Seite 1/3

INTRODUCTION

Thank you for choosing a De’Longhi product.

Please take a few moments to read the instructions to avoid

risks or damage to the appliance.

Symbols used in these instructions

Important warnings are identied by the symbols below.

It is important to respect the warnings.

Failure to respect the warnings could lead to electric shock,

serious injury, burns, re or damage to the appliance.

Danger!

Failure to observe the warning may result in life threatening

injury by electric shock.

Important!

Failure to observe the warning could result in injury or

damage to the appliance.

Danger of burns!!

Failure to observe the warning could result

in burns or scalds.

Please note:

This symbol indicates recommendations and important

information for the user.

IMPORTANT WARNINGS

Safety warnings

Danger!

- Do not use this appliance near showers, baths,

swimming pools, sinks, etc.

- The appliance must not be placed immediately under a

xed power socket.

- In order to avoid a hazard due to inadvertent resetting of

the thermal cutout, this appliance must not be powered

through an external switching device such as a timer, or

connected to a circuit that is regularly switched on and

o by the power provider.

Important!

- The appliance is designed and produced for domestic

use only.

- This appliance can be used by children

aged from 8 years and above and

persons with reduced physical, sensory

or mental capabilities or lack of

experience and knowledge if they have

been given supervision or instruction

concerning use of the appliance in a

safe way and understand the hazards

involved. Children shall not play with

the appliance. Cleaning and user

maintenance shall not be made by

children without supervision.

- Children of less than 3 years should

be kept away unless continuously

supervised.

- Children aged from 3 years and less

than 8 years shall only switch on/

o the appliance provided that it

has been placed or installed in its

intended normal operating position

and they have been given supervision

or instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

Children aged from 3 years and less

than 8 years shall not plug in, regulate

and clean the appliance or perform

user maintenance.

CAUTION — Some parts of this product

can become very hot and cause burns.

Particular attention has to be given

where children and vulnerable people

are present.

- The use of extension leads is not recommended. However

if they cannot be avoided, follow the instructions

Important warnings

Use

accompanying the extension lead and never exceed the

power limit marked on the extension.

- If the power cable is damaged, it must be replaced by

the manufacturer, an authorised service centre or a

qualied electrician in order to eliminate all risk.

- Do not use the appliance in rooms measuring less than 4

m.

- Before putting the appliance away, make sure it is

completely o and unplugged from the mains socket.

Wrap the cable around the base. Do not store in dusty

atmospheres.

Danger of burns!!

- Do not cover the appliance when in operation to avoid

the risk of re.

- Do not use the heater to dry laundry. Never obstruct the

intake and outlet grilles (danger of overheating).

- The heater must be positioned at least 50 cm from

furniture, walls, curtains, or other objects.

- When the appliance is used in the portable conguration,

do not place it near walls, furniture, curtains etc.

Please note:

- Always use the heater in an upright position.

- The heater is tted with a thermal cutout device which

switches the heater o in case of accidental overheating

(eg. obstruction of air intake and outlet grilles, motor

turning slowly or not at all). To reset, unplug the

appliance from the mains socket for a few minutes,

remove the cause of overheating then plug in again.

- Do not rest anything on the appliance.

IMPORTANT: Never under any circumstances cover

the appliance during operation as this would lead

to dangerous overheating of the appliance.

Disposing of the appliance

In compliance with European directive 2002/96/

EC, the appliance must not be disposed of with

household waste, but taken to an authorised

waste separation and recycling centre.

USE

Description

A Indicator light

B Function selector

C Thermostat

D Timer (only on some models)

Electrical connection

- Before plugging into the mains, make sure the voltage

of your mains supply corresponds to the value in Volts

(V) indicated on the appliance and that the socket and

power line are appropriate for the load required.

- THIS APPLIANCE COMPLIES WITH DIRECTIVE 2004/108/

EC ON ELECTROMAGNETIC COMPATIBILITY.

Installation

The appliance may be either portable or wall-mounted (if

supplied with a bracket). To mount on the wall, proceed as

follows:

- Fix the bracket to the wall respecting the minimum

measurements indicated in g. 2.

If the appliance is installed in a room with bath or

shower, respect the "safety distances" shown in g. 1

and always install away from taps, basins, showers, etc.

- Attach the appliance to the top hook of the bracket, then

rotate gently until it hooks to the bottom tooth of the

bracket (g. 3).

- The appliance must not be placed immediately under a

xed power socket.

Please note: if you do not intend to wall mount the

appliance, do not attach the bracket to the unit.

Functioning and use

Models with function selector and thermostat. Make sure the

appliance is o before plugging into the mains.

1. Plug the appliance into the mains. The light comes on.

If your appliance has a timer, see the section "Models

with 24 hour timer". However, to operate the appliance

without programming, place the timer selector in the

"I" position.

2. Turn the thermostat dial to maximum.

3. turn the function selector Summer mode (fan only):

to the position.

4. turn the function selector Low power operation:

to position 1 (in models with two fan speeds, the fan

operates at minimum).

5. turn the function selector Medium power operation:

to position 2 (in models with two fan speeds, the fan

operates at maximum).

6. High power operation: turn the function selector to

position 3 (the fan operates at maximum).

7. turn the function selector to the "0" Switching o:

position.

Please note: In models with two power levels, position

2 corresponds to maximum power.

Setting the thermostat

Position the thermostat lever on maximum "+". When the

room has reached the required temperature, slowly move

the thermostat lever towards the "-" position until you hear

a click and the fan goes o. The thermostat will then keep

room temperature at the selected level automatically.

Frost prevention mode

With the function selector in position 3 and the thermostat

dial in position , the appliance maintains room

temperature at about 5°C, preventing freezing with minimal

energy consumption.

Models with 24 hour timer

After setting the thermostat (see above), proceed as follows:

- turn the timer disk clockwise until the arrow on the

timer lines up with the number corresponding to the s

current time.

- set the times when you want the appliance to operate

by pushing the teeth towards the outside. Each tooth

corresponds to 15 minutes.

- place the selector in the position. The appliance will

now function each day at the times set.

To operate the appliance without the timer programming,

place the selector in the "I" position. To go back to timed

operation, just move the selector to the position.

MAINTENANCE

- Always unplug from the mains socket before cleaning.

- Clean the air intake and outlet grilles regularly.

- Do not use abrasive products or solvents to clean the

appliance.

THE TIMER IS SET FOR THE FOLLOWING

PERIODS OF OPERATION:

FROM 10 12: ONTO

FROM 12 18: OFFTO

FROM 18 20: ONTO

FROM 20 10: OFFTO

ARROW ON CURRENT

TIME 10.00

TEETH IN THE

"ON" POSITION

TEETH IN THE

"ON" POSITION

TEETH IN THE

"OFF" POSITION

SELECTOR IN

"TIMER ON"

POSITION

Use/Maintenance

Produktspezifikationen

Marke:	DeLonghi
Kategorie:	Heizung
Modell:	Caldobagno HBC 3030
Breite:	276 mm
Tiefe:	227 mm
Produktfarbe:	Weiß
Internationale Schutzart (IP-Code):	IP21
Höhe:	378 mm
Typ:	Elektrischer Raumheizlüfter
Abtaufunktion:	Ja
Wärmequelle:	Elektro
Abmessungen (BxTxH):	276 x 227 x 378 mm
Regelbare Temperatur:	Ja
Heizleistung:	2000 W
Wandmontage:	Ja
Sommerlüftung:	Ja
Platzierungsoptionen:	Flur
Hitzeleistung (min):	1150 W
Geeignet bis zu Zimmergrößen von:	60 m³
