User's Guide
0 to 10% Brix Refractometer
Model RF16
Introduction
Congratulations on your purchase of the Extech RF16 Brix Refractometer.
Precision optical instruments should be handled gently; avoid touching the
optical surface. Careful use of these instruments will provide years of
reliable service.
Specifications
Range 0 to 10% Brix
Resolution 0.1%
Dimensions 7.5 x 1.6 x 1.2" (190 x 40 x 30mm);
Weight 5.5 oz. (155g)
Description
1. Eyepiece
2. Mirror Tube
3. Adjustment screw
4. Cover Plate
5. Prism
Operation
This instrument measures the refractive index of a sample. The measurement
is displayed in % Brix.
1. Zero Adjustment
Allow the refractometer and the distilled water to stabilize at room
temperature. Cover the prism with a few drops of distilled water from the
included vial. Close the cover plate and rotate the adjustment screw until
the light/dark boundary (shadowline) lines up with the zero line. After the
zero adjustment, clean the prism with a soft cloth. The instrument is now
calibrated for the current ambient room temperature.
2. Sample Preparation and Reading
To take a sample reading, simply place a few drops of a sample liquid on
the measurement prism at the end
of the instrument. Close the prism
cover plate so that the liquid
spreads across the entire surface of
the prism without air bubbles or dry
spots. Allow the sample to remain
on the prism for approximately 30
seconds.
While holding the instrument under
a light source, look through the
eyepiece. The sucrose
concentration is determined by the intersection of the boundary of the light
and dark fields (known as the shadowline) on the printed scale. If the scale
appears out of focus, the eyepiece may be adjusted by rotating the knurled
portion of the eyepiece. The instrument also features an eye-guard to
prevent stray light from entering the eyepiece and causing reflections.
It may be necessary to adjust the position of the light source to maximize
the contrast of the shadowline. Under normal conditions, optimal contrast
is obtained by holding the instrument underneath and perpendicular to a
light source.
Once a reading has been taken, wipe dry with a clean cloth (do not wash
or rinse) and place the instrument in the supplied plastic case. Store the
instrument in a safe, dry environment.
Note: Ambient temperature should remain constant for accurate
measurments. If room temperature changes, recalibrate the instrument.
3. Temperature Compensation
Temperature is one of the single most important factors influencing
accurate refractometer readings and is one of the largest sources of
measurement error. Temperature compensation relieves the user of the
responsibility to measure temperature and apply a correction factor when
taking readings.
The RF16 Refractometer has been designed for use with a 20°C standard
temperature. Therefore, if the temperature of the measurement deviates
from 20°C, the reading must be manually compensated in accordance
with the Temperature Compensation Table.
Example: A reading of 20% at 28°C is compensated thusly: 20% +
0.62%=20.62%.
Temperature Compensation Table (Referenced To 20
O
C)
%
5 10 15 20 25 30 35 40 45 50 55 60 65 70
o
C
Subtract the following from the measurement
10
0.58
0.59
0.61
0.64
0.67
0.69
0.71
0.72
0.74
0.74
0.74
0.75 0.76 0.77
11
0.51
0.54
0.55
0.58
0.61
0.63
0.65
0.65
0.67
0.67
0.67
0.68 0.68 0.69
12
0.47
0.49
0.50
0.52
0.55
0.57
0.58
0.58
0.60
0.60
0.60
0.60 0.61 0.61
13
0.42
0.44
0.44
0.45
0.49
0.50
0.51
0.51
0.53
0.53
0.53
0.53 0.53 0.53
14
0.37
0.38
0.39
0.40
0.42
0.43
0.44
0.44
0.45
0.45
0.45
0.45 0.45 0.46
15
0.31
0.32
0.33
0.34
0.35
0.36
0.37
0.37
0.38
0.38
0.38
0.38 0.38 0.38
16
0.25
0.26
0.27
0.28
0.28
0.29
0.30
0.30
0.30
0.31
0.31
0.31 0.31 0.31
17
0.19
0.20
'0.20
0.21
0.21
0.22
0.22
0.23
0.23
0.23
0.23
0.23 0.23 0.23
18
0.13
0.13
0.14
0.14
0.14
0.15
0.15
0.15
0.15
0.15
0.15
0.15 0.15 0.15
19
0.06
0.07
0.07
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.08
0.08 0.08 0.08
Add the following to the measurement
21
0.07
0.07
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.08
0.08
0.08 0.08 0.08
22
0.14
0.14
0.14
0.14
0.15
0.15
0.16
0.16
0.16
0.16
0.16
0.16 0.16 0.15
23
0.21
0.21
0.22
0.22
0.23
0.23
0.23
0.23
0.24
0.24
0.24
0.24 0.23 0.22
24
0.28
0.29
0.29
0.30
0.30
0.31
0.31
0.31
0.31
0.31
0.32
0.32 0.31 0.31
25
0.35
0.36
0.37
0.38
0.38
0.39
0.39
0.40
0.40
0.40
0.40
0.40 0.39 0.39
26
0.43
0.44
0.44
0.46
0.46
0.47
0.47
0.48
0.48
0.48
0.48
0.48 0.47 0.47
27
0.51
0.52
0.53
0.54
0.55
0.55
0.56
0.56
0.56
0.56
0.56
0.56 0.55 0.55
28
0.59
0.60
0.61
0.62
0.63
0.64
0.64
0.65
0.65
0.64
0.64
0.64 0.64 0.63
29
0.67
0.68
0.69
0.70
0.71
0.72
0.73
0.73
0.73
0.73
0.73
0.72 0.72 0.71
30
0.75
0.77
0.78
0.79
'0.80
'0.81
0.81
0.81
0.82
0.81
0.81
0.81 0.80 0.79
Source: International Commission for Uniform Methods of Sugar Analysis (1966)
International Brix% Scale
Brix to Refractive Index (nD) Conversion Table
% nD % nD
0 1.333 6 1.3418
1 1.3344 7 1.3433
2 1.3359 8 1.3448
3 1.3373 9 1.3463
4 1.3388 10 1.3478
Source: International Sugar Analysis Committee
Warranty
FLIRSystems,Inc.warrantsthisExtechInstrumentsbranddevice to be free of defects inparts
and dateworkmanshipfor from oneyear of (a monthshipment six limitedwarrantyappliesto
sensorsandcables). becomeIfitshould necessaryto thereturn instrumentforserviceduringor
beyond contactthewarrantyperiod, theCustomerServiceDepartmentforauthorization.Visit
thewebsitewww.extech.comforcontactinformation. A ReturnAuthorization(RA) mustnumber
be any freight,issuedbefore productis isreturned.Thesender responsibleforshippingcharges,
insuranceandproperpackagingto topreventdamage does notintransit.Thiswarranty apply
defects action asresultingfrom oftheusersuch misuse,improperwiring, ofoperationoutside
specification,impropermaintenance or or repair, unauthorizedmodification.FLIRSystems,Inc.
specificallydisclaimsany forimpliedwarrantiesor ormerchantability fitness a specificpurpose
and be anywillnot liablefor direct,indirect,incidentalorconsequentialdamages.FLIR’stotal
liabilityis islimitedtorepairor ofreplacement theproduct.Thewarranty abovesetforth
inclusiveand no otherwarranty,whetherwrittenor ororal,isexpressed implied.
Copyright ©2008 2015‐ FLIRSystems,Inc.
Allrightsreservedincludingtherightof orreproductioninwhole in inpart any
form
www.extech.com
X X
12
3
4
5
Support 439 8324;Lines:U.S.(877) ‐ International:+1 ‐ (603) 324 7800
TechnicalSupport:Option3; ‐E mail:support@extech.com
Repair & Returns:Option4; ‐E mail:repair@extech.com
Productspecificationsaresubjecttochangewithoutnotice
Pleasevisitourwebsiteforthe datemostup‐to‐ information
www.extech.com
FLIRCommercialSystems,Inc.,9
Townsend West, Nashua,NH03063USA
ISO9001Certifie
d
