB ports with power. The docking station can also be used without a power

supply.

LED illumination

An internal blue LED illumination ensures that the ports can also be found in the

dark.

Small sturdy helper

Due to its small dimensions and its sturdy housing, this Delock docking station is

particularly suitable for travelling. It can simply be packed into the bag together

with the laptop or tablet and used as needed.

Specication

• Connectors:

1 x USB Type-C™ male

1 x USB 3.0 Type-A female

2 x USB 2.0 Type-A female

1 x SD / SDHC / SDXC slot

1 x Micro SD / SDHC / SDXC slot

1 x HDMI-A female

1 x USB Type-C™ female (power supply)

• Resolution up to 3840 x 2160 @ 30 Hz (depending on the system and the

connected hardware)

• Transmission of audio and video signals

• Input power: 1 x USB Type-C™ female max. 87 W

• It can only be used one memory card, not both at the same time

• Metal housing

• LED illumination

• Cable length without connectors: ca. 15 cm

• Dimensions (LxWxH): ca. 109 x 40 x 12 mm

-3-

English

System requirements

• Linux Kernel 4.6 or above

• Mac OS 10.14 or above

• Windows 7/7-64/8.1/8.1-64/10/10-64

• Windows 10 Mobile

• Device with a free USB Type-C™ port and DisplayPort alternate mode or with a

free Thunderbolt™ 3 port

Package content

• USB-C™ docking station

• User manual

Safety instructions

• Protect the product against moisture

• Protect the product against direct sunlight

Operation

1. Connect the USB-C™ cable of the docking station to the computer or mobile

device.

Note: A free USB Type-C™ port with DisplayPort alternate mode or with a

Thunderbolt™ 3 port is required.

2. Connect USB devices to the USB Type-A ports.

3. Connect an HDMI monitor to the docking station.

4. Connect a power supply to the USB Type-C™ charging port, to charge your

laptop or mobile device during operation.

5. Insert an SD card into the card reader.

6. Insert an Micro SD card into the card reader.

Produktspezifikationen

Marke:	DeLOCK
Kategorie:	Nicht kategorisiert
Modell:	87743
Breite:	40 mm
Tiefe:	109 mm
Produktfarbe:	Grau
Höhe:	12 mm
Anzahl USB 2.0 Anschlüsse:	2
Warentarifnummer (HS):	84719000
Menge pro Packung:	1 Stück(e)
Kabellänge:	0.15 m
Betriebsanleitung:	Ja
Verpackungsart:	Box
Gehäusematerial:	Metall
Plug & Play:	Ja
Anzahl HDMI-Anschlüsse:	1
LED-Anzeigen:	Ja
Unterstützt Windows-Betriebssysteme:	Windows 10, Windows 7, Windows 8.1
Unterstützt Mac-Betriebssysteme:	Mac OS X 10.14 Mojave
Netzteiltyp:	USB
Kompatible Speicherkarten:	MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	1
Integrierter Kartenleser:	Ja
Unterstützte Linux-Betriebssysteme:	Ja
Hostschnittstelle:	USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ C:	1
Datenübertragungsrate:	- Mbit/s
USB Power Delivery:	Ja
USB-Stromversorgung bis zu:	87 W
Anzahl Anschlüsse:	5
Hub-Schnittstellen:	HDMI, USB 2.0, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB-Stromversorgung Revision:	2.0
Maximale Auflösung (HDMI):	3840 x 2160 Pixel
Kartenleser-Slot:	2
