HANDLEBARCONTROLLER

INSTALLATION INSTRUCTIONS

Important Safety Information

Important Safety Information

Important Safety Information

Important Safety InformationImportant Safety Information

WARNING

See the guide in the product box for product warnings and other Important Safety and Product Information

important information.

Installing the Controller on the Handlebar

Installing the Controller on the Handlebar

Installing the Controller on the Handlebar

Installing the Controller on the HandlebarInstalling the Controller on the Handlebar

The handlebar controller is packaged with three bushings, designed for 22mm (7/

8

in.), 25mm (1 in.), and

32mm (1

1

/

4

in.) diameter handlebars.

We recommend installing the handlebar controller close to the left handle of your vehicle, within reach of your

thumb.

1 Place the bushing on the handlebar, in the mounting location for the controller.

2 Place the handlebar controller mounting clamp over the bushing, making sure the ridges on the bushing

match up with the grooves in the mounting clamp.

3 Using the included hex wrench, install the included screw .

GUID-997F4A1C-BE0A-414F-8A9E-CFFD210096DF v1

November 2024
