Maximum performance, actual data rates, and coverage will vary depending network condions and environmental factors. Product specicaons and design are subject change without noce. onto

Copyright © 2016 Edimax Technology Co. Ltd. All rights reserved.

www.edimax.com

Edimax Technology Co., Ltd

6F., No.3, Wu-Chuan 3rd Road, Wu-, Gu

New Taipei City 24891, Taiwan

Email: [email protected]

Edimax Technology Europe B.V.

Fijenhof 2, 5652 AE Eindhoven,

The Netherlands

Email: [email protected]

Edimax Computer Company

3350 Scott Blvd., Bldg.15 Santa Clara,

CA 95054, USA

Email : [email protected]

SPECIFICATIONS

2.4GHz 12dBi High Gain Single/Dual Polarization

Directional Antenna

ANT-2412D1/ANT-2412D2

Electrical Specications

Frequency Range 2,40

Max. Gain 12d

Antenna Type Uni-directional, Flat Panel

V.S.W.R. 2.0:1 (Max.)

Polarization Linear, Vertical

HPBW / Horizontal

30°

HPBW / Vertical

30°

Front to Back Ratio -20dB (Max.)

Isolation 20dB

Input Impedance 50Ω

Cable CFD200, 1000mm

Connector N-Type x1

Power Handling 10W

Lightning Protection DC Ground

Environmental & Mechanical Characteristics

Temperature

-20 ~ 70 C °

Humidity 95% RH

Radome Color Gray-white

Radome Material ABS

Dimension (L x W x H) 240 x 240 x 40mm

Weight 724g

Weatherproof IP55

Mount Type Pole Mount or Wall Mount

ACCESSORIES

Mounting Brackets Wall-Mount & Pole-Mount Bracket Kit

Specications

Range 2,400 ~ 2,500GHz

12dBi

Antenna Type Uni-directional, Flat Panel

V.S.W.R. 2.0:1 (Max.)

Polarization

Linear, ±90°

HPBW / Horizontal

30°

HPBW / Vertical

30°

Front to Back Ratio -20dB (Max.)

Isolation 20dB

Input Impedance 50Ω

Cable CFD200, 1000mm

Connector N-Type x2

Power Handling 10W

Lightning Protection DC Ground

Environmental & Mechanical Characteristics

Temperature

-20 ~ 70 C °

Humidity 95% RH

Radome Color Gray-white

Radome Material ABS

Dimension (L x W x H) 240 x 240 x 40mm

Weight 747g

Weatherproof IP55

Mount Type Pole Mount or Wall Mount

ACCESSORIES

Mounting Brackets Wall-Mount & Pole-Mount Bracket Kit

ANT-2412D1 ANT-2412D2

FEATURES

•Supports 802.11b/g/n 2.4GHz wireless.

•Provides 12dBi directional operation for point--point, to

high performance and long range connections.

•Works with N Type female connector (1 x ANT-2412D1

& 2 x ANT-2412D2).

•Dual-Polarization to avoid interference (ANT-2412D2).

•Easy installation mounting kit.

•Features IP55-rated housing.

ANT-2412D1 ANT-2412D2
