5700-03 / 5700-05

crossbar.

Crossbar (B) contains several pairs of threaded holes. Find the pair of holes that match the spacing of the holes on the junction box and on

your fixture’s backplate. Two of mounting screws (A) should be attached to crossbar (B). You may need to tighten the nuts that hold these

screws in place. Pull the house wires through the center of crossbar (B). Place crossbar (B) against the junction box so that mounting screws

(A) are aligned with the hole locations on fixture’s backplate (F). Secure crossbar (B) to the junciton box by securely tightening the mounting

screws (D).

crossbar (B) and wrap

the fixture’s ground wire around the green ground screw (E). Use a screwdriver to secure ground screw (E) onto the crossbar. Tuck all wires

neatly into the junction box.

Place the fixture’s backplate (F) against mounting screws (A) so that they protrude through the holes on the backplate. Screw deco nuts (G)

onto mounting screws (A). Twist until the backplate of the fixture is snugly against the wall. Secure glass (I) onto the socket (H) by screwing

socket ring (J) tight. Install light bulb (not included) in accordance with the fixture’s specifications. Do not exceed the recommended maximum

wattage.
