TYPICAL INSTALLATION

WARNING:ALWAYS turn compressor OFF, disconnect from power source, and drain all pressure

from system before servicing.

Note: Air supply must be dry enough to avoid ice formation at temperatures below 35°F (2°C).

Note: These products are designed specifically for compressed air service only.

Note: Use a thread sealer or Teflon® tape on all male threads.

CAUTION: Do not install to a system where the compressor is lubricated with, or theair contains, a

material that will attack plastic bowls. Certain compressor oils, household cleaners, chemicals,solvents,

paints, or fumes can cause plastic bowl failure.

DRYER

Maximum pressure: 175 psig (12 bar)

Maximum operating temperature: 140°F (60°C)

INSTALLATION

1.

2.

3.

4.

SPECIFICATIONS

Maximum Pressure

175PSI

Max. Temperature

140°F (60°C)

Air Inlet/outlet

3/8” NPT (F)

FIG. 1

WARNING:ALWAYS turn compressor OFF, disconnect from power source, and drain all pressure

from system before servicing. Personal injury and/or property damage could occur.

WARNING:RISK OF ELECTRIC SHOCK, FIRE, AND/OR INJURY. Keep the work area clean and well

lighted. Cluttered benches and dark areas increase the risks of electric shock, fire, and injury to persons.

Place cleaning rags and other flammable waste materials in a secured metal container. The container

should be disposed of properly in accordance with local, state, and federal regulations.

WARNING: RISK OF EXPLOSION AND/OR FIRE.

Do not operate the tool in explosive atmospheres,

such as in the presence of flammable liquids, gases, or dust. The tool is able to create sparks resulting in

the ignition of the dust or fumes.

WARNING: RISK OF INJURY.

Keep bystanders, children, and visitors away while operating the tool.

Distractions are able to result in the loss of control of the tool.

WARNING: RISK OF INJURY.

Dress properly. Do not wear loose clothing or jewelry. Contain long

hair. Keep hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair increase

the risk of injury to persons as a result of being caught in moving parts.

WARNING: RISK OF HEARING LOSS.

Always wear ANSI S3.19 approved ear protection when using

the tool. Prolonged exposure to high intensity noise is able to cause hearing loss.

WARNING: RISK OF EYE INJURY.

Always wear ANSI Z87.1 approved safety goggles when using an

air tool. Air powered equipment and power tools are capable of propelling materials such as metal chips,

sawdust, and other debris at high speed which could result in serious eye injury.

WARNING: RISK OF INJURY.

Disconnect the tool from the air supply when not in use. NEVER

change accessories or perform maintenance or service operations while the tool is connected to the air

supply.

WARNING:RISK OF BURSTING AND/OR INJURY. Check for damaged air hose. Keep the air hose

away from heat, oil, and sharp edges. Inspect the air hose periodically and replace it if it becomes worn or

damaged.

WARNING:RISK OF INJURY. Tool service must be performed only by qualified repair personnel.

WARNING:RISK OF INJURY. When servicing a tool, use only identical replacement parts. Use only

authorized parts.

WARRANTY

ONE YEAR LIMITED WARRANTY:DEWALT Industrial Tools (the Company) warrants that for a period

of twelve (12) months from the date of purchase, it will replace or repair, free of charge, for the original

retail purchaser only, any part or parts, manufactured by the Company, found upon examination by the

Company or its assigned representatives, to be defective in material or workmanship or both. All

transportation charges for parts submitted for replacement or repair under this warranty must be borne by

the original retail purchaser. This is the exclusive remedy under this warranty.

Failure by the original retail purchaser to install, maintain and operate said equipment in accordance with

good industry practices, or failure to comply with the specific recommendations of the Company set forth

in the owner’s manual, shall render this warranty null and void. The Company shall not be liable for any

repairs, replacements, or adjustments to the equipment or any costs for labor performed by the purchaser

without the Company’s prior written approval. The effects of corrosion, erosion and normal wear and tear

are specifically excluded from this warranty.

THE COMPANY MAKES NO OTHER WARRANTY OR REPRESENTATION OF ANY KIND WHATSOEVER,

EXPRESSED OR IMPLIED EXCEPT THAT OF TITLE. ALL IMPLIED WARRANTIES, INCLUDING ANY

WARRANTY OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE ARE HEREBY

DISCLAIMED. LIABILITY FOR CONSEQUENTIAL AND INCIDENTAL DAMAGES UNDER ANY AND

ALL WARRANTIES, OTHER CONTRACTS, NEGLIGENCE, OR OTHER SORTS IS EXCLUDED TO THE

EXTENT EXCLUSION IS PERMITTED BY LAW.

Notwithstanding the above, any legal claim against the Company shall be barred if legal action thereon is

not commenced within twenty-four (24) months from the date of purchase or delivery whichever occurs last.

This warranty constitutes the entire agreement between the Company and the original retail purchaser and no

representativeoragentisauthorizedtoalterthetermsofsamewithoutexpressedwrittenconsentofthe

Company.

ENGLISH

DXCM019-0376

Desiccant Dryer

IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR ANY DEWALT TOOL, CALL US

TOLL FREE AT: 1-888-895-4549.

WARNING:For your own safety, read the air compressor instruction manual before using any accessory.

Failure to heed these warnings may result in personal injury and serious damage to the air compressor and

the accessory. When servicing this tool, use only identical replacement parts.

WARNING: CONTAINS LEAD. May be harmful if eaten or chewed. May generate dust containing lead.

Wash hands after use. Keep out ofreach of children.

WARNING: This product can expose you to chemicals including Lead and Cadmium, which are known to

the State of California to cause cancer and birth defects or other reproductiveharm. For more information go

to www.P65Warnings.ca.gov.

WARNING:Thisproductisaspecificallydesignedforcompressedairservice ONLY.Adjustair

outletpressureatorbelowthemaximumratedpressureforeachtooloraccessory.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or

serious injury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or

moderate injury.

The air dryer should be located as close as possible to the air tool or spray gun.

A shutoff valve should be installed before the air dryer so the unit can be easily depressurized for

servicing. Securely mount the air cleaner/dryer in a vertical position using the mounting bracket

supplied with the unit.

Install a filter before and after the coalescing filter/dryer for optimum performance. Connect the

piping or hose with airflow in the direction of the arrows cast into the top of the unit. Avoid using

unnecessary fittings, couplings, etc., that restrict air flow.

Remove the bowl from the dryer housing by loosening the lock ring. Pull bowl down to remove

from housing.

Open bag of desiccant and pour into bowl. Shake or tap bowl periodically to settle desiccant. Fill

to within 1/2 from top of bowl. Do not allow desiccant to get into center tube.

5.

6.

Reinstall bowl on housing. Be sure the lock ring is tightened before pressurizing the unit.

7.

Be

s

u

re

to use a clean air hose to prevent contamination of the cleaned air.

8

.

Pressurize system and check for any air leaks.

1.

The only other servicing required for the air dryer is replacement of the desiccant when the desiccant

turns pink, and replacement of the filter element when the service indicator pops up.

2.

Desiccant Replacement

A. Shut off air flow to the air cleaner/dryer and depressurize system.

B. Remove bowl from the dryer housing by loosening the lock ring. Pull bowl down to remove from

housing.

C. Pour out used desiccant.

D. Pour new desiccant into bowl filling to within 1/2 of the top of the bowl. Do not allow desiccant to

get into center tube.

E. Reinstall bowl on housing. Be sureit is securely locked in place before pressurizing the unit.

Maintenance

WARNING:ALWAYS turn compressor OFF, disconnect from power source, and drain all

pressure from system before servicing.
