Seite 1/5

THE BRIDGE IIIP

Table of Contents

INTRODUCTION 3

FEATURES 3

INCLUDED ITEMS 3

COMPATIBILITY 3

INSTALLATION 4

CHARGING THE iPod OR iPhone 5

UNDOCKING THE iPod OR iPhone 5

TROUBLESHOOTING 5

SPECIFICATIONS 5

THE BRIDGE IIIP

Introduction, Features, Included Items and Compatibility

Introduction

Congratulations! With The Bridge IIIP, you are entering the new world of entertainment

made possible by combining the incredible storage capacity and playback ﬂexibility of an

iPod or iPhone with the sonic power of your harman kardon

system.

With a single cable, your iPod or iPhone is connected, and all you need is your remote

control to get started!

Features

•Single connection to a The Bridge IIIP-ready harman kardon product

•Plays content from a compatible iPod or iPhone through your harman kardon system

•Outputs high-deﬁnition video up to 720p from compatible iPod and iPhone models,

when available on the device

•Controls your iPod or iPhone, using the harman kardon remote

•Easy track selection with on-screen navigation

Included Items

•The Bridge IIIP docking station

•Five clear dock adapters, marked “NANO,” “5G (VIDEO 60GB),” “5G (VIDEO 30GB),”

“13” and “12, 14”

•Black insert marked “UNIVERSAL” to accept appropriate dock adapter

Compatibility

At the time of the printing of this manual, The Bridge IIIP is compatible with the

harman kardon BDS 2, BDS 5, MAS 101, MAS 102 and MAS 111.

Made for iPod nano 5th generation, iPod touch 2nd generation, iPod classic, iPod nano

4th generation, iPod touch 1st generation, iPod nano 3rd generation, iPod with video.

Made for iPhone 4, iPhone 3GS, iPhone 3G and iPhone.

Please check www.harmankardon.com for the latest compatibility information.

Video and photo playback requires iPod model supporting video browsing and a video-

capable harman kardon product.

Refer to the user manual of the compatible harman kardon product for information about

operation and capabilities.

THE BRIDGE IIIP

Installation

Installing

With only a single cable connection, The Bridge IIIP is easy to connect to your harman

kardon product.

Step One:

Turn off the harman kardon The Bridge IIIP-ready product, using its main

power switch.

Step Two:

Holding the cable with the wider part of the connector at the bottom, gently

squeeze the tabs on each side as you insert it into the connector on the rear panel of the

harman kardon product. See Figure 1.

Step Three:

Place the black insert in The Bridge IIIP, making sure to push it all the way

down. See Figure 2.

NOTE: Do not place an iPod or iPhone in The Bridge IIIP unless both the black insert and

a dock adapter are installed. Otherwise, the iPod or iPhone will not connect properly,

and both it and The Bridge IIIP may sustain damage that is not covered by the warranty.

Step Four:

Locate the dock adapter that was included with your iPod or iPhone, or select

one of the included clear dock adapters by referring to Table 1. If your iPod or iPhone does

not appear in Table 1 and did not include an adapter, contact Apple Inc. to purchase one.

Place the adapter in The Bridge IIIP insert, as shown in Figure 2.

Step Five:

Remove the iPod or iPhone from any case, and dock it in The Bridge IIIP, as

shown in Figure 2.

Table 1 – Select the Correct The Bridge IIIP Dock Adapter

The Bridge IIIP Insert iPod Model

NANO iPod nano, 1st generation

5G (VIDEO 60GB) iPod, 5th generation (60GB, 80GB) and iPod classic

(160GB)

5G (VIDEO 30GB) iPod, 5th generation (30GB) and iPod classic (80GB)

13 iPod nano, 3rd and 4th generation

12, 14 iPod touch – install large bumper; iPhone 4,

iPhone 3GS, iPhone 3G, iPhone – install small bumper

Figure 2 – Docking an iPod or

iPhone in The Bridge IIIP

Figure 1 – The Bridge IIIP

connector

Step Five

Step Four

Step Three

Produktspezifikationen

Marke:	Harman Kardon
Kategorie:	Lautsprecher
Modell:	The Bridge IIIP
Breite:	114 mm
Tiefe:	114 mm
Gewicht:	167 g
Produktfarbe:	Schwarz
Übertragungstechnik:	Andocken
Höhe:	30 mm
Mikrofon-Eingang:	Nein
Schnittstelle:	Docking-Anschluss
Integrierter Kartenleser:	Nein
Kompatibilität:	iPod, iPhone
Ethernet/LAN:	Nein
