Seite 1/14
INSTRUCTION MANUAL
MODE D'EMPLOI
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
HANDLEIDING
MANUAL DE INSTRUÇÕES
MULTI-COLOR UNDERWATER SPOTLIGHT
LAMPE À DEL SUBMERSIBLE À FAISCEAU
ÉTROIT MULTICOLORE
MEHRFARBIGE UNTERWASSER-SPOTLAMPE
FOCO MULTICOLOR SUMERGIBLE
MEERKLEURIGE ONDERWATERSCHIJNWERPER
PROJETOR SUBMERSO MULTICOLOR
LED
PRIS
M 2.0
EN
IMPORTANT SAFETY INSTRUCTIONS
WARNING – To guard against injury, basic safety precautions should be observed, including
the following:
1.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
and all the important notices on the appliance before using. Failure to do so may result in loss of fish
life and/or damage to this appliance.
2. DANGER – To avoid possible electric shock, special care should be taken since water is employed
in the use of aquarium equipment. For each of the following situations, do not attempt repairs
yourself; return the appliance to an authorized service facility for service or discard the appliance.
A. If the appliance shows any sign of abnormal water leakage, immediately unplug it from the
power source.
B. Carefully examine the appliance after installation. It should not be plugged in if there is water
on parts not intended to be wet. If the appliance or any part of it falls into the water DO NOT
reach for it First unplug the unit before retrieving..
C. Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning or it is
dropped or damaged in any manner. The power cord of this appliance cannot be replaced; if the
cord is damaged, the appliance should be discarded. Never cut the cord.
D. To avoid the possibility of the appliance plug or receptacle getting wet, position the appliance
to one side of a wall mounted receptacle to prevent water
from dripping onto the receptacle or plug. A “drip loop”
(see illustration) should be arranged by the user for the
cord connecting appliance to a receptacle. “The drip
loop” is that part of the cord below the level of the
receptacle or the connector if an extension cord is used,
to prevent water traveling along the cord and coming in
contact with the receptacle. If the plug or receptacle
does get wet, unplug the cord. Disconnect the DO NOT
fuse or circuit breaker that supplies power to the
appliance. Then unplug and examine for presence of water in receptacle.
3. This appliance is not intended for use by persons (including children) with significantly impaired
physical or mental capabilities, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety. Children should always be
supervised to ensure that they do not play with the appliance.
4. To avoid injury, do not touch moving parts or hot parts.
5. CAUTION - Always unplug or disconnect all appliances in the aquarium from electricity supply
before placing hands in water, before putting on or taking off parts and while the equipment is
being installed, maintained or handled. Never yank cord to pull plug from outlet. Grasp the plug and
pull to disconnect. Always unplug an appliance from an outlet when not in use.
6. Do not install or store the appliance where it will be exposed to weather or temperatures below
freezing. FOR INDOOR HOUSEHOLD USE ONLY.
7. Make sure the appliance is mounted correctly and securely positioned on the aquarium before
operating the appliance.
8. If an extension cord is necessary, a cord with proper rating should be used. A cord rated for less
amperes or watts than the appliance rating may overheat. Care should be taken to arrange the
cord so that it will not be tripped over or pulled. The connection should be carried out by a qualified
electrical installer.
9. The socket-outlet shall be installed near the equipment and shall be easily accessible.
10. LED power supply shall not be positioned on or into the cover frame.
11. “Z” attachments: The external flexible cable or cord of this luminaire cannot be replaced; if cord
is damaged the luminaire shall be destroyed.
12. ATTENTION: The light source of this luminaire is not replaceable; when the light source reaches
its end of life the whole luminaire shall be replaced.
13. ATTENTION: Do not stare at the operating light source.
SAVE THESE INSTRUCTIONS
For the complete use and understanding of this product it is recommended that this manual is
thoroughly read and understood. Failure to do so may result in damage to this product.
The Fluval Prism is a remote-controlled, high-output spotlight LED that allows the user to
create up to 80 multi-color lighting options, including special effects, to match any décor or
desired mood effect.
INSTALLATION AND USAGE:
Please verify that all components of the light fixture are undamaged before putting it into
operation. Before any kind of maintenance, always disconnect electrical supply of the light
fixture.
IMPORTANT: The Fluval Prism is designed to work only when fully submerged in water. Do
not operate dry.
• Affix light fixture to the inside glass of the aquarium.
Illustration 1
(See illustration 1)
Note: Light fixture should be positioned so that
it will illuminate the tank and its inhabitants.
• Ensure there is a direct line-of-sight between the
fixture’s sensor and the remote control. Press suction
cup firmly against the glass to ensure proper adhesion.
Note: Make sure the light fixture is mounted correctly
and securely positioned on the aquarium before
operating the appliance.
• Connect the plug to the electrical supply.
REMOTE CONTROL:
• Remove plastic cover from wireless remote; remove the clear plastic tab located at the
bottom of the remote to activate the battery
Illustration 2
connection (the remote should already have the
battery included).
• Ensure there is a direct line-of-sight between the
fixture’s sensor and the remote control.
(See illustration 2)
Sensor module can be affixed 2 ways:
• Remove red peel-away sticker cover and press
module (sticky side facing glass) firmly against side
of aquarium
• Thread screws (sold separately) through sensor
module's 2 molded holes and screw into side of cabinet/stand.
To operate:
• Point the remote so that the infrared sensor on the remote activates the sensor on the
light fixture.
To change the battery:
Battery compartment is located on back of remote, to open:
• Slide “Release” tab to the right while
gently pulling out the battery door.
• Insert (1) 3V battery
• Gently push battery door closed.
Remote Control Keypad Functions
a) Power: Press these buttons to turn LED on or off
b) Brightness (+ / - ): Press these buttons to increase or
decrease light intensity
c) R/G/B/W LED color: Press any of these buttons to add or
remove red, green, blue or white and to adjust the color
intensity
d) Special Effects: Press any of these buttons to add
special lighting effects
e) All color spectral cycle: Setting slowly cycles through
every color spectrum
MAINTENANCE:
For maximum LED performance, it is recommended that the fixture and the LED lens be
cleaned on a weekly basis. Unplug transformer prior to cleaning the light fixture and remove
from aquarium. Wipe exposed surfaces carefully with a damp cloth to remove any mineral
deposits that may collect over time. Do not use detergents or harsh cleaners as it can damage
the light fixture. Make sure wires are dry before re-connecting to the power source.
BASIC TROUBLE-SHOOTING:
If the fixture does not work, ensure that all plugs and wires are firmly connected.
WARRANTY
2 YEAR LIMITED WARRANTY
Your Fluval Prism LED is guaranteed for defective parts and workmanship for a period of 2 years
from the date of purchase. This guarantee is valid with proof of purchase only. The guarantee
is limited to repair or replacement only and does not cover consequential loss, loss or damage
to livestock and personal property or damage to animate or inanimate objects, irrespective
of the cause thereof. This guarantee is valid only under normal operating conditions for
which the unit is intended. It excludes any damage caused by unreasonable use, negligence,
improper installation, tampering, abuse or commercial use. The warranty does not cover wear
and tear or parts which have not been adequately or correctly maintained. THIS DOES NOT
AFFECT YOUR STATUTORY RIGHTS.
FOR AUTHORIZED WARRANTY REPAIR SERVICE:
For Authorized Warranty Service please return (well packaged and by registered post) to
the address below enclosing dated receipt and reason for return. If you have any queries or
comments about the operation of this product, please let us try to help you before you return
the product to your retailer. Most queries can be handled promptly with a phone call. When
you call (or write), please have all relevant information such as model number, age of product,
details of aquarium set-up, as well as the nature of the problem.
CANADA: Consumer Repair, Rolf C. Hagen Inc., 20500 Trans Canada Hwy,
Baie d’Urfé, QC H9X 0A2
U.S.A.: Rolf C. Hagen (U.S.A.) Corp., 305 Forbes Blvd, Mansfield, MA. 02048
UK: Rolf C. Hagen (UK) Ltd, Customer Service Department California Drive, Whitwood Ind
Est., Castleford West Yorkshire WF10 5QH http://faq.hagencrm.com/?uk
CALL US ON OUR TOLL-FREE NUMBER:
CANADA ONLY: 1-800-554-2436 between 9:00 a.m. and 4:30 p.m. Eastern Standard Time.
Ask for Customer Service.
U.S. ONLY: 1-800-724-2436 between 9:00 a.m. and 4:00 p.m. Eastern Standard Time.
Ask for Customer Service.
U.K. ONLY: Helpline Number 01977 521015. Between 9:00 AM and 5:00 PM, Monday to
Thursday and 9:00 AM and 4:00 PM on Friday (excluding Bank Holidays).
RECYCLING: This symbol bears the selective sorting symbol for waste electrical and
electronic equipment (WEEE). This means that this product must be handled pursuant
to European Directive 2012/19/EU in order to be recycled or dismantled to minimize its
impact on the environment. Check with your local Environmental Agency for possible
disposal instructions or take to an official council registered refuse collection point.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of hazardous
substances.
c
a
b
d
e
