Seite 1/8
DSP SERIES
10- D P cChannel igital Sound ro essor
GZDSP 6-10SQ
Qu
Qu
Qu
QuQuick
ick
ick
ickickst
st
st
ststart Gu
art Gu
art Gu
art Guart Guide
ide
ide
ideide
AWV4.2
GROUND ZERO GZDSP 6- 10SQ
DSP SERIES
General i nformation
The information and advice contained in this guide may be deviate from the delivery condition of the device.
This is due to constant further development of the product.
Content
• GZDSP 6- 10SQ
•
USB cable, type A to type B (1,5 m)
• Power supply and high- level input harness
• Built- a a in BT ntenn
• Quickstart Guide
Safety
• As a precaution, it is recommended to disconnect the vehicles battery before mounting the . (Note: For DSP
new vehicles, disconnecting the battery might cause various errors in your vehicle´s electric system that can
be cleared only by authorized service partners of your vehicle´s manufacturer! Please ask your service
partner first before disconnecting the battery!)
• The power supply wire (+12 V) has to be protected within max. 20 cm / 8” by a main fuse holder with a
fuse value matching the recommendation for your amplifier
(Note: If there is more than one DSP connected using this power wire, the main fuse value must be equal to
the sum of the recommended fuses of all connected devices. However, make sure the diameter of your
power wire will be sufficient for the required current!)
• If necessary, replace a defective fuse by a fuse with identical quality and value
• Never drill a hole to the vehicle´s gas tank or brake lines, to wirings or any other important vehicle parts!
• Never pass wires over sharp edges or vehicle parts to avoid any kind of damage
• Keep the wiring away from the antenna and electronic devices contributing to radio reception
• Lay the power supply wiring always separated from speaker wiring to avoid disturbance
GROUND ZERO GZDSP 6- 10SQ
DSP SERIES
Specifications
• Digital signal processor (DSP)
• High Performance Analog Devices SigmaDSP Audio Processor
• Premium DAC with differential signal routing
• High- -quality OP amps with lowest noise and distortion behaviour
• 6- channel line input (RCA)
• 6- - - channel high level input (with auto on function)
• Coaxial S/ and optical PDIF input
• 10- channel line output (RCA)
• Realtime setup of all functions (via PC or app)
• Simple handling graphical user interface (Windows® compatible)
• Input equalizer (7 bands per source)
• Input channel time alignment
• Output equalizer (10 x 31 bands)
• Time alignment (0- - - 20 ms / 0 692 cm / 0 272”) for each channel
• Adjustable crossover (HPF / LPF / BPF from 20 Hz to 20 kHz)
• Selectable crossover slope (6 to 48 dB/oct)
• 3 filter characteristics (Butterworth/Bessel/Linkwitz-Riley)
• Selectable phase shift for each channel (0˚ or 180°)
• Memory for 10 user presets (selectable via remote control, PC or app)
• Group selectable EQ settings
• Optional wired remote control GZREM 6- 10 available separately
• BT 5.0 for wireless music streaming and DSP settings
Product escriptiond
The GZDSP 6-10SQ is a digital signal processor that can significantly improve the sound quality of a car
music system under certain conditions. The basis for this is a 32-bit SigmaDSP in conjunction with six 32-bit
analog- -to digital and ten digital- -to analog converters. Thanks to the free combination of up to 6 input
channels and a 31-band equalizer for each output channel, the GZDSP 6-10SQ can be integrated into almost
any factory system. -The source specific, 7-band input equalizer also helps optimize the input signal.
In addition to the 6 analog high level connections, the GZDSP 6- -and low -10SQ also offers an optical, digital
and BT interface.
App control & music streaming
To use your mobile device controlling the unit and changing the adjustments, please install the GROUND ZERO
GZDSP 10SQ6- control app on your device (Android / iOS) and connect the separately available music
streaming interface. Check the web page for further information and to download the app´s owner´s manual.
Terms of warranty
The limited warranty for this product is covered by GROUND ZERO´s regional distribution partners and their
terms and conditions. For further information contact your local retailer or distributor.
