Seite 1/10
INSTRUCTION MANUAL
999 4730.7 © 2002 Greenlee Textron 8/02
Read understand and all of the instructions and
safety information in this manual before operating
or servicing this tool.
Quick Draw
®
Hydraulic Punch Drivers
Serial Codes AHJ, YZ, and ZA
7904SB / 7906SB
Quick Draw 90
®
7704SB / 7706SB
Quick Draw Flex™
7804SB / 7806SB
Quick Draw
®
Quick Draw
®
Hydraulic Punch Drivers
Greenlee Textron / Subsidiary of Textron Inc. 24455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose of this Manual .................................................. 2
Other Publications .......................................................... 2
Important Safety Information ...................................... 3–4
Specications ................................................................. 5
Capacity and Draw Stud Selection Guide ...................... 6
Operation ....................................................................... 7
Maintenance................................................................... 8
Troubleshooting ............................................................. 9
Draw Studs and Accessories ....................................... 10
All specications are nominal and may change as design improve-
ments occur. Greenlee Textron shall not be liable for damages
resulting from misapplication or misuse of its products.
Quick Draw Flex is a trademark and Quick Draw, Quick Draw 90,
Slug-Buster, and Slug-Splitter are registered trademarks of
Greenlee Textron.
KEEP THIS MANUAL
Description
The Quick Draw
®
punch drivers are self-contained
hydraulic tools.
These punch drivers, when used with Greenlee
punches, dies, and draw studs, form a complete system
for punching holes of various shapes and sizes through
mild steel, aluminum, berglass, and plastic.
Slug-Splitter
®
punches, dies, and studs are available for
punching all of these materials as well as stainless steel.
In addition, the 7704SB / 7706SB punch driver has a
exible body that allows hole punching at a variety of
angles. The handle and release mechanisms rotate
nearly 360 for convenient actuation.°
Safety
Safety is essential in the use and maintenance of
Greenlee tools and equipment. This manual and any
markings on the tool provide information for avoiding
hazards and unsafe practices related to the use of this
tool. Observe all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel with
the safe operation and maintenance procedures for the
following Greenlee hydraulic punch drivers:
7704SB / 7706SB Quick Draw Flex™
7804SB / 7806SB Quick Draw
®
7904SB / 7906SB Quick Draw 90
®
Keep this manual available to all personnel.
Replacement manuals are available upon request at
no charge.
Other Publications
Service Manual:
7704SB / 7706SB: Publication 999 4732.3
7804SB / 7806SB: Publication 999 4732.3
7904SB / 7906SB: Publication 999 4731.5
Quick Draw
®
Hydraulic Punch Drivers
Greenlee Textron / Subsidiary of Textron Inc. 34455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070
IMPORTANT SAFETY INFORMATION
Read and understand all of the
instructions and safety information in
this manual before operating or
servicing this tool.
Failure to observe this warning can
result in severe injury or death.
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury or
property damage. The signal word, dened below,
indicates the severity of the hazard. The message
after the signal word provides information for
preventing or avoiding the hazard.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Hazards which, if not avoided, COULD result in
severe injury or death.
Immediate hazards which, if not avoided, WILL
result in severe injury or death.
SAFETY
ALERT
SYMBOL
Electric shock hazard:
Do not use this tool near live circuits.
This includes, but is not limited to,
the following:
•Near circuit breaker panels or fuse
boxes with energized circuits
•Near junction boxes with
energized circuits
Failure to observe this warning can
result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection can
result in serious eye injury from
ying debris.
