HERITAGE AUDIO 2264JR

PRELIMINARY USER GUIDE

The 2264JR is a 2 slot 500 series Compressor and Microphone Preamplifier. Both uses cannot

be archived at the same time.

Its audio path is fully discrete Class A, transformer balanced. All controls are stepped on rotary

switches for easy recall and high precision.

It features discrete inputs for Compression / Line amp (Left slot input) and mic (Right slot

input).

Output in both cases is in the Left slot output.

Use as a compression amplifier

The 2264JR turns into a class A compressor by pressing the “DYN”dynamics ) switch. The (Gain

reduction meter will light, indicating compression is engaged.

- H Hi pass filter button: Engages a 200z high pass filter on the sidechaincircuit,

(not signal path!) eliminating the effect of heavy bass signals riding the

compression effect.

-FAST button: Sets the attack into FAST mode, and is the attack originally found in

the classic 2264 range of compressor modules.

- LINK button:Links 2 or more compressors OF THE SAME TYPE. Please read the

note at the end of this document before pressing the LINK button, as damage to

third party units may occur.

-RECOVERY switch: Sets the release time. Auto modes A1 and A2 set different

release times for peaks and program material and can be taken as start points.

-THRESHOLD switch: Sets the signal level above which compression occurs.

- RATIO switch:Sets the relationship between input and output signal levels.

-GAIN MAKEUP: Amplifies the already compressed signal in 2dB steps.
