GARMINSPECTRA

™

LED MODULE CONTROL

INSTALLATION INSTRUCTIONS

Important Safety Information

Important Safety Information

Important Safety Information

Important Safety InformationImportant Safety Information

WARNING

See the guide in the product box for product warnings and other Important Safety and Product Information

important information.

Failure to install this device according to these instructions could result in personal injury, damage to the vessel

or device, or poor product performance.

CAUTION

To avoid possible personal injury or damage to the device and vessel, disconnect the vessel's power supply

before beginning to install the device.

To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,

cutting, or sanding.

NOTICE

When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.

You must read all installation instructions before beginning the installation. If you experience difficulty during

the installation, go to .support.garmin.com

Tools and Supplies Needed

Tools and Supplies Needed

Tools and Supplies Needed

Tools and Supplies NeededTools and Supplies Needed

•16AWG (1.3mm

2

) wire to connect the wiring harness to power

•Inline fuse apporpriately-rated for the power source and connected LEDs ().Connecting to Power, page4

•20AWG (0.5mm

2

) wire to connect the wiring harness to lighting

You can purchase marine LED cable from your Fusion

®

or Garmin

®

dealer in 100m (328ft.) lengths

(010-13386-00).

•#2 Phillips screwdriver

•Appropriately sized marine-grade connectors for connecting the wiring harnesses to the speaker wire

•Wire cutters

•Drill and 2 mm (

3

/

32

in.) drill bit for mounting the LED control module

Getting Started

Getting Started

Getting Started

Getting StartedGetting Started

The Garmin Spectra LED control module allows you to control connected LED lights using compatible Garmin

chartplotters and compatible Fusion stereos connected to the same NMEA 2000

®

network. You can also control

connected LED lights using the ActiveCaptain

®

app.

The Garmin Spectra LED control module is designed for controlling only LED lighting. You must not use this

device to control navigation lights, non-LED lighting, or other devices.

This manual contains instructions for installing and performing the initial configuration for the Garmin Spectra

LED control module using a Garmin chartplotter or ActiveCaptain app. For complete instructions on using the

Garmin Spectra LED control module with a connected chartplotter or Fusion stereo, see the latest chartplotter or

stereo owner's manual.

GUID-6A3E1D9B-1E17-4069-BF5C-3C82F2202A9B v2

September 2024
