Elite 6”, 12”, and 18” (L) BracketsType X
For Models: ZVMAXLB6-B/W, ZVMAXLB12-B/W, ZVMAXLB18-B/W
A. A. PARTS
L brackets standard screw and accessories kit
a:
x 2 
SHookbx 2 
JScrewHook
c
x 6 
FlangelessDrill
Size(Drywall
Anchor)
d:
x 6 
PanHeadPhillips
Screw
e
x 2 
Wing Nut f
X 4 
Washer
g
X 2 
Nut  
1 2
3 4
B: 6” (L) bracket dimensions
C: Installation on drywall or ceiling using dry wall anchors (C) only if no studs are found
Examples for mounting (L) bracket to the wall.
1. Drill hole. 2. Insert flangeless anchor into predrilled hole. 3. Place (L) bracket into predrilled hole.
4. Insert pan head Phillips screw into pre-drilled hole for (L) bracket mounting.
D: Examples for hanging your Elite Screen with the (L) bracket a ceiling or ceiling
1. Ceiling Installation
This
side
mounts
to the
wall.
Side of
(L)
bracket
Top of (L) bracket
2. Wall Installation
E: L bracket sliding access and adjusting screen position.
www.elitescreens.com
info@elitescreens.com
techsupport@elitescreens.com
Top of (L) bracket with
sliding access to slide
screen in desired position
Secure J-Screw
hook with wingnut.
J-Screw hook
