MULTI-SURFACE
DIRT DEVIL MULTI-SURFACE
REWIND UPRIGHT
USER MANUAL
Please visit DirtDevil.com for video instructions
and FAQ’s for this Vacuum Cleaner.
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLY AND USE.
This product is intended for Household use only. If
used Commercially warranty is VOID.
©2023 Techtronic Floor Care Technology Limited. Distributed by, Royal Appliance Mfg. Co. Charlotte, NC 28262. 961152294-R0
Contact Dirt Devil
®
Support
for assistance with your vacuum
.
DO NOT
RETURN TO STORE
Chat with us!
dirtdevil.com/pages/ddcontact
Every day 8am-8pm EST
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ ALL SAFETY WARNINGS AND INSTRUCTIONS BEFORE USING THIS PRODUCT.
WARNING: WHEN USING AN
ELECTRICAL PRODUCT, BASIC PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED TO AVOID
ELECTRIC SHOCK, FIRE, AND/OR SERIOUS
INJURY, INCLUDING THE FOLLOWING:
• Fully assemble product prior to use.
• Operate cleaner only at voltage specified on
data plate on back of cleaner.
• Do not leave product when plugged in. Unplug
from outlet when not in use and before
servicing.
• Do not use outdoors or on wet surfaces.
• Do not allow to be used as a toy. Not intended
for use by children age 12 and under. Close
supervision is necessary when used by or
near children. To avoid injury or damage, keep
children away from product, and do not allow
children to place fingers or other objects into
any openings.
• Use only as described in this user’s manual.
Use only Dirt Devil® recommended attachments.
• Do not use product with damaged cord or
plug. If product is not working as it should,
has been dropped, damaged, left outdoors, or
dropped into water, call customer service at
1-800-321-1134 prior to continuing use.
• Do not pull or carry by cord, use cord as a
handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run
appliance over cord. Keep cord away from
heated surfaces.
• Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use
with any opening blocked; keep free of dust,
lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts
of body away from openings and moving parts.
• Turn o all controls before unplugging.
• Use extra care when cleaning on stairs. To
avoid personal injury or damage, and to prevent
the cleaner from falling, always place cleaner
at bottom of stairs or on floor. Do not place
cleaner on stairs or furniture, as it may result in
injury or damage.
• Do not use to pick up flammable or combustible
liquids, such as gasoline, or fine wood sandings,
or use in areas where they may be present.
• Do not pick up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
• Do not use without separator, filters, or dirt cup
in place.
CAUTION: TO REDUCE THE RISK OF
DAMAGE:
• Avoid picking up hard, sharp objects with this
product, as they may cause damage
• Store appropriately indoors in a dry place. Do
not expose machine to freezing temperatures.
• Brush roll continues to turn while product is
turned on and handle is in upright position.
To avoid damage to carpet, rugs, and flooring,
avoid tipping cleaner or setting it on furniture,
fringed area rugs, or carpeted stairs during
tool use.
• Do not use sharp objects to clean out hose as
they can cause damage.
• With brush roll on, do not allow cleaner to sit in
one location for an extended period of time, as
damage to floor can result.
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK, THIS APPLIANCE HAS
A POLARIZED PLUG (ONE BLADE IS WIDER
THAN THE OTHER). THIS PLUG WILL FIT IN A
POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG
DOES NOT FIT FULLY IN THE OUTLET, REVERSE
THE PLUG. IF IT STILL DOES NOT FIT, CONTACT
A QUALIFIED ELECTRICIAN TO INSTALL THE
PROPER OUTLET. DO NOT CHANGE THE PLUG IN
ANY WAY.
ASSEMBLY
FULLY ASSEMBLE PRODUCT PRIOR TO USE.
1
Insert the handle firmly into the body of the
vacuum.
2
Insert the top end of the hose into the handle
valve until you hear a click. Then, twist the
bottom end of the hose into the dirt cup inlet
until it locks into place.
OPERATION
CAUTION: Use extra care when
cleaning on stairs. To avoid personal injury or
damage, and to prevent the cleaner from falling,
always place cleaner at the bottom of the stairs
or on the floor. Do not place cleaner on stairs or
furniture, as it may result in injury or damage.
When using tools, always ensure handle is in
the upright position.
1
Step on red Power Pedal to turn ON/OFF.
2
Step on the silver Recline Pedal to lean vacuum
into the cleaning position.
3
Adjust the height of the brush roll based o
the floor type you are cleaning. If you find the
vacuum is dicult to push, adjust the dial to a
higher setting.
IMPORTANT: When pulling the cord, yellow
tape will identify when the cord is almost fully
extended. When red tape is visible on cord, the
cord has reached its full length. (Do not pull the
cord past the red tape.)
4
Prior to using, grasp the end of the plug and pull
to release the cord from the cord reel until red
tape is reached.
5
To return cord for storage, hold plug and press
down cord release pedal on side of cord reel.
AVAILABLE TOOLS
NOTE: Your model may not include all tools listed.
All tools lock into place when attached to hose or
extension wand.
CREVICE TOOL
PART# 44015703
The crevice tool may be used in
tight spaces, corners, and along
edges in places such as dresser
drawers, upholstered furniture,
stairs and baseboards.
DUSTING BRUSH
PART# 440015702
The dusting brush has delicate
bristles that gently clean the fine
dust.
2 IN 1 CREVICE AND DUSTING
TOOL
PART# 440015712
This is a combination of two tools
in one. Simply slide up the dusting
attachment until it locks into
place to use the duster. To use the
crevice tool, press side button to
unlock and slide down the dusting
brush.
UPHOLSTERY TOOL
PART# 440015708
The Upholstery Tool is perfect
for picking up debris on couches,
curtains, mattresses and more.
PET UPHOLSTERY TOOL
PART# 440015713
With the Pet Upholstery Tool, easily
manage pet hair above the floor
and clean up hair on furniture with
ease. The rubber edge makes this
tool easy to clean.
PET TURBO TOOL
PART# 440015714
This air powered tool allows for pet
hair to be agitated to get a deeper
clean on upholstery such as couches,
mattresses, and other furniture.
USING THE LIVE WAND
AND TOOLS
1a
Make sure the vacuum is upright and press the
wand release button.
1b
Attach the desired accessory to the end of the
wand.
MAINTENANCE
WARNING: To reduce the risk of
personal injury, unplug before cleaning or
servicing.
This product contains no serviceable parts. If
appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into
water, call customer service at 1-800-321-1134
prior to continuing use.
EMPTYING THE DIRT CUP
1
Press the bin release button.
2
Empty over trash by pressing dirt cup release
button.
CLEANING THE RINSEABLE FILTER
WARNING: To reduce the risk of
personal injury, unplug before cleaning or
servicing.
PART# 440015696
NOTE: For optimal performance check for debris
build up on filter and follow steps below.
1
Remove the dirt cup, then open the dirt cup latch
to access the rinseable filter.
2
Twist filter to the left to unlock, then lift plastic
puck o of the dirt cup.
3
Remove foam filter from the plastic puck and
rinse filter with water only until the filter is clean,
Make sure the water running through becomes
clear.
24-48
HRS
4
Allow for the filter to air dry at least 24 hours
before placing filter back into the unit.
IMPORTANT: The filter must be completely dry
before replacing it. This may take between 24
and 48 hours.
Check the inside of filter for dampness before
replacing.
HOW TO REPLACE BELT AND CLEAN
BRUSH ROLL
WARNING: To reduce the risk of
personal injury, unplug before cleaning or
servicing.
BRUSHROLL PART# 440015693
BELT PART# 440015963
1
Remove 5 screws and pull upward to remove
nozzle guard.
2
Pull brush roll out from the vacuum belt.
3
Cut o tangled hair along grooves.
NOTE: Hair can also be cut o without removing
the guard.
4
To replace the brush roll, loop the belt around
the brush roll and push the roll back into place.
Replace the nozzle guard and five screws.
TIP: Rotate brush roll manually to ensure the belt
is properly installed. Check for obstructions in
the brush roll area and remove any obstructions.
When obstructions are cleared, resume cleaning
as normal.
REMOVING SYSTEM CLOGS
To reduce the chance of system clogs be sure
to clean up larger debris from the area before
vacuuming.
If you are experiencing a loss of suction, or you
notice debris is spitting out of the nozzle, we
recommend checking the nozzle, tube, hose and
filters for any visible signs of blockage or built
up debris. It is also recommended to rinse your
Filter if there is visible built up dirt and dust on
the filter. This should help improve performance
on your vacuum.
THERMAL PROTECTION
A thermal protector has been designed into
your cleaner to protect it from overheating.
When the thermal protector activates the
cleaner will stop running.
If this happens proceed as follows:
1. Turn cleaner OFF and unplug it.
2. Empty the dirt cup.
3. Inspect the nozzle inlet, hose connector,
hose, dirt cup inlet, cyclonic filter
rinsable filter and exhaust filter for
any obstructions. Clear obstructions if
present.
4. When cleaner is de-energized and
motor cools for 30 minutes, the thermal
protector will deactivate and cleaning
may continue.
If the thermal protector continues to activate
after following the above steps, your cleaner
needs servicing.
