The Mutant Brain
24.April.2018 Mutant Brain user manual v1.00 PG1
Hexinverter Électronique, 2018
16 output
MIDI
to trigger, gate, polyphonic cv…and more
Thank you for your interest in/purchase of the Mutant Brain. We would like to thank you for considering a
place for the Mutant Brain in your modular synthesizer! Simple to use yet incredibly versatile and highly
accurate, the Mutant Brain can be the nerve center of your modular system. The Mutant Brain is a Eurorack
modular format product, available as a built module only.
BRIDGING THE GAP
Since the early 1980s MIDI has been how most synthesizers, sequencers, drum machines and keyboards
have talked to each other. Yet both old and new analogue synthesizers still use voltage for control, in the
form of continuous CV, gates and triggers. The analogue resurgence and the growth of Eurorack has meant
that CV-equipped synths have increased, rather than decreased, in popularity. At the same time the number
of devices capable of sequencing MIDI have proliferated - and many of these tend to be on the cheaper side.
Then, of course, there is the MIDI sequencer that exists in your computer: DAWs like Cubase and Ableton now
include incredibly sophisticated MIDI sequencers. If you’re a Eurorack user who wishes to incorporate any
MIDI device in your setup, or if you wish to use your PC and DAW to control your modular, you need a MIDI to
CV converter.
With the Mutant Drums Hexinverter Électronique has long been focused on providing modular users with the
best, most exciting and versatile modular drums experience. With six drum modules and a mixer the only
thing missing from the Mutant Drums was a means of sequencing. We deliberated for years over the
question: should we make a sequencer for our Mutant Drums? But this didn’t seem like the right idea, since
there has been such a resurgence of inexpensive, standalone MIDI drum machines and sequencing units!
Why re-invent the wheel? Eurorack already provides plenty of great sequencers, but for many users these
take up too much rack space, are too expensive, or are too fiddly to use for performanc. For users who do
invest in a modular sequencer, combining them with other sequencers in a live setting can be tricky without
the ability to sync transport controls.
What’s needed is a reasonably priced, versatile, low-HP module that can effectively bridge the gap between
MIDI and CV…….enter, the Mutant Brain!
The Mutant Philosophy
This module brings the Mutant Drums line to full maturity. With seven drum modules, a mixer and now
the Mutant Brain as the link to your MIDI sequencer of choice, the Mutant Drums form a remarkably
capable and utterly unique modular drum system.
There are already some great clones of vintage gear out there. The Mutant Drums are different. Although
every Mutant drum module began life as a classic drum topology, each one has been meticulously
designed from the ground up. We aim to create fully-fledged instruments that can transcend the
limitations and exploit the capabilities of the modern modular system.
24.April.2018 Mutant Brain user manual v1.00 PG2
Hexinverter Électronique, 2018
EASY OF USE AND MAXIMUM VERSATILITY
Unlike MIDI to CV devices that use MIDI-learn technology to program their ports, the Mutant Brain loads a
SysEx file that you create by filling out a simple web form. Once configured Mutant Brain will behave exactly
as you have programmed it until you decide to change it. For most users we expect this to be a ‘set and
forget’ module, providing a seamless link between your favourite MIDI sequencer and your modular rack. But
its range of capabilities, and the fact that loading a new SysEx files takes seconds, means you may want to
experiment with less obvious use cases!
Ever wanted to try setting up a modular keyboard patch with note velocity? How about four-note polyphony?
What about using your DAW to sequence your modular…sending LFOs as well as notes. Mutant brain allows
you to do all that and more.
TECHNICAL SPECIFICATIONS
Width: Depth: 8HP | 30mm
Current draw: +50mA, -4mA @ 12V
CV output resolution: 12bits (V/oct or V/Hz)
QUICK START
Straight out of the box, the Mutant Brain outputs are assigned as follows:
cv A
channel 1 – note pitch
cv B
Channel 2 – note pitch
cv C
channel 2 – note pitch
cv D
Channel 4 – note pitch
gate 1
channel 1 – note gate
gate 2
Channel 2 – note gate
gate 3
channel 3 – note gate
gate 4
Channel 4 – note gate
gate 5
channel 10 – trigger, note C4
gate 6
channel 10 – trigger, note D4
gate 7
channel 10 – trigger, note E4
gate 8
channel 10 – trigger, note F4
gate 8
channel 10 – trigger, note G4
gate 9
channel 10 – trigger, note A5
gate 10
channel 10 – trigger, note B5
gate 11
channel 10 – trigger, note C5
24.April.2018 Mutant Brain user manual v1.00 PG3
Hexinverter Électronique, 2018
This pre-loaded patch gives you 4 CV and gate pairs, each on their own MIDI channel 8 trigger outputs , plus
on a separate MIDI channel. Most MIDI sequencers use channels 1 and 2 as default MIDI note outputs and
most drum machines use channel 10, so this setup is fairly universal.
The specific notes used for each drum on channel 10 vary widely from device to device. We have used the
natural notes (white notes) from C4 (middle C on most keyboards) to C5. Depending on what device you are
using and your needs it may be easiest to simply match your sequencer mappings to these default settings.
However, there are many ways to assign MIDI notes and events to these outputs, as shown in the diagram
below:
MIDI Inputs Mutant Brain Outputs
CV Gate
Note
•
•
Clock
•
Velocity
•
Continuous CC
•
Transport
•
