FEATURES

• Upto30ampscontinuouscurrentwithproperairowand35amps

burstcurrent(15seconds)

• 3.5A*continuouscurrent,5VSwitch-ModeBECCircuit

• StrongerBECforsupportofmost3-axisstabilizationsystems

• Driveupto7analogor6digitalstandard-sizeservoswiththeBEC

onanyrecommendedinputvoltage

• 3-to4-cellLi-Po,9-to12-cellNi-MH/Ni-Cdinputvoltage

• Programmablemotorbraking

• Safepower-armmodepreventsaccidentalstarts

• Programmablelowvoltagecutoffwithsettingsfor3-cellLi-Po(9.2V),

4-cellLi-Po(12V)or74%ofbatterystartingvoltage

• Programmablethrottleinputrange(1.1ms–1.9msor1.2ms–1.8ms)

• Programmablesoftstartforhelisandairplanes

• Automotorshutdownifsignalislostorthereisinterference

• Programmabletiming—5user-selectablerangesforusewithalarge

varietyofbrushlessmotors

• Pre-wiredconnectors—E-iteEC3

™

connectoronbatteryinputand

3.5mmgoldbulletconnectorsonmotoroutputleads

*Propercoolingandairowrequired

SPECIFICATIONS

ContinuousCurrent 30A*

MaxBurstCurrent 35A(15sec)*

Length 51.0mm(2.00in)

Width 28.0mm(1.10in)

Height 8.70mm(0.35in)

Weight 31.0g(1.10oz)

Cells 3–4SLi-Poor9–12Ni-MH/Ni-Cd

BatteryInputLeads 16AWGwithE-iteEC3Connector

MotorOutputLeads 16AWGwith3.5mmGoldBulletConnectors

*Propercoolingandairowrequired

NOTICE

Allinstructions,warrantiesandothercollateraldocumentsaresubjecttochangeatthesolediscretionofHorizonHobby,Inc.Forup-to-date

productliterature,visithorizonhobby.comandclickonthesupporttabforthisproduct.

Meaning of Special Language

Thefollowingtermsareusedthroughouttheproductliteraturetoindicatevariouslevelsofpotentialharmwhenoperatingthisproduct:

NOTICE:Procedures,whichifnotproperlyfollowed,createapossibilityofphysicalpropertydamageANDalittleornopossibilityofinjury.

CAUTION:Procedures,whichifnotproperlyfollowed,createtheprobabilityofphysicalpropertydamageANDapossibilityofseriousinjury.

WARNING:Procedures,whichifnotproperlyfollowed,createtheprobabilityofpropertydamage,collateraldamage,andseriousinjuryOR

createahighprobabilityofsupercialinjury.

WARNING:ReadtheENTIREinstructionmanualtobecomefamiliarwiththefeaturesoftheproductbeforeoperating.Failuretooperate

theproductcorrectlycanresultindamagetotheproduct,personalpropertyandcauseseriousinjury.

Thisisasophisticatedhobbyproduct.Itmustbeoperatedwithcautionandcommonsenseandrequiressomebasicmechanicalability.Failure

tooperatethisProductinasafeandresponsiblemannercouldresultininjuryordamagetotheproductorotherproperty.Thisproductisnot

intendedforusebychildrenwithoutdirectadultsupervision.Donotattemptdisassembly,usewithincompatiblecomponentsoraugment

productinanywaywithouttheapprovalofHorizonHobby,Inc.Thismanualcontainsinstructionsforsafety,operationandmaintenance.Itis

essentialtoreadandfollowalltheinstructionsandwarningsinthemanual,priortoassembly,setuporuse,inordertooperatecorrectlyand

avoiddamageorseriousinjury.

Age Recommendation: Not for children under 14 years. This is not a toy.

STARTING YOUR POWER SYSTEM

1. PowerONyourtransmitterandensurethepositionofthethrottleisintheIdle(low)position.

2. ConnectthebatterytotheESC.Youwillhear1low,longtonetoindicatestartup,thentherespectivenumberofmedium-lengthmid-tonesto

indicatethecellcountoramusicaltoneforthe74%cutoff,followedby3risingtonestoindicatetheESCisarmed.

3. Whenyoumovethethrottlestickupward,themotorwillrun.Continuetomovethethrottlestickupwardtofullthrottle(highposition),andthe

motorwillrunfaster.Whenthethrottlestickgoesbelowthestart-upposition,themotorwillstoprunning.

4. Checktheservomotionaspartofyourpreightcheck.Itisveryimportanttomakesurelinkagesarefree-movingwithnobinding.Remember,

whenintheprogrammingmode:

FullThrottle=StickUp Idle=StickDown

ThedefaultsettingsfortheESCareasfollows:

• Voltagecutoffsetat74% • BrakesettoOff

• Timingsetat15degrees • ThrottleInputRangesetat1.2msto1.8ms

• Start-upRate(AccelerationDelay)setat0.25seconds • PWMFrequencysetat8KHz

• OperatingModesettonormal(airplane)

ThankyouforpurchasingtheE-ite

30-AmpProSwitch-modeBECBrushlessESC(V2).Thisisahigh-qualitysensorlessbrushlesselectronic

speedcontrolwithanintegratedswitch-modeBECthatisverylightweightandefcient.Itcanoperatewithouttheneedforaseparatereceiver

batterytopoweryourservosandreceivers,savingyouweightandcomplication.

Please visit www.horizonhobby.com for the most up-to-date technical manual for translations and changes.

SERVO RATINGS WITH BEC ENABLED

Drivesupto7analogor6digitalstandard-sizeservoswiththeBEConanyrecommendedinputvoltage.Someservocombinationsthathavebeen

testedinvariousmodelsinclude:

• 1analogstandardservo,1digitalsub-microservo,2analogsub-microservos—E-iteApprentice

15eRTF

• 2ParkZone

(PKZ1081)analogsub-microservosand2ParkZone(PKZ1090)digitalmetalgearsub-microservos—ParkZoneT-28TrojanRTF

&F4UCorsairRTF

Digitalservosandbindingservosofanykindtypicallyhavehighercurrentdraw.Asageneralrule,microandsub-microservosdrawlesscurrent,

whichmayaffectyourservousageasshownintheexamplesabove.WerecommendinstallingaHangar9

ServoandReceiverCurrentMeter

(HAN172),betweenthethrottleleadoftheESCandreceivertoconrmcurrentdrawoftheactualservosused.AlwayspositiontheESCfor

maximumairow;coolingcansignicantlyaidintheperformanceoftheBEC.

BEFORE FIRST USE

Pleasereferto“ ”notesforBECusageguidelines.Youmustfollowtheseguidelinesforsafeoperation.IfyouServo Ratings with BEC Enabled

areusingmorethan7analogstandardservos,morethan6digitalstandardservosorservoswithhighercurrentdrawthantheBECcandeliver,

youwillneedtodisabletheBEC.IfyouwishtodisabletheBEC,youmustremovetheredreceiverwireleadandconnectorfromthereceiverlead

housingandtheninsulateitproperlytopreventshorting.WhenoperatingwiththeBECdisabled,itisrecommendedtouseaseparate,high-power,

externalBEC,orreceiverpackandswitch.

TheESCcomesprewiredwithanEC3connectorandiscompatiblewithmostbatteries.Onlyuse3–4SLi-Poor9–12Ni-MH/Ni-Cdbatteries.

ConnectafullychargedbatterytotheESCbatteryconnector.

WARNING:AlwaysremovethepropellerbeforecheckingthestartupfunctionoftheESCormakingprogrammingchanges.Keepallbody

parts,hairandlooseclothingawayfromamovingpropeller,astheseitemscouldbecomeentangled.

WARNING:Alwaysdisconnectthebatterywhennotyingtoavoidover-dischargingthebattery.Batteriesdischargedtoavoltagelower

thanthelowestapprovedvoltagemaybecomedamaged,resultinginlossofperformanceandpotentialrewhenbatteriesarecharged.

When ﬂying in hot weather, check on the condition of the ESC, battery and motor after each ﬂight. Always let the electronic components cool to

near ambient temperature between ﬂights. During extreme conditions, throttle management is necessary when running near maximum levels of

current draw. It is possible to cause permanent damage to the motor, battery and ESC if in full throttle the entire ﬂight.

USING THE 30-AMP PRO SWITCH-MODE BEC BRUSHLESS ESC

ThisESCissimpletouseand,forsafety,willnotarmthemotoruntilthethrottlestickhasbeenheldintheIdle(low)positionformorethan1

second.TheESCwillindicatethesoftcutoffvoltagesettingeverytimethebatteryisconnectedbyrstemittingalow,longtonetoindicatestartup.

Dependingontheselectedcutoffvoltage(defaultis74%),youwillthenheartherespectivenumberofmedium-lengthmid-tonestoindicatethe

cellcountoramusicaltoneforthe74%cutoff,helpingyoutoconrmthesettingbeforeeveryight.

Properaircoolingisrequiredduringights.TheESCshouldbeplacedinanareawhereairowsovertheESC.

CONNECTING THE ESC TO THE MOTOR

ThethreewiresfromthemotorconnecttothethreegoldbulletconnectorsontheESC.Theorderofconnectiontothemotorisnotimportant;

anymotorwirecanbeconnectedtoanyconnector.Ifthemotorrunsbackwards,youcansimplydisconnectandswitchanytwoofthemotorwire

plugsconnectedtotheESC.

MOUNTING THE ESC

1. Choosealocationthathasgoodairowandoffersgoodprotection.

DO NOT cover the side with the ﬂat heat shield with hook and loop tape, or any other material, as this will greatly reduce its effectiveness.

2. MounttheESCwithacombinationofhookandlooptape,2-sidedfoamtapeand/ortiewraps.

ENTERING THE PROGRAMMING MODE

1. WiththebatterydisconnectedfromtheESCandthetransmitterpoweredON,movethethrottlesticktofullthrottle.Holdfullthrottle,then

connectthebatterytotheESC.

2. Wait5secondsandtheESCwillgivetwosetsoffastringingtonestoindicateyouhaveenteredProgrammingMode.

3. Onceyouhearthesetones,movethesticktocenterfor5seconds.TheESCwillbeep1time,indicatingyouarenowinMenu1.

4. TheESCwillnowwait5secondsforyoutomakeyourselection;yourprogrammingoptionsareeitherfullthrottleoridle.

5. Whenyouhavemadeavalidselection,theESCwillbeeponcewithalowertone.Movethestickbacktocenterforthenextmenuitem(2

beeps,3beepsandsoon).Ifyoudonotmakeaselectionwithin5seconds,theESCwillmovetothenextmenuitem.

6. Ifyouwanttomakechangesintheprogrammingmenus(seespecicinstructionsbelow),movethethrottlesticktofullthrottle.Youwillhave5

secondstomakeyourselection.

7. Ifyouwanttoadvancetothenextmenu,allowtheprogrammingtoskiptothenextmenuafterthe5secondshaveexpired.

PROGRAMMING MENU 1 – VOLTAGE CUTOFF

The default setting is 74% cutoff*.

UsethisoptiontosetthevoltageatwhichtheESCwillshutdownthemotortopreventdamagetothebatterywhenitreachesthecutoffvoltage.

Youwillknowthebatteryhasreachedautocutoffwhenyouhearthemotor“pulse”repeatedly.

1. Movethethrottlesticktofullthrottletomakechangestothevoltagecutoffprogramming.

 a.Toselect3-celllowvoltagecutoff—Youwillhear3shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyou

havesettheprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.Toselect4-celllowvoltagecutoff—Youwillhear4shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyou

havesettheprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 c.Toselect74%cutoff—Youwillhear7shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

*IMPORTANT NOTE ABOUT 74% CUTOFF: This option will activate the soft cutoff at 74% of the startup voltage or 9.2V, whichever is higher.

For example, if the battery measures 16.8 volts at startup, then the soft cutoff will occur at 12.4 volts.

The 74% cutoff option will check the startup voltage every time you connect the battery to the ESC. Avoid using partially charged batteries, as the

system cannot protect the Li-Po batteries if you are using the 74% cutoff and connect a partially charged battery.

You will know the battery has reached soft auto cutoff when you hear the motor “pulse” repeatedly. Land your model as soon as you hear the

motor pulse (indicating the battery voltage has dropped to the cutoff voltage level) to prevent over-discharge of the Li-Po battery and to prevent

sudden power loss.

PROGRAMMING MENU 2 – BRAKE TYPE

The default setting is Brake Off.

ThisoptiongivesyouthechoicetohavetheESCstopthepropellerduringight(BrakeOn)orallowittowindmill(BrakeOff).UsetheBrakeOn

optionsforfoldingpropellers.

1. Movethesticktocenterfor5secondsandtheESCwillbeep2times,indicatingyouarenowinMenu2.

2. MovethethrottlesticktofullthrottletomakechangestotheBrakeTypeprogramming.

 a.ToselectNoBrake/BrakeOff—Youwillhear1shortbeep.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhave

settheprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.ToselectSoftBrake—Youwillhear2shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 c.ToselectMediumBrake—Youwillhear3shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhaveset

theprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 d.ToselectHardBrake—Youwillhear4shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

PROGRAMMING MENU 3 – TIMING

The default setting is 15 degrees.

Asageneralrule,lowerpolecountmotorsuselowertimingandhigherpolecountmotorsusehighertiming.Pleaserefertoyourmotor

instructionsandspecicationsforanindicationofthenumberofpoles.

LOW TIMING ADVANCE

TimingDegrees 5&10

MotorPoles 2to4

ExpectedPerformance Goodbalanceofpowerandefciency

MotorPoles 6ormore

ExpectedPerformance Bestefciencyandruntime(lowestpower)

STANDARD TIMING ADVANCE

TimingDegrees 15&20

MotorPoles 6to12

ExpectedPerformance Goodbalanceofpowerandefciency

MotorPoles 14ormore

ExpectedPerformance Bestefciencyandruntime(lowestpower)

HIGH TIMING ADVANCE

TimingDegrees 25

MotorPoles 12

ExpectedPerformance Highestpower,lessefciency

MotorPoles 14ormore

ExpectedPerformance Goodbalanceofpowerandefciency

1. Movethesticktocenterfor5secondsandtheESCwillbeep3times,indicatingyouarenowinMenu3.

2. MovethethrottlesticktofullthrottlepositiontomakechangestotheTimingprogramming.

 a.Toselect5Degrees—Youwillhear1shortbeep.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.Toselect10Degrees—Youwillhear2shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 c.Toselect15Degrees—Youwillhear3shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 d.Toselect20Degrees—Youwillhear4shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 e.Toselect25Degrees—Youwillhear5shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

PROGRAMMING MENU 4 – THROTTLE INPUT RANGE (PWM)

The default setting is 1.2ms to 1.8ms (works with most radio systems).

Thisoptionallowsforproperthrottleinputwithmanydifferentradiosystems.However,someradioshaveawideroutputrange,andmaygive

amorelinearresponsewiththe1.1msto1.9msrange.Ifyoufeelthereistoomuch“dead”areainthestickmovementnearfullthrottle,try

adjustingtheendpointsinyourradio,orchangetothewiderinputrange.Beawarethatifthesesettingsarenotcorrect,itmaybeimpossibleto

armtheESC.

1. Movethesticktocenterfor5secondsandtheESCwillbeep4times,indicatingyouarenowinMenu4.

2. MovethethrottlesticktofullthrottletomakechangestotheThrottleInputRangeprogramming.

 a.Toselect1.2msto1.8ms—Youwillhear1shortbeep.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhaveset

theprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.Toselect1.1msto1.9ms—Youwillhear2shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhaveset

theprogramselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

PROGRAMMING MENU 5 – START-UP RATE

The default setting is 0.25 seconds.

Thestart-uprateisthetimeittakestoreachmaximummotorspeed.Changingthesettingto1secondcanbeusefulwithpower-fragilegear

boxes.

1. Movethesticktocenterfor5secondsandtheESCwillbeep5times,indicatingyouarenowinMenu3.

2. MovethethrottlesticktofullthrottlepositiontomakechangestotheStart-upRateprogramming.

 a.Toselect.25second—Youwillhear1shortbeep.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.Toselect1second—Youwillhear2shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

PROGRAMMING MENU 6 – PWM SWITCHING FREQUENCY

The default setting is 8KHz (acceptable for most motors).

IfyouhavealoworverylowinductancemotorandknowyouneedtouseahigherPWMFrequency(refertothemanualincludedwiththemotor),

thenyoucanchangethesetting.Otherwise,werecommendleavingthedefaultsetting.

1. Movethesticktocenterfor5secondsandtheESCwillbeep6times,indicatingyouarenowinMenu6.

2. MovethethrottlesticktofullthrottletomakechangestothePWMSwitchingFrequencyprogramming.

 a.Toselect8KHzPWMFrequency—Youwillhear1shortbeep.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyou

havesettheprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.Toselect16KHzPWMFrequency—Youwillhear2shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyou

havesettheprogramselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 c.Toselect32KHzPWMFrequency—Youwillhear3shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyou

havesettheprogramselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

PROGRAMMING MENU 7 – OPERATING MODE

The default setting is set to Normal (airplane) Mode (which is limited to a start-up rate of 0.25 or 1 second).

Alternatively,theHeliModecanbeselectedwhich,reducesthestart-uprateto5secondsfortherststart-upandanystart-upafterthemotor/

ESChasbeenstoppedformorethan5seconds.Thishelpstopreventdamagingthemotor,gearsoranyothercomponentsfromanabrupt

start-upwhennoneofthepartsaremoving.Anytimethemotor/ESChasbeenstoppedforlessthan5secondsinHeliMode,thestart-upwillbe

immediate.Thisallowspowertobeappliedimmediately,suchaswhenabortinganauto-rotationattemptortohelppreventacrash.Remember,

youmustwaitmorethan5secondsafterstoppingthemotor/ESCinorderforthe5-secondstart-uptooccuragain.

1. Movethesticktocenterfor5secondsandtheESCwillbeep7times,indicatingyouarenowinMenu7.

2. MovethethrottlesticktofullthrottletomakechangestotheOperatingModeprogramming.

 a.ToselectNormalMode—Youwillhear1shortbeep.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetothenextselection.

 b.ToselectHeliMode—Youwillhear2shortbeeps.Movethethrottlesticktocenter.TheESCwillbeep2times,indicatingyouhavesetthe

programselection.Leaveinfullthrottlefor5secondstoadvancetotherstselectionagain.

TROUBLESHOOTING

TheESCwillbeepmorequietlythannormaliftheinputvoltageisbelowthecutoffvoltagewhenthebatteryisconnected.Checkthevoltageof

thebatterytoseeifitiscorrect(charged),ortheprogrammedcutoffsettingoftheinputvoltageissetincorrectlyforthevoltageofthepackbeing

used.

IfyouhavetroublearmingtheESC(andthethrottletrimhasbeensettominimum),entertheprogrammingmodeandtrychangingthesettingto

1.1ms–1.9msinProgrammingMenu4toseeifithelpscorrecttheproblem.Ifitisacomputerradio,youmayalternativelyincreasehighandlow

throttleATV(endpoint)percentages.

IncreasingthehighATVwillnothaveaconsequenceonarmingissues,onlylowATV.

Sometransmitters,includingallFutabatransmitters,willrequirethethrottlechanneltobe“reversed”forproperoperation.

30-Amp Pro Switch-Mode BEC Brushless ESC (V2)

Instruction Manual | Bedienungsanleitung | Manuel d’utilisation | Manuale di Istruzioni (EFLA1030B)

1 YEAR LIMITED WARRANTY

What this Warranty Covers -HorizonHobby,Inc.,(Horizon)warrants

totheoriginalpurchaserthattheproductpurchased(the“Product”)will

befreefromdefectsinmaterialsandworkmanshipforaperiodof1

yearsfromthedateofpurchase.

What is Not Covered -This warranty isnot transferable and does

not cover (i) cosmetic damage, (ii) damage due to acts of God, ac-

cident, misuse, abuse, negligence, commercial use, or due to

improper use, installation, operation or maintenance, (iii) modi-

cation of or to any part of the Product, (iv) attempted service by

anyone other than a Horizon Hobby authorized service center,

(v) Product not purchased from an authorized Horizon dealer, or

(vi) Product not compliant with applicable technical regulations.

OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES

NO OTHER WARRANTY OR REPRESENTATION, AND HEREBY DIS-

CLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITH-

OUT LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGE-

MENT, MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE

HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET

THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE. 

Purchaser’s Remedy -Horizon’ssoleobligationandpurchaser’ssole

andexclusiveremedyshallbethatHorizonwill,atitsoption,either(i)

service,or(ii)replace,anyProductdeterminedbyHorizontobedefec-

tive.HorizonreservestherighttoinspectanyandallProduct(s)involved

inawarrantyclaim.Serviceorreplacementdecisionsareatthesole

discretion of Horizon. Proof of purchase is required for all warranty

claims.SERVICEORREPLACEMENTASPROVIDEDUNDERTHISWAR-

RANTYISTHEPURCHASER’SSOLEANDEXCLUSIVEREMEDY.

Limitation of Liability -HORIZONSHALLNOTBELIABLEFORSPE-

CIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS

OFPROFITS OR PRODUCTION OR COMMERCIAL LOSS INANYWAY,

REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT,

WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER

THEORYOFLIABILITY,EVENIFHORIZONHASBEENADVISEDOFTHE

POSSIBILITYOFSUCHDAMAGES.Further,innoeventshalltheliability

ofHorizonexceedtheindividualpriceoftheProductonwhichliability

isasserted.AsHorizonhasnocontroloveruse,setup,nalassembly,

modicationormisuse,noliabilityshallbeassumednoracceptedfor

anyresultingdamageorinjury.Bytheactofuse,setuporassembly,

theuseracceptsallresultingliability.Ifyouasthepurchaseroruser

arenotpreparedtoaccepttheliabilityassociatedwiththeuseofthe

Product,purchaserisadvisedtoreturntheProductimmediatelyinnew

andunusedconditiontotheplaceofpurchase.

Law -ThesetermsaregovernedbyIllinoislaw(withoutregardtoconict

oflawprincipals).Thiswarrantygivesyouspeciclegalrights,andyou

mayalsohaveotherrightswhichvaryfromstatetostate.Horizonreserves

therighttochangeormodifythiswarrantyatanytimewithoutnotice.

WARRANTY SERVICES

Questions, Assistance, and Services - Yourlocalhobbystoreand/

orplaceofpurchasecannotprovidewarrantysupportorservice.Once

assembly,setuporuseoftheProducthasbeenstarted,youmustcon-

tactyourlocal distributororHorizon directly.This willenableHorizon

tobetteransweryourquestionsandserviceyouintheeventthatyou

mayneedanyassistance.Forquestionsorassistance,pleasevisitour

websiteatwww.horizonhobby.com,submitaProductSupportInquiry,

orcall 877.504.0233 tollfree to speak toa Product Supportrepre-

sentative.

Inspection or Services - If this Product needs to be inspected or

servicedandiscompliantinthecountryyouliveandusetheProduct

in,pleaseusetheHorizonOnlineServiceRequestsubmissionprocess

foundonourwebsiteorcallHorizontoobtainaReturnMerchandise

Authorization(RMA)number.PacktheProductsecurelyusingaship-

pingcarton.Pleasenotethatoriginalboxesmaybeincluded,butare

not designed to withstand the rigors of shipping without additional

protection.Shipviaacarrierthatprovidestrackingandinsurancefor

lostordamagedparcels,asHorizonisnotresponsibleformerchandise

untilitarrivesandisacceptedatourfacility.AnOnlineServiceRequest

is available at http://www.horizonhobby.com/content/_service-cen-

ter_render-service-center.Ifyou do nothave internet access, please

contactHorizonProductSupporttoobtainaRMAnumberalongwith

instructionsforsubmittingyourproductforservice.WhencallingHori-

zon,youwillbeaskedtoprovideyourcompletename,streetaddress,

emailaddressand phonenumber whereyoucan bereached during

business hours.When sending product into Horizon, please include

yourRMAnumber,alistoftheincludeditems,andabriefsummaryof

theproblem.Acopyofyouroriginalsalesreceiptmustbeincludedfor

warrantyconsideration.Besureyourname,address,andRMAnumber

areclearlywrittenontheoutsideoftheshippingcarton.

NOTICE: Do not ship LiPo batteries to Horizon. If you have any

issue with a LiPo battery, please contact the appropriate Hori-

zon Product Support ofﬁce.

Warranty Requirements - For Warranty consideration, you

must include your original sales receipt verifying the proof-

of-purchase date. Provided warranty conditions have been met,

yourProductwillbeservicedorreplaced freeofcharge.Serviceor

replacementdecisionsareatthesolediscretionofHorizon.

Non-Warranty Service - Should your service not be covered by

warranty, service will be completed and payment will be re-

quired without notiﬁcation or estimate of the expense unless

the expense exceeds 50% of the retail purchase cost.Bysub-

mittingtheitemforserviceyouareagreeingtopaymentoftheservice

withoutnotication.Serviceestimatesareavailableuponrequest.You

mustincludethisrequestwithyouritemsubmittedforservice.Non-

warrantyserviceestimateswillbebilledaminimumof½houroflabor.

Inadditionyouwillbebilledforreturnfreight.Horizonacceptsmoney

ordersandcashier’schecks,aswellasVisa,MasterCard,American

Express, andDiscover cards.Bysubmitting anyitem to Horizonfor

service,you are agreeing to Horizon’sTerms and Conditions found

on ourwebsite http://www.horizonhobby.com/content/_service-cen-

ter_render-service-center.

NOTICE: Horizon service is limited to Product compliant in the

country of use and ownership. If non-compliant product is re-

ceived by Horizon for service, it will be returned unserviced at

the sole expense of the purchaser.

COMPLIANCE INFORMATION FOR THE EUROPEAN UNION

Declaration of Conformity(inaccordancewithISO/IEC17050-1)

No.HH2012111902

Product(s): EFL30AESC

ItemNumber(s): EFLA1030B

Theobjectofdeclarationdescribedaboveisinconformitywiththerequirementsofthespecicationslistedbelow,followingtheprovisionsof

theEMCDirective2004/108/EC:

EN55022:2010 + AC:2011

EN55024:2010

Signedforandonbehalfof:

HorizonHobby,Inc.

Champaign,ILUSA

November19,2012

StevenA.Hall

ExecutiveVicePresidentandChiefOperatingOfcer

InternationalOperationsandRiskManagement

HorizonHobby,Inc.

Instructions for disposal of WEEE by users in the European Union

Thisproductmustnotbedisposedofwithotherwaste.Instead,itistheuser’sresponsibilitytodisposeoftheirwasteequipment

byhandingitovertoadesignatedcollectionspointfortherecyclingofwasteelectricalandelectronicequipment.Theseparate

collectionandrecyclingofyourwasteequipmentatthetimeofdisposalwillhelptoconservenaturalresourcesandensurethat

itisrecycledinamannerthatprotectshumanhealthandtheenvironment.Formoreinformationaboutwhereyoucandropoffyourwaste

equipmentforrecycling,pleasecontactyourlocalcityofce,yourhouseholdwastedisposalserviceorwhereyoupurchasedtheproduct.

E-ite,EC3,Apprentice,ParkZoneandHangar9aretrademarksorregisteredtrademarksofHorizonHobby,Inc.

TheSpektrumtrademarkisusedwithpermissionofBachmannIndustries,Inc.

FutabaisaregisteredtrademarkofFutabaDenshiKogyoKabushikiKaishaCorporationofJapan.

Created10/12 39026

WARRANTY AND SERVICE CONTACT INFORMATION

CountryofPurchase HorizonHobby Address PhoneNumber/EmailAddress

UnitedStatesofAmerica

HorizonServiceCenter

(Electronicsandengines)

4105FieldstoneRd

Champaign,Illinois,61822USA

877-504-0233

OnlineRepairRequest:visit

www.horizonhobby.com/service

HorizonProductSupport

(Allotherproducts)

877-504-0233

productsupport@horizonhobby.com

UnitedKingdom HorizonHobbyLimited

Units1-4,PloytersRd,StapleTye,

Harlow,Essex,CM187NS,United

Kingdom

+44(0)1279641097

sales@horizonhobby.co.uk

Germany

HorizonTechnischer

Service

Christian-Junge-Straße1

25337Elmshorn,Germany

+49(0)41212655100

service@horizonhobby.de

France HorizonHobbySAS

11RueGeorgesCharpak

77127Lieusaint,France

+33(0)160183490

infofrance@horizonhobby.com

China HorizonHobby–China

Room506,No.97ChangshouRd.

Shanghai,China200060

+86(021)51809868

info@horizonhobby.com.cn

PARTS CONTACT INFORMATION

CountryofPurchase HorizonHobby Address PhoneNumber/EmailAddress

UnitedStatesofAmerica Sales

4105FieldstoneRd

Champaign,Illinois,61822USA

800-338-4639

sales@horizonhobby.com

UnitedKingdom HorizonHobbyLimited

Units1-4,PloytersRd,StapleTye

Harlow,Essex,CM187NS,United

Kingdom

+44(0)1279641097

sales@horizonhobby.co.uk

Germany HorizonHobbyGmbH

Christian-Junge-Straße1

25337Elmshorn,Germany

+49(0)41212655100

service@horizonhobby.de

France HorizonHobbySAS

11RueGeorgesCharpak

77127Lieusaint,France

+33(0)160183490

infofrance@horizonhobby.com

China HorizonHobby–China

Room506,No.97ChangshouRd.

Shanghai,China200060

+86(021)51809868

info@horizonhobby.com.cn

Produktspezifikationen

Marke:	E-flite
Kategorie:	ferngesteuertes Spielzeug
Modell:	EFLA1030B
Breite:	28 mm
Gewicht:	31 g
Produkttyp:	ESC
Produktfarbe:	Mehrfarbig
Höhe:	8.7 mm
Typ:	Radio-Controlled (RC) Model Parts
Menge pro Packung:	1 Stück(e)
Vorgesehene Verwendung:	Flugzeug
Kompatibilität:	Taylorcraft 450 ARF\nApprentice S 15e RTF \nApprentice S 15e BNF\nP-51D Mustang BNF Basic
Markenkompatibilität:	E-flite
Beschichtung Steckerkontakte:	Gold
Verbindungstyp:	3.5mm
Battery Eliminator Circuit (BEC) Ausgangsspannung:	5 V
Maximale Anzahl der Zellen kompatibler Akkus:	18
