Seite 1/2
d:dicate™ 4018A Supercardioid Microphone
A combination of the MMC4018 Microphone Capsule and the MMP-A
Preamplifier, this mic is part of the modular d:dicate™ Recording Micro-
phones series. At any time and with no tools necessary it is transform
the basic 4018A Microphone into a new configuration by combining it
with another d:dicate™ Microphone Capsule or Preamplifier.
Performance
Mount the foam windscreen on the mic head whenever used outdoors
or in air turbulent situations such as close miking voice in order to
prevent wind or pop noise.
With each d:dicate™ Microphone Capsule, comes a unique calibration
chart that shows the exact frequency response of the purchased
capsule measured with a linear MMP-A .Preamplifier
Typical on- and off-axis and frequency responses for a MMC4018 at
30 cm (1ft):
Attenuation pad
The MMP-A Preamplifier has a 20 dB attenuation push-
switch at the XLR connector. Use a pencil or the like
to activate the attenuator and lower output by 20 dB.
dB
10
0
-10
-20
-30
20 Hz 50 100 200 500 1 kHz 2 5 10 20 40
90
140
0
30
60
d p a m i c r o p h o n e s . c o m / 4 0 1 8 A
Service & repair
If you are not satisfied with the characteristics exhibited by this product, please go to
www.dpamicrophones.com/service for instructions.
Warranty
The d:dicate™ 4018A Supercardioid Microphone is covered by a five-year limited warranty.
CE marking
This product conforms to all relevant directives approved by the European Commision.
DPI-4018A-QG
7TIGM½GEXMSRW
Directional pattern
Supercardioid
Principle of operation
Pressure gradient
Cartridge type
Pre-polarized condenser
Frequency range
10 Hz - 20 kHz
Frequency range, ± 2 dB, at 30 cm
40 Hz - 18 kHz
Sensitivity, nominal, ±2 dB at 1 Hz
12 mV/Pa; -38.4 dB re. 1 V/Pa
Equivalent noise level, A-weighted
Typ. 16 dB(A) re. 20 µPa (max. 19 dB)
S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL)
Typ. 78 dB(A)
Total Harmonic Distortion (THD)
< 1 % up to 137 dB SPL peak
Dynamic range
Typ. 121 dB
Max. SPL, peak before clipping
157 dB
Switchable attenuator, filters etc.
0 dB / -20 dB
Output impedance
200 Ω
Minimum load impedance
2 kΩ
Cable drive capability
100 m (328 ft)
Output balance principle
Impedance balancing with Active Drive
Common Mode Rejection Ratio (CMRR)
> 60 dB
Power supply
48 V Phantom power (±4 V)
Current consumption
2.8 mA
Connector
XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
Color
Matte black
Weight
158 g (5.6 oz)
Microphone diameter
19 mm (0.75 in)
Capsule diameter
19 mm (0.75 in)
Microphone length
170 mm (6.7 in)
Maximum output voltage, RMS
7 V
Polarity
+V at Pin 2 for positive sound pressure
Temperature range
-40 to 45 °C (-40 to 113 °F)
Relative Humidity (RH)
Up to 90%
