Quick Setup

IMPORTANT: Before using this product, make sure you read these instructions

and the safety instructions in the online User’s Guide.

Contents

Make sure your projector box includes all of these parts:

Connect the projector

Choose from the following connections. See the sections below or the online

User’s Guide for details.

Computer

Computer1

HDMI 1

Audio 1

LR

Audio 2

Audio OutMonitorOutRS-232C

Computer 2

Video

USB cable

HDMI cable

VGA cable

Audio cable

HDMI

TM

port

Connect one end of an HDMI cable to the projector’s HDMI port and the other

end to an HDMI port on your computer.

Computer port

Connect one end of a VGA cable to one of the projector’s Computer ports and

the other end to your computer’s monitor port. If you are using a laptop,

switch it to external display (see “Troubleshooting”). You can also connect an

audio cable.

USB port

Connect the square end of a USB cable to the projector’s USB-B (square) port.

Connect the flat end of the cable to any USB port on your computer.

Windows

®

7 or later: After turning on the projector, follow the on-screen

instructions to install the Epson

®

USB Display software (EMP_UDSE.EXE; only

on first connection). If the software screen does not display automatically, open

My Computer, Computer, or This PC, then double-click EPSON_PJ_UD.

OS X 10.8.x or higher: After turning on the projector, the setup folder for USB

Display appears in the Finder. Double-click USB Display Installer and follow

the on-screen instructions to install the Epson USB Display software (only on first

connection). If the software screen does not display automatically, double-click

EPSON_PJ_UD, then double-click USB Display Installer.

Video device

Connect multiple video devices and use the Source Search button on the

projector or remote control to switch between them.

Computer1

HDMI 1

Audio 1

LR

Audio 2

Audio OutMonitorOutRS-232C

Computer 2

Video

RCA video cable

(composite video)

RCA audio cable

HDMI cable

Using the remote control

Install the batteries as shown (two AA batteries).

Choose which

source to display

Turn projector

on and off

Access projector

menus

Turn off projector

display

Access the Home

screen

Navigate projector

menus

For more information on using the remote control, see the online User’s Guide.

Turn on your equipment

1

Plug in the projector.

The power light on

the projector turns blue.

2

Open the A/V Mute slide all the way.

3

Press the power button on the projector

or remote control. The Status light flashes

blue, and then stays on.

Note: To shut down the projector,

press the power button twice.

4

When the Home screen appears, use the arrow and buttons on the

projector or remote control to switch between projection sources and

quickly access various options.

5

The default language of the menu system is English. To select another

language, press the Menu button on the projector or remote control.

Select Extended, select Language, then select your language. Press the

Menu button to exit the menu system.

6

Turn on your computer or video source.

Adjust the image

1

If you don’t see an image, press the Source Search button on the projector

or remote control to select the image source.

Note: If you still see a blank screen or have other display problems, see

“Troubleshooting.”

2

To raise the image, press the foot release button and lift the front of the

projector. Release the button to lock the foot in position.

3

To reduce or enlarge the image, press the E-Zoom buttons on the remote

control.

4

To sharpen the image, turn the focus ring.

5

If your image looks like or , you may have placed the projector off

to one side of the screen at an angle. Place the projector directly in front of

the center of the screen, facing the screen squarely. If you can’t move the

projector, use the horizontal keystone slider on the projector to correct the

image shape.

6

If your image looks like or , press the or button on the

projector to correct it.

Troubleshooting

•

If you see a blank screen, check the following:

•

Make sure the A/V Mute slide is open.

•

Make sure the Status light on the projector is blue and not flashing.

•

Press the power button or the A/V Mute button on the remote

control to wake the projector from standby or sleep mode, if necessary.

•

If you see a blank screen when a computer is connected, check the

following:

•

On Windows, hold down the Windows key and press P at the same

time, then click Duplicate.

•

If you are using a Mac laptop with macOS 13 or newer, select System

Settings > Displays. Select the projector, then choose the mirror

option for your display from the Use as pop-up menu.

On macOS 12, select System Preferences > Displays > Display

Settings. Select the projector, then choose the mirror option for your

display from the drop-down menu.

On macOS 11 and older, open System Preferences and select

Displays. Click the Arrangement tab and select the Mirror Displays

checkbox.

•

If the projector does not respond to remote control commands, make sure

the batteries in the remote control are installed correctly. Replace the

batteries if necessary.

Registration

Scan the QR code to register for product updates and exclusive offers.

Where to get help

Manuals

For more information about using the projector, you can view or download the

manuals from the Epson website, as described below.

Internet support

Visit http://epson.com/support/ple24 (U.S.), http://epson.ca/support/ple24

(Canada), or http://latin.epson.com/support/ple24 (Latin America) to

download software and utilities, view manuals, get FAQs and troubleshooting

advice, or contact Epson.

Telephone support

To use the Epson PrivateLine

TM

Support service, call (800) 637-7661. This service is

available for the duration of your warranty period. You may also speak with a

support specialist by calling (562) 276-4394 (U.S.) or (905) 709-3839 (Canada).

Support hours are 7 a.m. to 4 p.m., Pacific Time, Monday through Friday. Days

and hours of support are subject to change without notice. Toll or long distance

charges may apply.

In Latin America, see the online User’s Guide for technical support information.

Optional accessories

For a list of optional accessories, see the online User’s Guide.

You can purchase screens or other accessories from an Epson-authorized

reseller. To find the nearest reseller in the U.S. or Canada, call 800-GO-EPSON

(800-463-7766). Or you can purchase online at http://epsonstore.com (U.S. sales)

or http://epsonstore.ca (Canadian sales).

To find the nearest reseller in Latin America, go to http://latin.epson.com.

PowerLite

TM

E24

EPSON is a registered trademark and PowerLite is a trademark of Seiko Epson Corporation.

PrivateLine is a trademark of Epson America, Inc.

Mac, macOS, and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.

Windows is a trademark of the Microsoft group of companies.

General Notice: Other product names used herein are for identification purposes only and may be trademarks of

their respective owners. Epson disclaims any and all rights in those marks.

This information is subject to change without notice.

© 2024 Epson America, Inc., 10/24
