Seite 1/2
Gang box is not supplied.
The height of the can refer to the wall switch standard, and it is about 1.4 m above the ground.Gang box
When inserting an peripheral module, ensure that the silicone rubber ring is intact to prevent rain and other input.
(Optional) According to actual needs, you can connect other modules to the USB interface, and secure them with 2 M3 screws.
Cable Hole
Silicone Rubber
Ring
Apply Silicone
Sealant
Make sure the gang box is installed on the wall.
Secure the
mounting plate
on the gang box with two supplied screws (SC-KA4X25).
Route the cable through the cable hole, wire the cables and insert the cables in the gang box.
Apply silicone sealant among the cable wiring area to keep the raindrop from entering.
Align the device with the mounting plate, and secure the device on the mounting plate with 1 supplied screw (SC-KM3X8-T10-SUS-NL).
UD35448B
Install with Mounting Plate
Interfaces and Dimension
Peripheral Module
For Better recognition, there should be light source in or near the
installation environment.
The minimum bearing weight of the wall or other places should be 3
times heavier than the device weight.
Installation Environment:
Avoid backlight, direct sunlight, and indirect sunlight.
Direct Sunlight
Direct Sunlight
through Window
Indirect Sunlight
through Window
Backlight
Close to Light
118.2 mm
MIC
Camera
Screen
SIM Card Slot
TF Card Slot
Wiring Terminal
Debugging Port
(For debugging only)
Reserved
Tamper
Indicator
26.5 mm
23.85 mm
233.99 mm
Card Presenting/
Fingerprint
Adding Area
Loudspeaker
Type-A USB Interface
1
DS-K1T670 Series
Face Recognition Terminal
Quick Start Guide
Quick Guide
4 Other Operations
Activate the device.
3 Activation
1.1 Open the box.
1.2 Check the environment.
1.3 Install the device.
2.1 Power supply wiring.
2.2 Door lock wiring.
2.3 Door contact wiring.
2.4 Exit button wiring.
2.5 Wiegand wiring.
2.6 RS-485 wiring.
2.7 Alarm in/out wiring.
4.1 Quick operation settings.
4.2 Authentication settings.
2 Wiring
1 Installation
Installation
If the audio plug diameter is greater than 8 mm, an external adapter is required.
The figures are for reference only.
The peripheral module can be accessed according to actual needs.
Data Protec�on
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Document
h�ps://www.hikvision.com
About this Product
Acknowledgment of Intellectual Property Rights
LEGAL DISCLAIMER
2
2 3 4
Wiring
Wiring Activation Other Operations
Device Wiring
Secure Door Control Unit Wiring
Steps:
Ac�vate
Activation via Device
Steps Afterwards
Log in Home Page
Restore to Factory
password, or keyfob
Tap System Maintenance - Restore to Factory All
parameters will be restored to the factory settings. The system
will reboot to take effect.
