ECLER TECHNICAL DATA SHEET

1/6

HUB1408

DIGITAL MATRIXES

8 outputs digital zoner with DSP

PRODUCT OVERVIEW

HUB1 is a digital zone manager with inputs and 8 outputs. It has the HANGAR embedded web-server 40814

application (control from standard web browser in Windows / MacOS, etc.) for its configuration; remote control from

physical wall installation panels, call (paging) stations and applications for mobile devices (Android, iOS). Includes DSP

with specific functions for both inputs and outputs.

HUB Series offers multiple possibilities, being intuitive and easy to configure. From the least experienced user to the

most expert, you can set up a professional audio installation in a matter of minutes (Plug & Play). It is the perfect

solution for any type of sound that requires managing and controlling different zones.

KEY FEATURES

•14 inputs, 8 outputs digital zoner with integrated DSP

•Easy programming and control by embedded web

application, HANGAR, and standard web browser

•Control from the front panel and user remote control by:

-eMCONTROL1 wall panels (up to 8)

-eMPAGE paging consoles (up to 2)

-Ecler pilot application, compatible with Android and iOS:

control graphic panels set to user needs (pilot panels)

--NET protocol (RS-232 interface with DB9 connector) TP

for control and integrating with third party systems

•Control available, by zone (output): selection of audio

source (input), volume adjustment and MUTE, 3 band tone

adjustment and general volume

•Four priority levels, ducker/pager functions

•Available DSP: frequency shifter, link stereo, delay,

crossover filters, 8-band graphic EQ, compressor/limiter

and much more

•Predefined setups for a quick installation (plug and play)

•MUTE port can be activated by closing the external dry

contact, affecting programmed outputs to this effect.

APPLICATIONS

• Commercial

• Hospitality

• Education

• Corporate

• Sports and wellness

ACCESSORIES & COMPATIBLE DEVICES

• eMPAGE

• eMCONTROL1

eMPAGE

eMCONTROL1
