GETTINGSTARTED

FLIR

CHAMELEON®3

USB3



Vision

Willyoursystemsupportthecamera?

RecommendedSystemConfiguration:

nOS—Windows,Linux(32-and64-bit)

nCPU—IntelCore2Duo,orequivalent

nRAM—2GBRAM

nVideo—128MB

nPorts—PCIe2.0compatiblehostcontrollerwithUSB3.1connector

nSoftware—MicrosoftVisualStudio2010(tocompileandrunexample

code)

SeeTechnicalApplicationNote10359forinformationonrecommendedsystem

componentsforUSB3.0.

Doyouhaveadownloadsaccount?

Ourdownloadspagehasmanyresourcestohelpyouoperateyourcamera

effectively,including:

nSoftware,includingDrivers(requiredforinstallation)

nFirmwareupdatesandreleasenotes

nDimensionaldrawingsandCADmodels

nDocumentation

Toaccessthedownloadsresourcesyoumusthaveadownloadsaccount.

1.Gotoourwebsite:www.flir.com/iis.

2.Intheupperrightcorner,clickRegister.

3.Completetheform,thenclickRegister.

Afteryousubmityourregistration,youwillreceiveanemailwithinstructionson

howtoactivateyouraccount.

Doyouhaveallthepartsyouneed?

Toinstallyourcamerayouwillneedthefollowingcomponents:

nUSB3.1cable

nLens

nTripodadapter(optional)

nInterfacecard

FLIRsellsanumberoftheadditionalpartsrequiredforinstallation.Topurchase,

visitourAccessoriespage.

CameraCare

Tocleantheimagingsurfaceofyourcamera,followthestepsoutlinedin

KnowledgeBaseArticle10243.

Extendedexposuretobrightsunlight,rain,dustyenvironments,etc.maycause

problemswiththeelectronicsandopticsofthesystem.

Avoidexcessiveshaking,dropping,ormishandlingofthedevice.

Warning!Donotopenthecamerahousing.DoingsovoidstheHardware

Warranty.

Avoidelectrostaticcharging.

InstallingYourInterfaceCardandSoftware

1.InstallyourInterfaceCard

Ensurethecardisinstalledperthe

manufacturer'sinstructions.

ConnecttheinternalIDEorSATApower

connectoronthecardtothecomputer

powersupply.

Alternatively,useyourPC'sbuilt-inhost

controller,ifequipped.

OpentheWindowsDeviceManager.Ensurethecardisproperlyinstalledunder

UniversalSerialBusControllers.Anexclamationpoint(!)nexttothecard

indicatesthedriverhasnotyetbeeninstalled.

2.InstalltheFlyCapture®Software

Note:ForexistinguserswhoalreadyhaveFlyCaptureinstalled,we

recommendensuringyouhavethelatestversionforoptimalperformance

ofyourcamera.IfyoudonotneedtoinstallFlyCapture,usethe

DriverControlGUItoinstallandenabledriversforyourcard.

a.Logintoourdownloadspage.

b.SelectyourCameraandOperatingSystemfromthedrop-downlistsand

clicktheSearchbutton.

c.ClickontheSoftwaresearchresultstoexpandthelist.

d.Clicktheappropriatelinktobeginthedownloadandinstallation.

Afterthedownloadiscomplete,theFlyCapturesetupwizardbegins.Ifthe

wizarddoesnotstartautomatically,double-clickthe.exefiletoopenit.Follow

thestepsineachsetupdialog.

3.EnabletheDriversforthecard

Duringinstallation,youarepromptedtoselectyourinterfacedriver.

IntheInterfaceDriverSelectiondialog,selecttheIwilluseUSBcameras.

Thisselectionensuresthepgrxhci(USBPro)andpgrusbcamdriversare

installed.

Touninstallorreconfigurethedriveratanytimeaftersetupiscomplete,usethe

DriverControlGUI.

1/26/2017

Namesandmarksappearingontheproductshereinareeither

registeredtrademarksortrademarksofFLIRSystems,Inc.

and/oritssubsidiaries.

©2015-2017FLIRIntegratedImagingSolutionsInc.Allrights

reserved.
