GOS-6103C OSCILLOSCOPE

USER MANUAL

 i 

CONTENTS PAGE

1.

PRODUCT INTRODUCTION................................................

1-1.Description……………………………………………….

1-2.Feature…………………………………………………...

1

1

2

2. TECHNICAL SPECIFICATION…………………………..

4

3. PRECAUTIONS BEFORE OPERATION…….…………..

3-1.Unpacking the instrument………………….…………..

3-2.Checking the Line Voltage…………………..………….

3-3.Environment……………………………………..………

3-4.Equipment Installation and Operation………………....

3-5.CRT Intensity……………………………………………

3-6.Withstanding Voltage of Input Terminals……………...

7

7

7

8

8

8

8

4. PANEL INTRODUCTION……………………..…………..

4-1.Front Panel……………………………………………….

4-2.Rear Panel……………………………………….………

9

11

31

5. OPERATION METHOD………………………………...…

5-1.Readout Display……………………………………..…...

5-2.Connecting Input Signals..………………………………

5-3.Adjustment and Checks…………………………………

5-4.Function Check…..………………………………………

5-5.Basic Operation………….….…………………………...

5-6.Measurement Application……………………………….

33

33

35

36

38

40

48

6. MAINTENANCE……………………………………………

6-1.Fuse Replacement………………………………………..

6-2.Line Voltage…………………………………………..….

6-3.Cleaning………………………………………………….

53

53

53

54

7. BLOCK DIAGRAM………………………………………....55

GOS-6103C OSCILLOSCOPE

USER MANUAL

 ii 

SAFETY TERMS AND SYMBOLS

These terms may appear in this manual or on the product:

WARNING. Warning statements identify condition or

practices that could result in injury or loss of life.

CAUTION. Caution statements identify conditions or

practices that could result in damage to this product or

other property.

The following symbols may appear in this manual or on the product:

DANGER ATTENTION Protective Earth(ground)

High Voltage refer to Manual Conductor Terminal

Terminal
