Copyright 2021 EtherWAN Systems, Inc. Page 1
All Rights Reserved
EL2242-BT
7/15/2021
EL2242-BT Hardened PoE Media Converter
Installation Guide
1 Unpacking
Unpack the items. Your package should include:
➢ One EL2242-BT PoE Media Converter
➢ Power input terminal block
➢ Wall and DIN-Rail mounting hardware
brackets
If items are missing or damaged, notify your
EtherWAN representative. Keep the carton and
packing material.
More information available at:
https://www.etherwan.com/us
For warranty information, visit:
https://www.etherwan.com/us/support/warrant
y-policy
2 Equipment Needed
➢ Category 5e or better cable for RJ-45 port
➢ SFP Module
➢ Single Mode/Multimode Fiber Cable
➢ Power supply with supplied voltage within
specified range of 52 to 56VDC
3 Select a Location
➢ DIN-rail installations: Attach the bracket on
the unit using the included screws and then
mount on a DIN-rail.
➢ Wall installations: Attach the brackets on the
unit using the included screws and then
mount on a wall.
➢ Identify a power source within 6 feet (1.8
meters).
➢ Choose a dry area with ambient temperature
between -40 and 75ºC (-40 and 167ºF).
➢ Keep away from heat sources, sunlight, warm
air exhausts, hot-air vents, and heaters.
➢ Make sure there is adequate airflow.
4 Connect to the Ports
The EL2242-BT has the following ports:
➢ 1 10/100/1000 Mbps copper port
➢ 1 dedicated 100/1000 SFP slot
10/100/1000BASE-T Port
Port can be connected to a switch, a router or a
PoE device (PD).
SFP Slot
100/1000BASE SFP slot.
5 Connect Power
Terminal Block
Connect the unit to a suitable power supply using
appropriate wire, 18-24AWG, rated for 105°C or
higher.
Redundant power is supported. However, only
one power input is required to operate the unit.
1. Connect power wires to the appropriate
V1+/- or V2+/- pins on the terminal
block.
2. Connect the grounding wire to the ground
screw.
3. Plug the terminal block into the socket.
6 Front Panel LEDs
LED Panel Layout
LED
Color
Status
Power
1 & 2
Green
ON = power detected
OFF = power not detected
PoE
Amber
ON = PD is detected
Off = No PD detected
RJ-45
Link/Act
Green
ON – TX port is detected
FLASHING – TX data is
transmitting
SFP
Link/Act
Green
ON – FX port is detected
FLASHING – FX data is
transmitting/receiving
