00K

%P

WIFI RESET

2300K6800K

CCT

MINMAX

INTENSITY

LED-480LS / GVM-560AS

160.00 mm

120.00 mm

封底封面

封底和封面内页留白，书本形式

Battery

installation slot

Adapter interface

135678

（Battery lead）

24

CONTENTS

Product introduction Page 1-------------------------------------------

Disclaimers Page 1--------------------------------------------------------

LED-480LS Product details Page 2-------------------------------------

GVM-560AS Product details Page 3----------------------------------

Product structure analysis Page 4------------------------------------

Installation method Page 567,,----------------------------------------

Accessories installation method Page 8,9-------------------------

Description of product control keys Page 10----------------------

Function introduction & instruction for use Page 11-------------

APP connection and APP control Page 12~13--------------------

Precautions Page 13------------------------------------------------------

Simple faults and troubleshooting Page 14------------------------

Use and preservation Page 15-----------------------------------------

Packing list Page 16-------------------------------------------------------

Welcome to "LED-480LS / GVM-560AS". This product is specially designed for senior

photography enthusiasts. The product is suitable for live / outdoor / studio photography,

and also for youtube video shooting. The main features of the product are:

PRODUCT INTRODUCTIONLED-480LS

PRODUCT DETAILS

①

②

③

1

The lamp can be installed and fixed on the bracket by rotating the knob

clockwise, and unloaded by rotating in the counterclockwise direction.

PRODUCT

STRUCTURE ANALYSIS

INSTALLATION

METHOD

2

Insert the diffuser from the side of the light panel.

Loosen the adjustment knobs on both sides of the U-bracket, adjust

the angle of the panel you need, and then tighten the adjustment

knobs on both sides of the U-bracket.

3

Brand : GVM

Type : Photography fill light

Number : LED-480LS

Material : Aluminum alloy

Number of light beads : 480

Color-rendering Index : ≥97

Color Temperature : 2300K---6800K

Luminance : 13000lux/0.5m, 3500lux/1m

Function/Characteristics : APP, High color rendering index light beads

Light angle of lamp bead : 45°

Power : 29W

Power Supply Mode : DC input & Battery

Voltage : AC:100-240V

Power specification : DC15V/3A

Battery Capacity : 7.4V-4400mAh*2 ( To be purchased separately)

Weight : 1KG

Size ( mm ) : 260x265x48

Heat Dissipation : Natural way

Brightness adjusting : Stepless adjustment

Color Temperature adjusting : Stepless adjustment

Origin : Huizhou, China

There are two power supply modes to choose.

① Connect the power cord and adapter for power supply.

② Purchase two other suitable lithium batteries and use them for power

supply. ( Both battery cells must be plugged in to power )

Cooling hole

WIFI reset

button

Brightness control

Adapter interface

Battery tank

Color

temperature

adjusting knob

Indicator light

Power switch

Electronic display

LED lamp beads

External diffuser

mounting screw hole

U-frame

Lamp rack interfaceLamp holder fixing knob

Lamp rack interface

Soft light spot

locking mouth

1

2

3

5

6

4

7

8

DC15V power input interface

Power switch

WIFI reset button: WIFI username and password reset button

Brightness indicator: when adjust the brightness knob, the indicator

is on

Color temperature indicator: when adjust the color temperature knob,

the indicator is on

Nixie tube: show value including lightness, color temperature and

channel

Color temperature adjustment button: adjust the color ( 2300K~6800K )

Brightness adjustment button: adjust the brightness ( 10%~99% )

WIFI username and password resetting

It is able to reset the WIFI username and password if long press the WIFI reset

button for over 5 seconds. After resetting, the username and the password will

return to the initial ( WIFI usernameGVM_LED, WIFI passwordgvm_admin ): : .

DESCRIPTION OF

PRODUCT CONTROL KEYS

FUNCTION INSTRUCTION &

INSTRUCTION FOR USE

USE AND

PRESERVATION

9101112131415

Angle fixing knob

4

1.

DISCLAIMERS

Before using this product, please read the instructions carefully and make sure

use the product correctly. If you don’t obey the instructions and warnings, you

maybe cause harm to yourself and the people around, or even damage the

product and other things around.

2.Once you use this product, you are deemed to have read the disclaimer and warning

carefully, understand and acknowledge all the terms and contents of this statement,

and promise to take full responsibility for the use of this product and possible

consequences.

GVM-560AS

PRODUCT DETAILS

Brand : GVM

Type : Photography fill light

Number : GVM-560AS

Material : Aluminum alloy

Number of light beads : 560

Color-rendering Index : ≥97

Color Temperature : 2300K---6800K

Luminance : 13500lux/0.5m, 3800lux/1m

Function/Characteristics : APP, High color rendering index light beads

Light angle of lamp bead : 45°

Power : 30W

Power Supply Mode : DC input & Battery

Voltage : AC:100-240V

Power specification : DC15V/3A

Battery Capacity : 7.4V-4400mAh*2 ( To be purchased separately)

Weight : 1KG

Size ( mm ) : 260x265x48

Heat Dissipation : Natural way

Brightness adjusting : Stepless adjustment

Color Temperature adjusting : Stepless adjustment

Origin : Huizhou, China

Step-less adjustable dual color temperature feature, color range 2300K ~ 6800k,

with High color rendering index LED lamp beads, which is helpful to restore and enrich

the color of objects and provide you with natural and vivid shooting effect.

App intelligent control system, which can be controlled by your intelligent mobile

device.

Digital display screen and stable system, which can support 360 ° rotation and

effectively control the light Line. You can also install folding and external soft light

board to avoid redundant light and make the light softer. You can customize the

control of fill light, so that you can easily shoot the desired results.

We firmly believe that the correct use of this product will definitely help your shooting

work. Before using the product, we strongly recommend that you carefully read the

following user guide.

1

2

3

4

00K

%P

WIFI RESET

2300K6800K

CCT

MINMAX

INTENSITY

87

6

5

② Adjust brightness (BRG) range 10%~99%:

Rotating brightness adjusting rotary knob can adjust brightness.

① ：Control options

③ Adjust color temperature (CCT)range 2300K~6800K:

Rotating brightness adjusting rotary knob can adjust color temperature.

④ Indicator light

When the brightness is adjusted by brightness level knob or APP, the

brightness indicator light is on and the color temperature indicator light

is off.

This product has two control modes: knob control and APP control.

Knob control: Adjust the brightness and color temperature by turning the

knob.

APP control: adjust brightness and color temperature through the mobile

APP.

When the color temperature is adjusted by the color temperature adjusting

knob or APP, the color temperature indicator will be on and the brightness

indicator will be off.

SIMPIE FAULTS

AND TROUBLESHOOTING

Phenomenon

①

②

Make sure the adapter is well

contacted with the power plug.

Charge the battery before using

it.

Check the product

Troubleshooting

The switch

indicator

does not light up

Check the matching power

adapter indicator light up

or not.

When using lithium battery,

make sure there's no "low

power" protection.

Check whether the WiFi is

connected in WiFi mode,

whether the WiFi is successfully

connected, and whether

“Connected” is displayed on the

APP.

Normal steps:

APP can't

connect / can't

control

①

②

Switch to WiFi mode after

booting;

Successfully connect to WiFi;

③Open the APP and the

connection will be successful.

Check if the product is “OFF”

because of the APP of the

mobile phone.

Press the “ON/OFF” button once

again.

The product is in

the "ON" state,

the display and

lights are not on

Check if the "Switch Device"

type in the APP main menu is

switched to "Singe/Double

color temperature light”.

Click APP main menu → Switch

device → Singe/Double color

temperature light

WiFi is

successfully

connected, but

the device cannot

connect to the

APP

Set master mode for the photography light (automatically as a master mode

when switching on the machine), open “GVM Easily” APP on the mobile phone

(meanwhile turn on WIFI on the phone), in the main menu in the APP----switch

the devices---select “Singe/Double color temperature light”, then in the main

menu in APP-----set----select “switch WIFI”, and connect photography light

(WIFI initial username: GVM_LED, password: gvm_admin), once it shows

“Device connection GVM_LED”, return back to the main interface, after it

shows “Connected” in the main interface, it is allowed to control the lightness,

color temperature, channel value or switch on and off through the control key

in APP, and also the slave machines.

APP CONNECTION AND

APP CONTROL

Scan the QR code on the back of the manual to download the APP

main menu

Current

channel value

1

Desktop Light Stand :

2

A

C

B

F

D

E

Loosen the A knob as shown in the figure below to clamp the lower end of

the lamp holder to the desktop, and then tighten the A knob to fix the lamp

holder on the desktop.

ACCESSORIES

INSTALLATION METHOD

Only some packages include the following accessories, subject to the actual purchase of the package

Light control folding can control the Angle of light.

Align the front mounting holes with the screw holes of the hinges and lock

the latches with screws.

Light control folding :

①

If the desktop is thick, you only need to loosen the B knob and C knob to

remove it, after adjusting E down, then install the B knob to the position of

the original C knob, and install the C knob to D. At this time, proceed to

step to install the light stand on a thicker desk.①

②

Loosen the knob of the lamp, install the lamp on the lamp holder as shown

in the figure, and then tighten the knob.

③

Loosen the F knob to adjust the height of

the lamp holder and tighten the F knob to

lock the height of the lamp holder.

④

Do not put the product in a highly humid, strong electromagnetic field,

direct sunlight, high-temperature environment. If not use the product for a

long time, disconnect the power and take out the battery.

Clean：Before clean, disconnect the power plug. And use wet cloth rather than any

detergent or soluble liquid, avoiding damaging the surface layer.

Repairing：If there is fault or performance degradation, do not unpack the shell by

yourself, avoiding damage the machine and lose the right of maintenance. When there

is a fault, do not hesitate to contact us, and we will do our best to deal with the problem.

Accessories：Please use the accessories provided by manufacturer and approved

ones, in order to maximize the performance.

Guarantee：Do does not modify the product, or you will lose the right of maintenance.

Clean：

Repairing：

Accessories：

Guarantee：

Power：Make sure the power is in the demanded range, not too high or too low. Correctly

load the battery, in order not the damage to machine.

Power：

PRECAUTIONS

①Please use the matching power adapter or lithium battery with the same

specification to power the product. Do not use power adapter with

different output voltage parameters.

The product is not waterproof, please use it in rainproof environment.②

The product is not anti-corrosion, therefore do not let the product touch

any corrosive liquid.

③

When using the product, make sure the product is put firmly and prevent

from falling and damage.

④

If the product will not be used for a long time, please switch off the power

to reduce energy loss.

⑤

Single

light kit

1

Power cord

Adapter

Diffuser

Barndoors

Name

Quantity

Two

lamp kit

Three

lamp kit

Notes

The desktop

light stand kit

2

12

12

12

2

23

Clip

4

1

4

23

3

3

3

32

2

2

2

2

Carrying Case

Instructions

1111

1111

Desktop Light

Stand

Light stand

PACKING LIST

Photography

lights

FacebookGVM Official

website

Download APP

IOS

Download APP

Android

Web: www.gvmled.com

B&H Email: bh@gvmled.com

GVM Email: support@gvmled.com

Amazon Email: amazonsupport@gvmled.com

Warehouse Add: 4301 N Delaware ave, unit D. PHILADELPHIA, PA19137, USA

Color filter

16
