Havit M69 Bedienungsanleitung
Havit
KFZ-Halterung
M69
Lies die bedienungsanleitung für Havit M69 (1 Seiten) kostenlos online; sie gehört zur Kategorie KFZ-Halterung. Dieses Handbuch wurde von 3 Personen als hilfreich bewertet und erhielt im Schnitt 3.8 Sterne aus 2 Bewertungen. Hast du eine Frage zu Havit M69 oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/1
format music in it. (The Max storage of the
micro SD card is 32GB).
AUX mode
Connecting your music player/phone to the
speaker via the provided dual 3.5mm audio
cable, then the speaker will automatically
recognize.
One key for Siri
Short press the voice button to activate
voice assistant.
Music playing
1. Short press the play/pause button to
pause/play;
2. Long press the “-”for PREV;
3. Long press the “+”for NEXT.
4. Short press the“-”for VOL－;
5. Short press the“+”for VOL＋.
True Wireless Stereo (TWS) Fit for two M69
speakers
You can connect two M69 speakers as a
pair for stronger stereo and surrounding
effect.
1. Make sure the Bluetooth function is OFF
Power ON/OFF
1.Long press the power switch for 2
seconds to turn on, the LED indicator turns
blue and then flashes blue.
2.Long press the power switch for 2
seconds to turn off, the LED status
indicator goes off.
Bluetooth connection
1.Turn on the Bluetooth speaker, the LED
indicator flashes blue continuously while
waiting for paring.
2.Then active the Bluetooth of your phone
and search for "HAVIT M69". Click
manually to connect. If the connection is
successful, the LED indicator will turn
steady blue.
3. Since the speaker can automatically
reconnect to the last paired device. When
the Bluetooth of your device turns on, (Just
turn on the speaker), it will automatically
reconnect.
Answer incoming calls
Press the play/pause button to answer
incoming calls.
Tip: Since some mobile phones default to
answer calls via their own receiver, please
refer to the instructions of your phone and
set on your phone.
End the call
Press the play/pause button once to end
the current call.
Refuse incoming calls
Long press the play/pause button for 2s to
reject when there comes a call.
Last number redial
Dual press the play/pause button to redial
the last calling number.
Bluetooth disconnection
Dual press the mode button to cut off the
Bluetooth connection.
Mode switching
Short press mode button to select mode.
(Bluetooth/Micro SD card/AUX in)
Micro SD card mode
Insert a micro SD card, the speaker will
automatically recognize (with a voice
prompt) and automatically broadcasts MP3
5. Charge if the power LED indicator lights
up red, and it goes off upon charging
finished.
Specification:
Bluetooth version: V5.3
Rated power: 8W*2
Peak power: 12W*2
Battery capacity: 3.7V/3600mAh
Play time: 25H
Talk time: 25H
Charging time: 4H
Voice chat: Supported
Support: Bluetooth ,AUX ,Micro SD,TWS
Material: ABS+Fabric
Charge means: Type-C
Product size: 195*75*73mm
Net weight: 490g
Wireless working range: 18M (without
obstacles)
Speaker: 48mm*2
Input voltage: DC5V/2.4A
Warnings:
1. Please follow the instruction to operate.
2. PLS charge the product with input power
below 5V/2.4A, in order to protect the
battery;
3. Please store or use the product in a
normal temperature environment.
4. Please keep the product from heat source,
such as radiators, hot air regulators, stoves,
or other heat generating instruments. As it is
not anti-high temperature.
5. Don’t jam the ports of the product, such
as charger port, LED port and microphone
etc..
6. In order to protect your hearing and
extend the speaker service life, it is not
recommended to adjust the volume to the
maximum level for a long time.
7. If the speaker system halted, long press
the MFB to reset and power off.
8. Whatever reasons damage the product,
please feel free to contact our after-sales
staff in time rather than repair by yourself.
Otherwise, you will accept without
after-sales service.
on your Bluetooth player;
2. Turn on two speakers;
3. Long press mode button on either
speaker for 2 seconds, then there comes
up a melody which means the two speakers
are now in TWS pairing status. Until LED
of the auxiliary channel speaker lights up
steady blue and the LED of the main
channel speaker flashes, the TWS
connection is successful.
4. Then active the Bluetooth of your phone
and search for "HAVIT M69". Click
manually to connect.
Charging
1.As product has built-in non-removable
and rechargeable battery, please use the
provided TYPE-C cable to charge.
2. Charging voltage and current is 5V/2.4A,
please charge the speaker with the input
power below 5V/2.4A.
3. Please choose the charger that is
certified by the regular manufacturer.
4. The battery performance may decrease
as repeating charging and using the
speaker. It’s a normal phenomenon for all
rechargeable batteries.
1.Power switch
2.Mode button
3.PREVIOUS/VOL-
4.Play/Pause button
5.NEXT/VOL+
6.Voice button
7.Type -C charging port
8.Micro SD card port
9.AUX in
M69 STRONG BASS
WIRELESS SPEAKER
M69 STRONG BASS
WIRELESS SPEAKER
1 2 3 4 5 6 7 8
Certificate of quality x1
Bluetooth speaker x1
TYPE-C
Charging Cable x1 Dual 3.5mm audio cable x1
User manual x 1
Packing list
please keep this
document for reference
P r o d u c t
W a r r a n t y
P R O DU C T M A NU A L
P R O D U C T M A N U A L
Product structure
Produktspezifikationen
| Marke: | Havit |
| Kategorie: | KFZ-Halterung |
| Modell: | M69 |
