Seite 1/2
Pairing on Computer
Quick Start Guide
Pairing on ELPWP20
ON
ON
A
B
USBType-A
D
Pairing on ELPWP10
B
USBType-A
A
ON
C
D
A
Epson Wireless
Transmitter Settings
(Windows/Mac)
epson.sn
B
ON
ON
or
USBType-A
C
Network > Transmitter Settings > Start Pairing
D E
F
USBType-C
USBType-A
or
G H
USB pe-C USB pe-ATy Ty
B
A
ELPAP11
ELPWP10
ELPWP20
ELPAP11
complete
C
complete
complete
About This Guide
This guide explains how to use the Wireless Transmitter ELPWT01.
ELPWT01 is a transmitter that can be added to the Wireless Presentation System
ELPWP10/ELPWP20.
For details on how to use the system, use the QR code on the right to access our
website to see the "Epson Wireless Presentation System User's Guide".
Safety Instructions
Warning
May be a source of electromagnetic interference to cardiac pacemakers and cause them to malfunction.
Before using this unit, check that there is no one in the vicinity using a cardiac pacemaker.
May be a source of electromagnetic interference to sensitive medical equipment and cause them to malfunction.
Before using this unit, check that there is no sensitive medical equipment in the vicinity.
May be a source of electromagnetic interference and cause malfunctions or accidents to occur. Do not use
this unit near automatically controlled equipment such as automatic doors or re alarms.
Do not attempt to disassemble or remodel this transmitter (ELPWT01).
ELPWT01 Specications
Item Specications
Power Consumption 5 VDC / 0.5 A
Operating Temperature 0 to +40°C (Humidity of 20 to 80%, No condensation)
Storage Temperature -20 to +70°C (Humidity of 0 to 95%, No condensation)
Operating Altitude 0 to 3,000 m
Dimensions
Width 63.5 x Height 11 x Depth 175 mm (excluding USB conversion adapter)
Weight Approx. 53 g
Product Parts and Functions
A
USB terminal
B
Indicator
Connects to your computer’s USB
port.
You can use this in two ways:
with the USB conversion adapter
(USB-C) or without (USB-A).
When pairing on a projector,
connect it to the USB-A port.
Flashing blue
quickly
The wireless transmitter is connected to
your computer and is waiting for the Epson
Wireless Presentation software to launch.
Lit blue
The Epson Wireless Presentation software is running.
Flashing blue slowly
Projecting the computer's screen.
Lit orange
An error has occurred. Close the Epson Wireless
Presentation software, and then disconnect
the wireless transmitter from your computer.
EN
EN Before pairing, make network settings for the projector.
FR Avant l’appairage, dénissez les paramètres réseau du projecteur.
DE Kongurieren Sie vor der Kopplung die Netzwerkeinstellungen für den Projektor.
ES Antes de realizar la asociación, realice los ajustes de red del proyector.
IT Prima di eseguire l'abbinamento, congurare le impostazioni di rete del proiettore.
PT Antes de emparelhar, congure as denições de rede do projetor.
TC
配對前,請為投影機進行網路設定。
KO
페어링하기 전에 프로젝터의 네트워크를 설정합니다 .
JA
ペアる前に、プロのネワーを行い。
epson.sn
À propos de ce guide
Ce guide explique comment utiliser l’émetteur sans l ELPWT01.
L’ELPWT01 est un émetteur qui peut être ajouté au système de présentation sans l
ELPWP10/ELPWP20.
Pour plus de détails sur l’utilisation du système, utilisez le code QR à droite an
d’accéder à notre site Web et de consulter le «Epson Wireless Presentation System
Guide de l'utilisateur».
Consignes de sécurité
Avertissement
Peut être une source d’interférences électromagnétiques pour les stimulateurs cardiaques et causer leur dysfonctionnement.
Avant d'utiliser cette unité, assurez-vous qu'aucune personne utilisant un stimulateur cardiaque ne se trouve à proximité.
Peut être une source d’interférences électromagnétiques pour le matériel médical sensible et causer son
dysfonctionnement.
Avant d'utiliser cette unité, assurez-vous qu'elle ne se trouve pas à proximité de matériel médical sensible.
Peut être une source d’interférences électromagnétiques et causer des dysfonctionnements ou des
accidents. N’utilisez pas cette unité à proximité d’équipements à commande automatique tels que des
portes automatiques ou des alarmes incendie.
N’essayez pas de démonter ou de transformer cet émetteur (ELPWT01).
Caractéristiques ELPWT01
Élément Caractéristiques
Consommation électrique 5V CC / 0,5A
Température de fonctionnement 0 à +40°C (Humidité de 20 à 80%, sans condensation)
Température de stockage -20 à +70°C (Humidité de 0 à 95%, sans condensation)
Altitude de fonctionnement 0 à 3000m
Dimensions
Largeur 63,5 x Hauteur 11 x Profondeur 175mm (hors adaptateur de conversion USB)
Poids Env. 53g
Éléments et fonctions du produit
A
Prise USB
B
Indicateur
Se raccorde au port USB de votre
ordinateur.
Vous pouvez l’utiliser de deux
façons: avec l’adaptateur de
conversion USB (USB-C) ou sans
(USB-A).
Lors de l’appairage sur un
projecteur, raccordez-le au port
USB-A.
Clignotement bleu
rapide
Lémetteur sans l est connecté à votre
ordinateur et attend le lancement du logiciel
Epson Wireless Presentation.
Éclairage bleu xe
Le logiciel Epson Wireless Presentation est en
cours d’exécution.
Clignotement bleu
lent
Projection de l’écran de l’ordinateur.
Éclairage orange
xe
Une erreur s'est produite. Fermez le logiciel
Epson Wireless Presentation, puis débranchez
l’émetteur sans l de votre ordinateur.
FR
epson.sn
USB pe-C USB pe-ATy Ty
B
A
© 2021 Seiko Epson Corporation
이 가이드 소개
이 가이드에서는 무선 송신기 ELPWT01 을 사용하는 방법에 대해 설명합니다 .
ELPWT01 은 무선 프레젠테이션 시스템 ELPWP10/ELPWP20 에 추가할 수 있는 송신
기입니다 .
시스템을 사용하는 방법에 대한 자세한 내용은 오른쪽의 QR 코드를 통해 당사 웹사이트
에 액세스하여 "Epson Wireless Presentation System 사용자 가이드 " 를 참조하십시오 .
안전 지침
경고
인공 심장 박동기에 대한 전자파 방해의 원인이 될 수 있으며 , 오작동을 일으킬 수 있습니다 .
이 장치를 사용하기 전에 주변에 심장 박동기를 사용하는 사람이 없는지 확인하십시오 .
민감한 의료기기에 대한 전자파 방해의 원인이 될 수 있으며 , 오작동을 일으킬 수 있습니다 .
이 장치를 사용하기 전에 주변에 민감한 의료기기가 없는지 확인하십시오 .
전자파 방해의 원인이 될 수 있으며 오작동 또는 사고를 일으킬 수 있습니다 . 자동문 또는 화재 알람 등 자동으
로 제어되는 설비 주변에서는 이 장치를 사용하지 마십시오 .
이 송신기를 분해하거나 변경하려고 하지 마십시오 (ELPWT01).
ELPWT01 사양
항목 사양
전력 소모 5VDC / 0.5A
작동 온도 0~+40° C ( 습도 20~80 %, 비응축 )
보관 온도 -20~+70° C ( 습도 0~95 %, 비응축 )
작동 고도 0~3,000m
크기 너비 63.5 x 높이 11 x 깊이 175mm (USB 변환 어댑터 제외 )
무게 약 53g
제품 부품 및 기능
A
USB 단자
B
표시등
컴퓨터의 USB 포트에 연결합니
.
USB 변환 어댑터와 함께
(USB-C) 또는 없이 (USB-A)
같이 두 가지 방법으로 사용할 수
있습니다 .
프로젝터에서 페어링할 때는
USB-A 포트에 연결하십시오 .
파란색으로 빠르게
깜박임
무선 송신기가 컴퓨터에 연결되어 있고 Epson
Wireless Presentation 소프트웨어가 시작될 때까
지 대기하고 있습니다 .
파란색으로 켜짐
Epson Wireless Presentation 소프트웨어가 실행
중입니다 .
파란색으로 천천이
깜박임
컴퓨터 화면을 투사 중입니다 .
주황색으로 켜짐
오류가 발생했습니다 . Epson Wireless
Presentation 소프트웨어를 닫은 후 컴퓨터에서
무선 송신기의 연결을 끊으십시오 .
KO
epson.sn
Sobre este guia
Este guia explica como utilizar o Transmissor Sem Fios ELPWT01.
O ELPWT01 é um transmissor que pode ser adicionado ao Sistema de Apresentação
Sem Fios ELPWP10/ELPWP20.
Para mais detalhes sobre a utilização do sistema, utilize o código QR à direita para
aceder ao nosso website para consultar o “Epson Wireless Presentation System Manual
do Utilizador”.
Instruções de Segurança
Aviso
Pode ser uma fonte de interferência eletromagnética em pacemakers cardíacos e causar a sua avaria.
Antes de utilizar esta unidade, certique-se de que não há ninguém nas proximidades que use um pacemaker
cardíaco.
Pode ser uma fonte de interferência eletromagnética em equipamentos médicos sensíveis e causar a sua avaria.
Antes de utilizar esta unidade, certique-se de que não existe equipamento médico sensível nas proximidades.
Pode ser uma fonte de interferência eletromagnética e causar avarias a sua avaria ou provocar acidentes. Não
utilize este aparelho próximo de equipamentos controlados automaticamente, tais como, portas automáticas ou
alarmes de incêndio.
Não tente desmontar nem modicar este transmissor (ELPWT01).
Especicações do ELPWT01
Item Especicações
Consumo de energia 5 VDC / 0,5 A
Temperatura de funcionamento 0 a +40 °C (humidade de 20 a 80 %, sem condensação)
Temperatura de armazenamento -20 a +70 °C (humidade de 0 a 95 %, sem condensação)
Altitude em funcionamento 0 a 3 000 m
Dimensões
Largura 63,5 x Altura 11 x Profundidade 175 mm (excluindo adaptador de
conversão USB)
Peso Aprox. 53 g
Componentes e funções do produto
A
Terminal USB
B
Indicador
Liga à porta USB do seu
computador.
Pode ser utilizado de duas formas:
com o adaptador de conversão
USB (USB-C) ou sem o adaptador
(USB-A).
Quando emparelhar com um
projetor, ligue-o à porta USB-A.
A piscar
rapidamente em
azul
O transmissor sem os está ligado ao seu
computador e a aguardar que o software Epson
Wireless Presentation seja executado.
Aceso em azul
O software Epson Wireless Presentation está a ser
executado.
A piscar lentamente
em azul
A projetar o ecrã do computador.
Aceso em laranja
Ocorreu um erro. Feche o software Epson Wireless
Presentation e, em seguida, desligue o transmissor
sem os do seu computador.
PT
epson.sn
Informazioni sulla guida
Questa guida spiega come utilizzare il Trasmettitore wireless ELPWT01.
ELPWT01 è un trasmettitore che può essere aggiunto al Sistema di presentazione
wireless ELPWP10/ELPWP20.
Per i dettagli sulle modalità d’uso del sistema, utilizzare il codice QR a destra per
accedere al nostro sito Web per consultare il “Epson Wireless Presentation System
Manuale dell'utente”.
Istruzioni sulla sicurezza
Avvertenza
L’unità può essere fonte di interferenze elettromagnetiche per i pacemaker e provocarne il malfunzionamento.
Prima di utilizzare l'unità, assicurarsi che nelle vicinanze non vi siano persone che utilizzano un pacemaker.
L’unità può essere fonte di interferenze elettromagnetiche per le apparecchiature mediche sensibili e provocarne
il malfunzionamento.
Prima di utilizzare l'unità, assicurarsi che nelle vicinanze non vi siano apparecchiature mediche sensibili.
L’unità può essere fonte di interferenze elettromagnetiche e provocare malfunzionamenti e incidenti. Non
utilizzare l’unità nei pressi di attrezzature automatiche come porte automatiche o allarmi antincendio.
Non smontare o rimodellare il trasmettitore (ELPWT01).
Speciche di ELPWT01
Voce Speciche
Consumo elettrico 5 V CC / 0,5 A
Temperatura di funzionamento Da 0 a + 40 ° C (umidità da 20 a 80 %, senza condensa)
Temperatura di stoccaggio Da -20 a + 70 ° C (umidità da 0 a 95 %, senza condensa)
Altitudine operativa Da 0 a 3.000 m
Dimensioni
Larghezza 63,5 x Altezza 11 x Profondità 175 mm (escluso adattatore di
conversione USB)
Peso Circa 53 g
Parti e funzioni del prodotto
A
Terminale USB
B
Indicatore
Consente di collegarsi alla porta
USB del computer.
È possibile l’uso in due modi: con
l'adattatore di conversione USB
(USB-C) o senza (USB-A).
Quando si abbina un proiettore,
collegarlo alla porta USB-A.
Lampeggiante
rapidamente in blu
Il trasmettitore wireless è connesso al computer
e in attesa dell’avvio del software Epson Wireless
Presentation.
Acceso in blu
Il software Epson Wireless Presentation è in
esecuzione.
Lampeggia
lentamente in blu
Proiezione dello schermo del computer.
Acceso in arancione
Si è vericato un errore. Chiudere il software
Epson Wireless Presentation, quindi scollegare il
trasmettitore wireless dal computer.
IT
epson.sn
Acerca de esta guía
En esta guía se explica cómo usar el transmisor inalámbrico ELPWT01.
ELPWT01 es un transmisor que se puede agregar al sistema de presentación
inalámbrico ELPWP10/ELPWP20.
Para obtener detalles sobre cómo utilizar el sistema, utilice el código QR de la derecha
para acceder a nuestro sitio web y consulte la "Epson Wireless Presentation System
Manual de usuario".
Instrucciones de seguridad
Advertencia
Puede ser una fuente de interferencia electromagnética para los marcapasos y hacer que funcionen mal.
Antes de usar esta unidad, compruebe que ninguna de las personas que le rodean usa marcapasos.
Puede ser una fuente de interferencia electromagnética para los marcapasos y provocar un mal funcionamiento
en ellos.
Antes de usar esta unidad, compruebe que no hay equipos médicos sensibles cerca.
Puede ser una fuente de interferencia electromagnética y provocar averías o accidentes. No utilice esta unidad
cerca de equipos controlados automáticamente, como puertas automáticas o alarmas contra incendios.
No intente desmontar o remodelar este transmisor (ELPWT01).
Especicaciones ELPWT01
Elemento Especicaciones
Consumo eléctrico 5 VCC / 0,5 A
Temperatura de funcionamiento De 0 a +40°C (humedad del 20 al 80 %, sin condensación)
Temperatura de almacenamiento De -20 a +70°C (humedad del 0 al 95%, sin condensación)
Altitud de funcionamiento Entre 0 y 3000 m
Dimensiones
63,5 Ancho x Alto 11 x Fondo 175 mm (excluido el adaptador de conversión
USB)
Peso Aprox. 53 g
Componentes y funciones del producto
A
Terminal USB
B
Indicador
Se conecta al puerto USB de su
PC.
Puede utilizar esto de dos formas:
con el adaptador de conversión
USB (USB-C) o sin él (USB-A).
Al asociar en un proyector,
conéctelo al puerto USB-A.
Parpadeo en azul
rápidamente
El transmisor inalámbrico está conectado al equipo
y está esperando a que el software Epson Wireless
Presentation se inicie.
Azul encendido
Se está ejecutando el software Epson Wireless
Presentation.
Parpadeo en azul
lentamente
Proyectar la pantalla del equipo.
Naranja encendido
Se p2-ha producido un error. Cierre el software Epson
Wireless Presentation y desconecte el transmisor
inalámbrico del equipo.
ES
epson.sn
關於本說明書
明書明如何使用無線器 ELPWT01。
ELPWT01 是可以加入無線簡系統 ELPWP10/ELPWP20 器。
如何使用系統的詳細資訊,請造訪 http://epson.sn取右側 QR
連結至網站,以查無線簡系統 使用說明書」
安全使用須知
警告
是心律調節的電磁干擾來源並導
使件前,請確認鄰近是否有使用起搏器人。
是敏感醫療設的電磁干擾來源並導
使件前,請確認鄰近是否有敏感的醫療設備。
電磁干擾來源並導或意外發生勿在動控制附近使例如或火災報器。
勿嘗或改本傳器 (ELPWT01)。
ELPWT01 規格
項目 規格
5 VDC / 0.5 A
工作溫度 0 +40° C ( 濕度 20 80%未凝)
儲存溫度 -20 +70° C ( 濕度 0 95%未凝)
操作 0 3,000 m
尺寸 寬度 63.5 x 度 11 x 深度 175 mm ( 不含 USB 接器 )
重量 53 g
產品零件與功能
A
USB 端子
B
指示燈
至電腦的 USB 埠。
您可方式使
使 USB 接器 (USB-C) 或
不使 (USB-A)。
在投影機上對時,請連
USB-A 埠。
速閃藍色
無線至電腦候 Epson Wireless
Presentation 軟體啟動。
藍色
Epson Wireless Presentation 軟體正在執
閃爍藍色
投影電腦畫面
亮橘
發生錯誤關閉 Epson Wireless Presentation
軟體,然後從電腦中斷連線無線器。
NCC 警語
取得審驗證明之低功器材,非經核准公司、商或使用者均不得擅自變頻率、加大功更原
設計性及功
低功器材之使不得影響飛航安全及干擾合法;經發現有干擾現象即停用,並改善至無
干擾時方得繼續使。前合法指依管理定作業之無線電通信。低功器材忍受合法
信或工業、學及醫療用電射性備之干擾。
波干擾、 本器材止於屋外使
隨產品所附的 "Epson America, Inc. Limited Warranty." 文件僅適用美國地區使用者
前往 Epson 保固登錄網站解產品保固服務條款以及完成登錄
Epson 保固登錄網 https://www.epson.com.tw/lcpwarranty
危害物質限制指令
單元 限用物質及其化學符號
(Pb)
(Hg)
(Cd)
六價
(Cr
+6
)
多溴聯苯
(PBB)
多溴二苯醚
(PBDE)
電路
外殼
電纜
1.〝○〞係指該項限用物質分比含分比含基準值。
2.〝〞係指該項限用物質為除項目
製造 SEIKO EPSON CORPORATION
地址 3-5, Owa 3-chome, Suwa-shi, Nagano-ken 392-8502 Japan
電話 81-266-52-3131
口商 台灣愛普生科份有公司
地址 台北市信區松仁100 15
電話 (02)8786-6688
TC
epson.sn
Über diese Anleitung
Diese Anleitung erklärt die Nutzung des Drahtlossenders ELPWT01.
ELPWT01 ist ein Sender, der dem Drahtlos-Präsentationssystem ELPWP10/ELPWP20
zugefügt werden kann.
Einzelheiten zur Nutzung des Systems erhalten Sie über den QR-Code auf der rechten
Seite, über den Sie auf „Epson Wireless Presentation System Bedienungsanleitung“
zugreifen können.
Sicherheitsanweisungen
Warnung
Kann bei Herzschrittmachern elektromagnetische Störungen und damit verbunden Fehlfunktionen verursachen.
Stellen Sie deshalb vor der Verwendung dieses Geräts sicher, dass sich keine Person mit einem Herzschrittmacher
in der Nähe bendet.
Kann bei empndlichen medizinischen Geräten elektromagnetische Störungen und damit verbunden
Fehlfunktionen verursachen.
Stellen Sie deshalb vor der Verwendung dieses Geräts sicher, dass sich keine empndlichen medizinischen
Geräte in der Nähe benden.
Kann zu elektromagnetischen Störungen und damit verbunden zu Fehlfunktionen oder Unfällen führen.
Verwenden Sie dieses Gerät nicht in der Nähe automatisch gesteuerter Geräte, wie automatischer Türen oder
Feueralarme.
Versuchen Sie nicht, diesen Sender (ELPWT01) zu demontieren oder umzubauen.
ELPWT01 Technische Daten
Element Technische Daten
Stromverbrauch 5 V Gleichspannung / 0,5 A
Betriebstemperatur 0 bis +40 °C (Feuchtigkeit von 20 bis 80 %, keine Kondensation)
Lagerungstemperatur -20 bis +70 °C (Feuchtigkeit von 0 bis 95 %, keine Kondensation)
Betriebshöhe 0 bis 3.000 m
Abmessungen Breite 63,5 x Höhe 11 x Tiefe 175 mm (ohne USB-Wandler)
Gewicht Ca. 53 g
Produktteile und -funktionen
A
USB-Anschluss
B
Anzeige
Stellt eine Verbindung zum USB-
Anschluss Ihres Computers her.
Sie können dies auf zwei Weisen
nutzen: mit USB-Wandler (USB-C)
oder ohne (USB-A).
Verbinden Sie ihn bei Kopplung
an einem Projektor mit der USB-A-
Buchse.
Blinkt schnell blau
Der Drahtlossender ist mit Ihrem Computer
verbunden und wartet auf die Ausführung der
Software Epson Wireless Presentation.
Leuchtet blau
Die Software Epson Wireless Presentation läuft.
Blinkt langsam blau
Projektion des Computerbildschirms.
Leuchtet orange
Es ist ein Fehler aufgetreten. Schließen Sie die
Software Epson Wireless Presentation, trennen Sie
dann den Drahtlossender von Ihrem Computer.
DE
epson.sn
本書につい
本書はー ELPWT01 の使用方法を説明ていま
ELPWT01 は、ワレスプレゼンンシム ELPWP10/ELPWP20 に追加す
です
しい操作方法については、右記に掲載の『Epson Wireless Presentation System
取扱説明書』をご覧ださい。
安全お使いいめに
警告
心臓ペースメーカーに電磁妨害をおよ、誤作動の原因があます
お使いの前に、心臓ペースメーカーを使用した人が近にいないを確認ださ
医療機器に電磁妨害をおよ、誤作動の原因とながあます
お使いの前に、医療機器が近にないとを確認ださい。
電磁妨害にる誤動作や事故の原因となます。自動や火災報知機などの動制御機器の近で使用
いでい。
ー(ELPWT01)の分解・改造は絶対にしないださい。
ELPWT01 仕様
項目 仕様
消費電 5 VDC / 0.5 A
動作温度範囲 0 40 ℃(湿度 20 80 %、結露ないと)
保存温度範囲 -20 ~ 70 ℃(湿度 0 95 %、結露しなと)
動作高度 0 ~ 3,000 m
外形サ 63.5 × 高さ 11 × 奥行 175 mm(USB 変換アダプ含まず)
質量 53 g
各部の名称
A
USB 端子
B
インジケーター
ピューの USB 子に
USB 変換アダプー有(USB
Type-C)、無(USB Type-A)の二
使い方ができま
ロジターペアグする時
USB-A 端子に接続します
速い青点滅
に接続
し、アプリEpson Wireless Presentation
を待いる態で
青点灯
Epson Wireless Presentation が起
状態です
遅い青点滅
ータ画面を投写している状
橙点灯
異常状態です。Epson Wireless
Presentation せて
からます
JA
epson.jp/lcp/doc/
Türkiye’deki kullanıcılar için
AEEE Yönetmeliğine Uygundur.
Indication of the manufacturer and the importer in accordance
with requirements of EU directive
Manufacturer: SEIKO EPSON CORPORATION
Address: 3-5, Owa 3-chome, Suwa-shi, Nagano-ken
392-8502 Japan
Telephone: 81-266-52-3131
http://www.epson.com/
Importer: EPSON EUROPE B.V.
Address: Atlas Arena, Asia Building,
Hoogoorddreef 5,1101 BA Amsterdam
Zuidoost
The Netherlands
Telephone: 31-20-314-5000
http://www.epson.eu/


Produktspezifikationen

Marke: Epson
Kategorie: Kabelloser Presenter
Modell: ELPWT01
Produkttyp: Transmitter-Modul
Produktfarbe: Grey, White
Warentarifnummer (HS): 85176990
Menge pro Packung: 1 Stück(e)

Brauchst du Hilfe?

Wenn Sie Hilfe mit Epson ELPWT01 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
